- Page 1 Saratoga 5 Piece Bar Set OWNER'S MANUAL Product Code: D71 M80193 UPC Code: 7-6945575806-4 Vendor Item: SS-J-251-1NMT Date of Purchase: _____ /_____ /_____ Receipt of Purchase: Attach Here See our extensive assortment of outdoor living products on-line at www.sears.com and www.kmart.com...
- Page 2 PARTS Read through all the instructions before beginning assembly. Unpack and identify all the parts. Place them on a flat, non-abrasive surface. Assembly by two people is recommended. A (1) B (1) C (2) Left Tempered Right Tempered Left Mesh Shelf Glass with Rim Glass with Rim E (1)
- Page 3 ASSEMBLY INSTRUCTIONS Fig. 1 Place the left and right side apron panel (E&F) on a flat surface. Assemble side apron panels (E& F) by sliding the hinge pins together. Rotate the hinges to ensure a secure fit. See Fig. 1. Fig.
- Page 4 Turn over the assembled tabletop (A& B) and place Fig. 8 it onto the assembled body. Insert a short bolt (Ga) Fig. 7 through a metal washer (Gd), through the tabletop (A) and into the side panel (E) for each hole. See Fig. 6. Do not tighten.
