Haier 10518526 Operation Manual

Haier split type room air conditioner operation manual
Hide thumbs

Advertisement

Quick Links

SPLIT TYPE ROOM AIR CONDITIONER

OPERATION MANUAL

HSU-09HEA03/(BP)
HSU-12HEA03/(BP)
Please read this operation manual before using the air conditioner.
0010518526

Advertisement

loading

  Summary of Contents for Haier 10518526

  • Page 1: Operation Manual

    SPLIT TYPE ROOM AIR CONDITIONER OPERATION MANUAL HSU-09HEA03/(BP) HSU-12HEA03/(BP) Please read this operation manual before using the air conditioner. 0010518526...
  • Page 2: Safety Instructions And Warnings

    Damaged air conditioners are not to be put into operation. In case of doubt, consult your supplier. Use of the air conditioner is to be carried out in strict compliance with the relative instructions set forth in the User's Guide.
  • Page 3: Specifications

    Cautions Do not obstruct or cover the ventilation grille of the air conditoner.Do not put fingers or any other things into the inlet/outlet and swing louver. Do not allow children to play with the air conditioner.In no case should children be allowed to sit on the outdoor unit.
  • Page 4: Parts And Functions

    Parts and Functions Indoor Unit Display board Inlet Air Purifying Filter (inside) Inlet grille Horizontal flap (adjust up and down air flow. Don't adjust it manually) Actual inlet grille may vary from the one shown in the manual according to the product purchased Outdoor Unit OUTLET...
  • Page 5: Clock Set

    Parts and Functions Remote controller ON/OFF TEMP MODE TIMER CLOCK SWING HEALTH POWER/SOFT LOCK RESET 1. Operation mode display COOL DRY Operation mode Remote controller Display board 2. SWING display 3. FAN SPEED display AUTO 4. HEALTH display POWER/SOFT display 6.
  • Page 6: Remote Controller's Operation

    Operation Remote controller's operation When in use, put the signal transmission head directly to the receiver hole on the indoor unit. The distance between the signal transmission head and the receiver hole should be within 7m without any obstacle as well. Don't throw the controller, prevent it from being damaged.
  • Page 7: Cool Operation

    (4) Fan speed selection Press FAN button. For each press, fan speed changes as follows: Remote controller: AUTO Air conditioner is running under displayed fan speed. Air conditioner is running under displayed fan speed. Unit stop Press ON/OFF button, the unit stops. Hints On cooling only unit, heating mode is not available.
  • Page 8: Heat Operation

    Operation Heat Operation (1) Unit start Press ON/OFF button, unit starts. Previous operation status appears on display. (Not Timer setting) (2) Select operation mode Press MODE button. For each press, operation mode changes as follows: HEAT COOL Unit will run in operation mode displayed on LCD. Stop display at your desired mode.
  • Page 9: Dry Operation

    Operation Dry Operation (1) Unit start Press ON/OFF button, unit starts. (2) Select operation mode Press MODE button. For each press, operation mode changes as follows: HEAT COOL Unit will run in operation mode displayed on LCD. Stop display at your desired mode. (3) Select temp.
  • Page 10 Operation (5) Air flow direction adjustment After operation mode is selected, horizontal flap will open automatically according to the mode. Referring to the Fig. COOL About 10 Up and down (Use remote controller) Press SWING button, horizontal flap will move within the range shown in the Fig.
  • Page 11: Timer Operation

    Operation TIMER Operation Set Clock correctly before starting Timer operation You can let unit start or stop automatically at following times: Before you wake up in the morning, or get back from outside or after you fall asleep at night. TIMER ON/OFF (1)After unit start, select your desired operation mode.
  • Page 12: Power Operation

    Operation POWER/SOFT Operation POWER Operation When you need rapid heating or cooling, you can use this funciton. Selecting of POWER operation Press POWER/SOFT button. Every time the button is pressed,display changes as follows: POWER Stop the display at In POWER operation status: In COOL mode, fan speed automatically runs in HI mode for 15 min then returns to original status setting.
  • Page 13: Emergency Operation

    More than 23 Less than 23 If an air conditioner is a model for both cooling and heating. Cooling when the room temperature at the start of operation is above 23 Heating when the room temperature at the start of operation is below 23...
  • Page 14: Maintenance

    Maintenance Replacement of Air Purifying Filter 1.Open the lnlet Grille Prop up the inlet grille by using a small device named grille-support which located in the right side of the ind- oor unit. 2.Detach the standard air filter Slide the knob slightly upward to release the filter, then withdraw it.
  • Page 15: During Operation

    Maintenance For Smart Use of The Air Conditioner Setting of proper room temperature Close doors and windows during operation If the unit is not to be used for a long time, turn off the power supply main switch. Do not block the air inlet...
  • Page 16: Safety Instruction

    Installation Please call Sales/Service Shop for the Installation. Do not attempt to install the air conditioner by yourself because improper works may cause electric shock, fire, water leakage. lnstallation in a inadequate place may cause accidents. Do not install in the following place.
  • Page 17 Cautions When abnormality such as burnt-small found, immediately stop the operation button and contact sales shop. Connect power supply cord to the outlet completely STRICT ENFORCEMENT Do not use power supply cord in a bundle. PROHIBITION Do not start or stop the operation by disconnecting the power supply cord and so on.
  • Page 18: Troubleshooting

    When the electric plug is pulled out and reinserted, the protection circuit will work for 3 minutes to protect the air conditioner. During unit operation or at stop, a swishing or gurgling noise may be heard. At first 2-3 minutes after unit start, this noise is more noticeable.
