Owner's Manual
Steel Round Gazebo
Product Code: D71 M11969
KSN: 03975385-0
Made in / Hech en CHINA
UPC Code: 805670021153
Distributed by Sears, Roebuck and Co., Hoffman Estates, IL 60179
See our extensive assortment of outdoor living products
on-line at www.sears.com and www.kmart.com
Date of Purchase: _____/ _____/ _____
Advertisement
Related Manuals for Garden Oasis Steel Round Gazebo
Summary of Contents for Garden Oasis Steel Round Gazebo
- Page 1 Owner’s Manual Steel Round Gazebo Product Code: D71 M11969 KSN: 03975385-0 Made in / Hech en CHINA UPC Code: 805670021153 Distributed by Sears, Roebuck and Co., Hoffman Estates, IL 60179 See our extensive assortment of outdoor living products on-line at www.sears.com and www.kmart.com...
- Page 2 Assembly Instruction for Round Gazebo (GFM00330F) ***CAUTION: The remote control is not water resistant! During severe or inclement (Rain, Snow, Wet...) weather, you must keep it indoors!
- Page 3 Description Image Part List Beam Beam with Screw Holder Cambered Rail Long Slide Bar Short Slide Bar Post Folding Canopy Canopy Cover Support Bar Canopy Cover Attachment Tube Solar Panel Beam Hub Light Cover Light Rail Connect Post Holder Base Canopy Handle Netting Canopy Cover...
- Page 4 Image Part List Description Plastic Washer W 12 for Slide Bars Screw & Nut Screw & Nut Screw Screw Screw Screw Nut Wrench Magnetic Plate Allen Wrench Light Control with Holder Slide Bar Holder Plastic Grove Countersunk Screw Ground Stake Wrench...
- Page 5 Step 1 Fig 1 Fig 2 Fig 3 Step1: 1. Lay down all 6pcs Cambered Rails (C) in a cycle. Insert all 6pcs Rail Connecters (N) into the end of Cambered Rails (C), keep screw holes straight, as shown in Fig.1 2.
- Page 6 Step 2 Fig 2 Fig 1 Fig 3 Fig 4 Step2: Connect all 5pcs of Beams (A) and 1pc of Beam with Screw Holder (B) to Beam Hub (K). Use 1pc M6x15 Screw (Z) to secure each beam to Beam Hub (K), as shown in Fig.1 & Fig.2 This step requires 2 people to lift the Roof structure onto the circle structure.
- Page 7 Step 3 Fig 5 Fig 4 Fig 6 Fig 3 Fig 1 Fig 2 Step3: Insert the bottom rib (the one without wheel) of the Canopy (G) into the bottom of Beam with Screw Holder (B), as shown in Fig.1 Connect the top rib of the Canopy (G) onto the top of Beam with Screw Holder (B) with M5x15 Screw and Nut (X), as shown in Fig.2 Place the ribs with wheels onto the Cambered Rail (C), as Shown in Fig.3 &...
- Page 8 Step 4 Fig 1 Fig 2 Step4: With one person holding the Light (M), another person connect the two wires as shown in Fig.1 Secure the Light (M) under the Folding Canopy (G) by inserting 2pcs M6x15 Screws(Z) through the bracket and into the top of the Light(M). A s shown in Fig.2...
- Page 9 Step 5 Fig 1 Fig 2 Fig 4 Fig 3 Step5: Insert the 2pcs Canopy Cover Attachment Tube (I) into Canopy Cover (S) as shown in Fig.1. Attach the Canopy Cover (S) to the Beams (A & B) with 3pcs M6x15 Screws (Z) on each Beam. As shown in Fig.3 &...
- Page 10 Step 6 Fig 3 Fig 4 Fig 2 Fig 1 Step6: Take out Solar Panel (J), Be sure to turn on the Solar Panel (J) (Press the red button) , as shown in Fig.1 Thread the wire on the Solar Panel (J) into the big hole of the Light Cover (L). Connect the Solar Panel (J) and Light Cover (L) with 1pc M6x15 (Z).
- Page 11 Step 7 Fig 1 Fig 2 Fig 3 Step7: Attach the Canopy Handle (Q) onto the first outer rib on the front of Folding Canopy (G) with M5x25 Screw and Nut (Y). Make sure the magnet on the handle can be adhered onto the rail.
- Page 12 Step 8 Fig 1 Fig 3 Fig 2 Step8: This step requires 6 people and 6 step ladders Put 6 Posts (F) vertically and close to the Post Holder (O) on the roof structure. have 6 person lift the roof onto the Post (B). Adjust the Post's position to ensure the screw holes are in line with Post Holder (F).
- Page 13 Step 9 Fig 3 Fig 4 Fig 2 Fig 1 Take out 1pc Short Slide Bar (E) and 1pc Long Slide Bar (D), connect the two slide bars with M6x68 Screw (Z2) in the middle of bars. Make sure there is a Plastic Washer (W) between two bars and a plastic Washer (W) between the Long Slide Bar (D) and Cambered Rail (C).
- Page 14 Step 10 Fig 2 Fig 1 Fig 3 Put the Plastic Rings (V) into the holes on the top of Sidewalls (T) and Nettings (R). Hang the Sidewall (T) onto the Long Slide Bar (D) which is closer to the Cambered Rail (C) as shown in Fig.1.
