- Page 1 Saratoga 7 Piece Dining Set OWNER'S MANUAL Product Code: D71 M80190 UPC Code: 7-6945575838-5 Vendor Item: SS-J-251-1NR/6 Date of Purchase: _____ /_____ /_____ Receipt of Purchase: Attach Here See our extensive assortment of outdoor living products on-line at www.sears.com and www.kmart.com...
- Page 2 PARTS Read through all the instructions before beginning assembly. Unpack and identify all the parts. Place them on a flat, non-abrasive surface. Assembly by two people is recommended. B (6) A (4) C (2) Sling Seat And Chair Frame Rocker Frame Back F (2) D (2)
-
Page 3: Assembly Instructions
ASSEMBLY INSTRUCTIONS ROCKER ASSEMBLY Place the sling seat and back (B) and the rocker frame (C) on a flat surface. Align the holes, from outside insert a long bolt (Gc) through a small metal washer (Gd), through the front crossbar of rocker base (C), through the crossbar of seat Fig. - Page 4 Place the rocker base (E) on a flat surface, Fig. 4 and insert the center post (F) into the hole located at the center of the base (E). See Fig. 4. Push the center post (F) down firmly and twist it left and right as necessary.
- Page 5 Turn over the chair frame. Line up the holes and insert a short bolt (Gb) through a small metal washer (Gd), through the sling seat and back (B), secure into the chair frame (A). See Fig. 7. Do not tighten completely. Repeat procedure for the other side.
