HandPunch 2000 Installation and Operations Manual
Installation planning
Use the following guidelines to help in installing your HandPunch.
Place the terminal where it does not interfere with pedestrian or vehicular traffic.
The terminal platen (hand placement surface) should be 40 inches above the floor.
The wire run between the terminal and computer must not exceed 50 feet (15 meters).
The terminal must be within 5 feet (1.5 meters) of a 120VAC duplex outlet.
An 8 foot (2.4 meter) cable is included with modem units. The telephone connection
must be within 8 feet of the terminal to use this cable.
Hand reader placement
The reader should be in a convenient location where it is not exposed to water,
chemicals, or direct sunlight.
3
