4 Technical Data

Certification Number
ATEX Certification
IECEx Certification
FM Certification
Compliance
Dimensions
IP Rating
Operating Temperature
Weight
Housing
Relative humidity
Power
Memory
Lens
Focal Distance
View Finder
Power Modes
Battery Life
Connectivity
OS Support
Flash
Audio recording format
Image format
Time and Date
Operating Manual
ITS09ATEX26868X, IECEx ITS 09.0027X
II 1 G Ex ia IIB T4 Ga, II 2 G Ex ia IIC T4 Gb
II 1 G Ex ia IIB T4 Ga, II 2 G Ex ia IIC T4 Gb
Class 1 Div 1 ABCD T4 - Pending
EMC: EN 55022 1998 class B, EN 55024 1999
LV: EN 60950 2002
FCC: Class A device, compliance through verification route
132mm x 32mm x 22mm (5.20" x 1.26" x 0.87")
IP65
-20ºC to +60ºC
Approx 200g including batteries
Injection moulded anti static plastic housing
95% RH non condensing
2 x Alkaline AA batteries, refer to Ex Certificate for details on range of approved batteries
On board 1Gbyte NAND Flash (holds approx 5,000 JPEG images without any audio
recording and additional 960Kbytes per min for audio)
3.1 Mega-Pixel (2048 x 1536 resolution)
1/4" format lens, F/#2.8, focal length 3.8mm
30 cm to infinity
Two element optical view finder
Operate and auto power-down (after 2 mins)
Up to 800 shots without flash and up to 150 shots with flash taken one after the other. 310
shots as per the CIPA DC-002 standard (mixed mode shots with and without flash)
Note it is very difficult to be precise about exact numbers as there are many factors that can
influence this such as the ambient temperature, how long the camera is powered up,
number of voice recordings made and the number and length of time it is connected to a PC
for transferring picture and voice data.
USB 1.1 via mini-USB socket for use in the safe area only. Certified for direct connection to
a PC without requiring an external protection barrier
PTP imaging device in Windows 2000/XP/Vista/7, Mac OsX 10.x and most versions of Linux.
USB firmware upgrade utility for Windows XP/2000/Vista/7 only.
4 LED flash giving 43.7 lux.seconds of energy at 67ms exposure
16KHz 16bit Microsoft Wave Format
jpeg
Time and date stamping of stored images
Time and date set via Picture Transfer Protocol (PTP) automatically
