Using the Dumping Feature
To operate the dumping feature, pull the dumping
release handle outward to release the plastic bed from
the locking mechanism. Lift up the release handle to
rotate cart upward into the dumping position.
CAUTION
DO NOT EXCEED MAXIMUM OVERALL LOAD CAPACITY 600 LBS.
MAXIMUM DUMPING LOAD CAPACITY 300LBS
Returning the Plastic Bed to
the Lowered Position
Rotate the plastic bed back down to the lowered position.
Make sure the dumping release handle is locked into place
when the cart is in the lowered position.
Garden
Dump
Cart
Owners Manual
10
Model RMD
6
• Important Safety Instructions
• Assembly Instructions
• Parts and Hardware Identification
CAUTION:
Read, understand and follow ALL instructions before using this product.
For product inquiries:
Tricam Industries Asia Ltd.
7677 Equitable Drive
Eden Prairie, MN 55344
800-867-6763
U.S. Patent No. 6,851,756
Other Patents Pending
12/05
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Rubbermaid RMD106
Summary of Contents for Rubbermaid RMD106
- Page 1 Using the Dumping Feature Returning the Plastic Bed to the Lowered Position To operate the dumping feature, pull the dumping release handle outward to release the plastic bed from Rotate the plastic bed back down to the lowered position. the locking mechanism. Lift up the release handle to Make sure the dumping release handle is locked into place rotate cart upward into the dumping position.
-
Page 2: Important Safety Instructions
Important Safety Instructions Step 6 Step 7 Assemble the wheels using bushings (4pcs.), washers Assemble the handle to the yoke using M8X60 bolt (1pc.), (4pcs.), and cotter pins (4pcs.). M8 lock nut (1pc.) and washer (1pc.) 1. READ ALL INSTRUCTIONS CAREFULLY BEFORE USE. If you do not understand these instructions, need clarification or further explanation, please call our toll free answer line for assistance at 1-800-867-6763.
