2.2

Powering on/Off

Information The iCAM501 must be fully powered on before plugging a USB cable into
the camera or to take a picture. This will be indicated when the green
LED has stopped flashing.
Press and hold the "FLASH"
and "RECORD" buttons
simultaneously until the "ON"
LED starts to flash green.
The diagrams above show how to power on the iCAM501. The same procedure is
required to turn the iCAM501 off. Once it is turned off no LEDs should be lit.

2.3 Installing the iCAM501 With an Operating System

This section will provide details on how to install the iCAM501 to be used with a
supported host operating system. Although the iCAM501 supports various Linux
Operating Manual
Green LED will flash for ~10
seconds while the camera boots.
The Blue and Red LED will flash
briefly during boot up. The Green
LED then goes solid when ready
6
for operation.
