Page 1: Installation Manual
SPLIT SYSTEM AIR CONDITIONER OWNER’S MANUAL & INSTALLATION MANUAL MODELS: GD09I - GD12I - GD18I Thank you for Choosing a Dimplex Air Conditioner, Please read this OWNERS MANUAL carefully prior to use. -
Page 2: Table Of Contents
Thank you for choosing a DIMPLEX air conditioner, please read this owner's manual carefully before operating the unit and keep it for future reference. The product images in this manual may be slightly different to your actual unit. Depending on the model, some models have a display and some models dont, for actual position and shape of the displayer/finish please refer to the physical unit itself. -
Page 3: Operation And Maintenance
Operation and maintenence This Dimplex Air Select the most appropriate tem- Unplug the air conditioner conditioner must be when not used for a long perature. installed by a qualified period. installer. We recommend setting the temperature at 18 - 20 C The appliance also needs to bi-wired by a qualified electrician. -
Page 4: Instructions Prior To Operation
Instructions prior to operation The airflow direction is adjustable. The vertical If the power cord is damaged, it must be replaced direction of the airflow can be adjusted with the by the manufacturer or a service agent or a upward/downward louvers. The horizontal similarly qualified person in order to avoid a direction of airflow can be adjusted with the hazard. -
Page 5: How To Use Your Air Conditioner
How to use your Dimplex Air Conditioner Working mechanism and special functions for cooling mode Principle: Air conditioners absorb the heat in a room, then transmit that heat outdoors, where it is then discharged. This decreases the ambient indoor temperature. The cooling capacity of the air conditioner may increase or decrease depending on the outdoor ambient temperature. - Page 6 How to use your Dimplex Air Conditioner Anti-cool air function: The unit is designed not to blow cold air on HEAT mode when the indoor heat exchanger is in one of the following three situations: 1. When heating mode begins 2.
-
Page 7: Names And Functions Of Each Part
Names and functions of each part Indoor unit Air inlet Air outlet Icons on display: Cool Remote Control Power cable Hea t Remote control Front panel Se t temp. Filter Guide louver Outdoor unit Wall pipe Air inlet Binding tape Connection wire Drainage hose Air outlet... -
Page 8: Operation Of Remote Control
Operation of remote control Descriptions and functions of remote control Make sure there is nothing obstructing the receiver or the remote control. Do not drop or throw the remote control. Keep liquids away from the remote control. Do not place the remote control in direct sunlight, or keep near very high temperatures. - Page 9 Operation of remote control Description and functions of remote control Please note: The remote control is the same for all units. Should your unit not support all the functions displayed on the remote control, pressing those buttons will not affect your unit.
- Page 10 Operation of remote control Description and functions of remote control Please note: The remote control is the same for all units. Should your unit not support all the functions displayed on the remote control, pressing those buttons will not affect your unit.
- Page 11 Operation of remote control Guide for - General operation 1. Press this button to turn the unit ON. Press it again to turn the unit OFF. When the unit is turned off, the guide louver will close automatically. 2. Press the MODE button to select the desired running mode. 3.
- Page 12 Operation of remote control ‘Lock’ Feature Press +and - buttons simultaneously to lock or unlock the remote. If the remote control is locked, the will be displayed. If a button is pushed while the keypad is locked, the will flash. When the keyboard is unlocked, the [lock icon] will disappear Swing Glider Operation 1.
-
Page 13: Emergency Operation
Emergency operation Turning the display light on/off The LIGHT button allows you to turn the light on and off. You can use this feature to turn on/off the ambient light of the unit if you intend to sleep whilst the unit is operating. To turn the display light on: Press the LIGHT button. -
Page 14: Clean And Care
Clean and care Caution Before cleaning, turn the power off and unplug the unit to prevent electric shock. To clean, use a damp cloth to wipe the unit down. Never put water on or in the unit when cleaning, or electric shock may occur. Never use flammable liquids to clean the air conditioner. - Page 15 Clean and care Check before use Make sure nothing is obstructing the intake or outlet vents. Make sure the ground wire is properly connected. Check the batteries. Make sure the outdoor stand is not damaged. If it is, please contact the retailer for further assistance. Maintenance and Upkeep Turn main power off.
-
Page 16: Troubleshooting
Troubleshooting CAUTION Do not attempt to repair the unit by yourself. If the unit is not functioning properly, please check the following troubleshooting guide before contacting Dimplex customer services. Malfunction Solution The unit does not restart. Once the air conditioner has been turned off, it will not restart within three minutes. - Page 17 Troubleshooting Malfunction Solution Is the power turned off? The unit is not running. Has the cable come out of the outlet? Has the circuit breaker tripped? Is the voltage of the outlet too high or too low? (Please get a professional to test this.) Is the TIMER on? Is the set temperature suitable? The unit is not cooling or heating efficiently.
- Page 18 If any of the following situations occur, turn off and unplug the unit immediately and contact Dimplex customer services on 09 274 8265 (NZ) or 1300 556 816 (AUS) - There is a loud or harsh sound coming from the unit.
-
Page 19: Installation Instructions
If the unit is not installed by an accredited installer, the unit may not be installed properly and malfunctions may occur. The Dimplex 5 year warranty will also be void. Basic Requirements for Unit Location This unit should not be installed in any of the following locations: Close to high heat sources or flammable vapours, gases, or materials. -
Page 20: Grounding Requirements
Installation Instructions Safety Requirements For Electric Appliances 1. The circuit and power supply must be compatible with the unit and cable. 2. Do not yank or tug on the power cable. This unit must be properly grounded, and should therefore be installed by a qualified technician. -
Page 21: Installation Dimension Diagram
Installation dimension diagram Installation dimensions diagram Distance to the ceiling or more Distance to the wall or more or more Distance to the wall or more or more Air outlet side Distance to the floor This diagram shows the necessary dimensions for the location of the unit. -
Page 22: Installing The Indoor Unit
3. Pass the power cable and the signal control wire from the back of the unit in through the wiring hole. 4. Reattach the clasp and wiring cover. 5. Reattach the surface panel. GD18I unit GD09I /GD12I N(1) 2 BLU BLK BRN YEL - GRN YELLOW-... - Page 23 Installing the indoor unit NOTE: Make sure the wires are all properly connected. Improper connections may result in malfunctions of the unit. Tighten the terminal screw to prevent the wires from disconnecting. Once the screw is tightened, tug gently on the wire to make sure it is properly connected. If the grounding wire is not properly connected, it may cause electric shock.
-
Page 24: Installing The Outdoor Unit
Installing the outdoor unit Electric wiring Handle Pull the handle on the right hand side of the outdoor unit. Undo the clasp. Attach the power cable and signal control wire to the terminal. The wiring should match that of the N(1) 2 indoor unit. -
Page 25: Post-Installation Checklist And Operation Test
Post-installation checklist and operation test Check after installation Things to check If improperly installed... The unit may shake, make loud noises, Is the unit securely attached to the wall? or fall down. The unit may not heat or cool efficiently. Have you done the refrigerant leakage test? Condensation may form. -
Page 26: Installation And Maintenance Of Silver Ion Filter
Installation and Maintenance of Silver Ion Filter Installation Instructions 1. Pull up gently on the front cover. The cover will hinge upward. Pull the air filter down and out of the unit (see Figure a). Fig. a Fig. b 2. Mount the Silver Ion filter onto the air filter, (as Air filter shown in Figure b). - Page 27 Contact Details: Glen Dimplex Australia Pty Ltd 2/205 Abbotts Road Dandenong South 3175 Victoria, Australia Phone: 1300 556 816 Fax: 1800 058 900 Email: sales@glendimplex.com.au web: www.dimplex.com.au Glen Dimplex New Zealand Ltd P.O. Box 58473 Botany Manukau 2163 New Zealand...
