- Page 1 OWNER’S Product code: D71 M80446 UPC code: 7-6945575825-5 MANUAL Vendor Item: SC-176NSF/4 Malden 4 Piece Seating Set Date of purchase: _____/ _____/ _____...
- Page 2 PARTS Read through all the instructions before beginning assembly. Unpack and identify all the parts. Place them on a flat, non-abrasive surface. Assembly by two people is recommended. B (2) A2 (3) C (2) A1 (3) Seat for Cushion Chair Left Arm Back for Cushion Chair Right Arm...
- Page 3 ASSEMBLY INSTRUCTIONS All parts are shrink wrapped together. Remove all components from the box and place on top of the box. Carefully cut the wrapping open. Count and identify all parts. Fig. 1 Attach the back for cushion chair (C) to the seat for cushion chair (B).
- Page 4 Attach the left arm (A2) to the seat for the loveseat (D). Fig. 8 Align the holes, for upper hole insert an M6 x 50L bolt (Kd) through a metal washer (Kg), the arm (A2) and secure into the front crossbar of the seat (D). For lower hole insert an M6 x 50L bolt (Kd) through a metal washer (Kg), the arm (A2), the bracket of the seat (D) and secure with a nut (Kh).
