- Page 1 WORKINGMAN’S WORKINGMAN’S SERIES SERIES BASS COMBOS BASS COMBOS ’ ’ OWNER OWNER’ ’ S MANUAL S MANUAL INCLUDES: INCLUDES: WORKINGMAN’S 10 WORKINGMAN’S 12 WORKINGMAN’S 15 SWR • SCOTTSDALE, AZ • USA...
-
Page 2: Table Of Contents
Just a little humor there, but true nonetheless. For over 15 years we here at SWR have been putting everything we know about bass into the SWR product line. We’ve earned a reputation for designing and manufacturing gear that has changed the way bassists hear themselves. -
Page 3: Workingman's 10
WORKINGMAN’S 10 WORKINGMAN’S 10 80 watt, 1x10 combo amplifier with tweeter. A small yet powerful bass cube, extremely portable. The SWR Sound “to go.” Speaker Complement: Speaker Complement: (1) Custom Designed 10" SWR driver (1) Custom Designed Piezo tweeter Power Output: 80 Watts RMS, 100 Watts RMS @ 4 Ohms... - Page 4 True low fundamentals (one of the sonic signatures of all SWR amplifiers) require lots of headroom and air motion. That’s why we recommend that 5-string players use an extension cabinet to increase the power output of the amplifier and get more air moving.
-
Page 5: Rear Panel Features
this control clockwise, more of the effect can be heard in the overall sound. When the Blend control is fully clockwise, no dry or unaffected signal is heard other than the output of your effect device. This type of control and patching arrangement is very effective in reducing noise caused by effects devices and in maintaining a more natural sound. - Page 6 The impedance of the speaker should be 8 ohms or greater. If you wish to connect two additional cabi- nets be sure their combined impedance is not less than 8 ohms (equivalent to two 16 ohm speaker cabinets in parallel). Recommended speaker cabs from SWR are: Workingman’s 1X10T, Workingman’s 1X15T, Workingman’s 2X10T, Workingman’s 4X10T. STEREO HEADPHONES JACK By inserting a set of stereo headphones into this jack you will be able to monitor your sound or practice without disturbing your neighbors.
- Page 7 replacement will be easy at almost any computer, electronics or pro audio store. NOTE: The rating for this cable is 3-conductor, 10 amperes. This is a rating of the current capacity of the cable, designated for higher power-drawing devices like amplifiers. If replacement is neces- sary, or if you wish to buy a longer cable, look for the rating on the cable and be sure it is at least 10 amps.
-
Page 8: Suggested Settings
WORKINGMAN’S WORKINGMAN’S 10 Suggested Settings 6 6 • WORKINGMAN’S COMBOS OWNER’S MANUAL... -
Page 9: Workingman's 12
120 watt, 1x12 combo amplifier with tweeter. A little powerhouse. Great for both electric and upright basses. Speaker Complement: Speaker Complement: (1) Custom Designed 12" SWR driver (1) Custom Designed Piezo tweeter Power Output: 120 Watts RMS, 160 Watts RMS @ 4 Ohms Power Output:... - Page 10 DO distort. Because of the hi-fi nature of all SWR products, even the smallest amount of distortion originating at the source (instrument) may be heard. Active Input The Active input jack should be used with instruments having a built-in (on-board) preamp that will pro- duce signals over 1 volt RMS.
- Page 11 True low fundamentals (one of the sonic signatures of all SWR amplifiers) require lots of headroom and air motion. That’s why we recommend that 5-string players use an extension cabinet to increase the power output of the amplifier and get more air moving.
-
Page 12: Rear Panel Features
This type of control and patching arrangement is very effective in reducing noise caused by effects devices and in maintaining a more natural sound. If your effects device has a similar control, we suggest leaving it set to its maximum effect/minimum dry signal position and using the Effects Blend control for this function. - Page 13 8 ohms (equivalent to two 16 ohm speaker cabinets in parallel). Recommended speaker cabs from SWR are: Workingman’s 1X10T, Workingman’s 1X15T, Workingman’s 2X10T, Workingman’s 4X10T, Son Of Bertha, Goliath III and Big Ben.
- Page 14 A/C LINE CORD RECEPTACLE Accepts a standard A/C power cable (supplied with the Workingman’s 12 in the United States), used with almost all current musical, professional and household electronic devices. If it becomes misplaced, replacement will be easy at almost any computer, electronics, or pro audio store. NOTE: The rating for this cable is 3-conductor, 10 amperes.
-
Page 15: Suggested Settings
WORKINGMAN’S WORKINGMAN’S 12 Suggested Settings WORKINGMAN’S COMBOS OWNER’S MANUAL • 13... -
Page 16: Front Panel Features
200 watt, 1x15 combo amplifier with tweeter. Perfect for small to medium size gigs. Lightweight! Speaker Complement: Speaker Complement: (1) Custom Designed 15" SWR driver (1) Custom Designed Piezo tweeter Power Output: 160 Watts RMS, 200 Watts RMS @ 4 Ohms Power Output:... - Page 17 Preamp Clip LED is not activated, try using the Active input jack. And please note, some passive pickups DO distort. Because of the hi-fi nature of all SWR products, even the smallest amount of distortion originating at the source (instrument) may be heard.
- Page 18 True low fundamentals (one of the sonic signatures of all SWR amplifiers) require lots of headroom and air motion. It is for this reason that we recommend that 5-string players use an extension cabinet to increase the power output of the amplifier and get more air moving.
- Page 19 The Treble control operates in a tonal area that extends through and beyond the usual Treble control range. It may be thought of as a “transparency” control. Boosting the control will open up the sound of a dull instrument, particularly in conjunction with the piezo tweeter in the Workingman’s 15. However, this is also the range of string rattle, finger slides, pickup clicks, etc.
-
Page 20: Rear Panel Features
LIMITER LED The Limiter LED lights when your signal has reached the Limiter threshold, letting you know that the Limiter circuit has been activated. NOTE: No harm is being done to your amplifier when this LED lights or stays lit. THREE WAY SELECTOR SWITCH The top position, labeled Full Range, activates both the tweeter and the 15"... - Page 21 8 ohms (equivalent to two 16 ohms speaker cabinets in parallel). Recommended speaker cabs from SWR are: Workingman’s 2X10T, Workingman’s 4X10T, Workingman’s 1X15T, Goliath III and Big Ben. A/C LINE FUSE The line fuse can open (blow) due to power surges or high powerline transients.
-
Page 22: Suggested Settings
WORKINGMAN’S WORKINGMAN’S 15 Suggested Settings 20 • WORKINGMAN’S COMBOS OWNER’S MANUAL... - Page 23 IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS CAUTION: TO REDUCE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER OR BACK. NO USER-SERVICEABLE PARTS INSIDE. PLEASE REFER TO A QUALIFIED SERVICE TECHNICIAN. A. Read Instructions: All safety and operation instructions should be read before the product is operated. B.
-
Page 24: Covers & Replacement Parts
ONE (1) YEAR from the date of purchase, against defects in materials and workmanship and provi- -ded that it is purchased from an Authorized SWR Dealer. This warranty applies only to products purchased in the USA or Canada. This warranty is VOID if the unit has been damaged due to accident, improper handling, the installation or operation, shipping damage, abuse or misuse, unauthorized repair or attempted repair, or if the serial number has been defaced or removed.
