  • Page 1 Workingman’s 4004 OWNER’S MANUAL SWR • CORONA, CA • USA...
  • Page 2 SWR product. We truly hope that your purchase of an SWR helps bring out the best in your playing and adds to your enjoyment of music.
  • Page 3 If you hear a small amount of distortion and the Preamp Clip LED is not activated, try using the Active input jack. And please note, some passive pickups DO distort. Because of the hi-fi nature of all SWR products, even the smallest amount of distortion originating at the source (instru- ment) may be heard.
  • Page 4 ACTIVE INPUT The Active input jack should be used with instruments having a built-in (on-board) preamp that will pro- duce signals over 1 volt RMS. Known basses that should use the Active input only are the Kubicki X- Factor and some Ovation electrics. Some really "hot" pickups installed in your instrument may find the Active input more compatible.
  • Page 5 TONE CONTROL SECTION The Workingman's 4004 Tone Control section is a five-band set of level slide controls centered around the frequencies 80 Hz (Bass), 160 Hz (Low Mid), 400 Hz (Mid), 800 Hz (Hi Mid) and 3KHz (Treble). Each control can cut or boost its band a maximum of 15dB. Each slider has a flat (center click) position that defeats its function.
  • Page 6 EFFECTS BLEND CONTROL The Effects Blend control mixes the signal coming from your instrument with the sound coming from your effect. With the Blend control fully counter-clockwise, no signal from your effect will be heard. As you turn this control clockwise, more of the effect can be heard in the overall sound. When the Blend control is fully clockwise, no dry or unaffected signal is heard other than the output of your effect device.

  • Page 7: Rear Panel Features

    STEREO HEADPHONES JACK By inserting a set of stereo headphones into this jack you will be able to monitor your sound or practice without disturbing your neighbors. The headphone volume level is adjusted by the Master Volume. We suggest you begin with the Master Volume full off (counter-clockwise), then slowly bring up the volume to the desired level.
  • Page 8 The total impedance of the speakers should be 4 Ohms or greater. This means you can use one 4 ohm cabinet, two 8 ohm cabinets or four 16 ohm cabinets. RECOMMENDED SPEAKER ENCLOSURES FROM SWR INCLUDE: Workingman's 4X10T, Workingman's 1X15T, Goliath III, Son Of Bertha, and the Big Ben Subwoofer (you can use any two of these as they are all 8 ohms).

  • Page 9: Suggested Settings

    SUGGESTED SETTINGS WORKINGMAN’S 4004 • 9...
  • Page 10 SUGGESTED SETTINGS (CONTINUED) WORKINGMAN’S 4004 • 10...
  • Page 11 WORKINGMAN’S 4004 LIMITED WARRANTY The WORKINGMAN’S 4004 from SWR is warranted to the original consumer purchaser for ONE YEAR from the date of purchase against defects in materials and workmanship, provided that it is purchased from an Authorized SWR dealer. This warranty applies only to products purchased in the USA or Canada.
