Power Walker VI 400 User Manual

Uninterruptible power supply
Hide thumbs
1
2
3
4
5
6

Advertisement

Table of Contents

7. TROUBLE SHOOTING

To call for service, please have the model, serial number, and
description of the problem available.
PROBLEM
POSSIBLE CAUSE
NO LIGHT (UPS
1. The power switch is in
"OFF" or not pressed
NOT ON)
2. The voltage for battery is
weak
3. Battery failure
4. Power Connection looses 4. Check the input power and
BUZZER BEEPS
1. Overload of the UPS.
CONTINUOUSLY
1. Battery failure
BACKUP TIME IS
2. AC fuse may be burnout. 2. Replace fuse or call for service.
SHORT OR
ALWAYS IN
3. Battery is not fully
charged.
"BATTERY MODE"
4. Power Connection loses
SOLUTION
1. Press power switch to turn on.
2. Re-charge the UPS at least 8
hours.
3. Replace with the same type of
battery or call for service.
replug it again
1. Remove the noncritical load or
call for service.
1. Replace with same type of
battery or call for service.
3. Re-charge the UPS at least 8
hours.
4. Check the input power and
replug it again
11
POWER WALKER VI 400/600/800

Uninterruptible Power Supply

USER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VI 400 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Power Walker VI 400

Summary of Contents for Power Walker VI 400

  • Page 1: Trouble Shooting

    POWER WALKER VI 400/600/800 7. TROUBLE SHOOTING To call for service, please have the model, serial number, and Uninterruptible Power Supply description of the problem available. PROBLEM POSSIBLE CAUSE SOLUTION USER’S MANUAL NO LIGHT (UPS 1. The power switch is in 1.
  • Page 2 Thank you for 1. INTRODUCTION purchasing PowerWalker UPS. PowerWalker VI series is a line interactive UPS which is designed to protect your personal computer or sensitive electronic equipments. The UPS is equipped with boost Safety information and operating instructions are to stabilize input voltage.

  • Page 3: Safety Requirements

    2. SAFETY REQUIREMENTS 3. OVERVIEW Please save this manual properly. This manual Front Panel includes important safety information. Please read it carefully and thoroughly before operating the UPS. Comply with all the warnings and operating instructions on the unit and in the manual strictly. To reduce the risk of electric shock, the user must disconnect the UPS from the mains supply before installing any cable.
  • Page 4 Back Panel 5. RS-232 Communication Port This communication port is used to communicate with a computer or modem and support the operating systems 1. Battery Power Supplied Receptacle The power supplied receptacles are used for battery to power up your equipments while AC is failure. 2.

  • Page 5: Installation

    5. Connect the Computer 4. INSTALLATION Connect the interface cable from your computer to the Before the installation, please ensure the power switch output receptacles on the back panel of the UPS. on the UPS is in "OFF" position, and the voltage of the 6.

  • Page 6: Monitoring Software

    6. TECHNICAL SPEICIFICATION After the UPS has been installed, you must install the MODEL software(Smart Power) that came packaged with your PowerWalker PowerWalker PowerWalker VI 400 VI 600 VI 800 UPS. Smart Power monitoring software performs the CAPACITY VA/W 400VA/240W...
