BENCH TOP 10'' TABLE SAW
MODEL G5045

INSTRUCTION MANUAL

COPYRIGHT ©2000 BY GRIZZLY IINDUSTRIAL, INC.
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
REVISED AUGUST, 2000 PRINTED IN USA
DISCONTINUED MACHINE MANUAL DISCLAIMER
THE INFORMATION IN THIS MANUAL REPRESENTS THE LAST CONFIGURATION OF THE MACHINE BEFORE IT WAS DISCONTINUED. MACHINE CON-
FIGURATIONS MAY HAVE CHANGED AS PRODUCT IMPROVEMENTS WERE INCORPORATED. IF YOU OWN AN EARLIER VERSION OF THE MACHINE,
THIS MANUAL MAY NOT EXACTLY DEPICT YOUR MACHINE . CONTACT CUSTOMER SERVICE IF YOU HAVE ANY QUESTIONS ABOUT DIFFERENCES.
PREVIOUS VERSIONS ARE NOT AVAILABLE ONLINE.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the G5045 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Grizzly G5045

Summary of Contents for Grizzly G5045

  • Page 1: Instruction Manual

    INSTRUCTION MANUAL COPYRIGHT ©2000 BY GRIZZLY IINDUSTRIAL, INC. WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC. REVISED AUGUST, 2000 PRINTED IN USA DISCONTINUED MACHINE MANUAL DISCLAIMER THE INFORMATION IN THIS MANUAL REPRESENTS THE LAST CONFIGURATION OF THE MACHINE BEFORE IT WAS DISCONTINUED.
  • Page 2 WARNING Some dust created by power sanding, sawing, grind- ing, drilling, and other construction activities contains chemicals known to the State of California to cause cancer, birth defects or other reproductive harm. Some examples of these chemicals are: • Lead from lead-based paints. •...

  • Page 3: Table Of Contents

    TABLE INSERTS ...22 PUSH PADDLES ...22 FEATHERBOARDS ...22 MAINTENANCE GENERAL ...23 LUBRICATION ...23 UNPAINTED SURFACES...23 CLOSURE MACHINE DATA...24 PARTS DIAGRAM ...25 PARTS LIST ...26-29 PUSHSTICK TEMPLATE ...30 WARRANTY AND RETURNS ...32-33 G5045 10'' Bench Top Table Saw Table Of Contents PAGE...

  • Page 4: Safety Instructions For Power Tools

    DON’T FORCE TOOL. It will do the job better and safer at the rate for which it was designed. USE RIGHT TOOL. Don’t force tool or attachment to do a job for which it was not designed. G5045 10'' Bench Top Table Saw VISITORS...
  • Page 5 It’s safer than using your hand and frees both hands to operate tool. G5045 10'' Bench Top Table Saw 13. DON’T OVERREACH. Keep proper footing 14. MAINTAIN TOOLS WITH CARE. Keep 15. DISCONNECT TOOLS before servicing 16.

  • Page 6: Additional Safety Instructions For Table Saws

    Everyday glasses or reading glasses only have impact resistant lenses, they are not safety glasses. Be certain the safety glass- es you wear meet the appropriate stan- dards of the American National Standards Institute (ANSI). G5045 10'' Bench Top Table Saw ⁄ " equipment.

  • Page 7: Section 2: Circuit Requirements

    SECTION 2: CIRCUIT REQUIREMENTS 110V Operation The 1 H.P. motor supplied with the G5045, draws approximately 13 amps @ 110V. We recommend a dedicated 15-amp breaker. This should be sat- isfactory for normal use, while providing enough protection against motor damage caused by power surges or overload.

  • Page 8: Section 3: General Information

    SECTION 3: GENERAL INFORMATION Commentary We are proud to offer the Grizzly Model G5045 Bench Top Table Saw. The Model G5045 is part of the growing Grizzly family of fine woodworking machinery. When used according to the guide- lines set forth in this manual, you can expect years of trouble-free, enjoyable operation and proof of Grizzly’s commitment to customer satis-...

  • Page 9: Clean Up

    G5045 10'' Bench Top Table Saw Site Considerations 1. Floor Load: Your G5045 10" Table Saw represents a moderate weight load in a small footprint. Most floors are suitable for the table saw. Some older residential floors may require additional build up to support both machine and operator.

  • Page 10: Unpacking

    Unpacking The Model G5045 Table Saw is shipped from the manufacturer in a carefully packed carton. If you discover the machine is damaged after you’ve signed for delivery, please call Customer Service immediately for advice. Save the containers and all packing materials for possible inspection by the carrier or its agent.

  • Page 11: Assembly Bench Mounting

    SECTION 4: ASSEMBLY Bench Mounting The Model G5045 can be mounted on a work- bench or a portable stand, in addition to its stan- dard heavy-duty base. If the saw is bench-mount- ed, it is essential to create a cutout below the saw to allow sawdust to exit the machine.
  • Page 12 Figure 6. Fastening stand to saw body. 6. Level the stand by checking all sides for symmetry. Measure diagonally from top to bottom and adjust the stand so both diago- nals are equal. Tighten all of the stand bolts. G5045 10'' Bench Top Table Saw...

  • Page 13: Handwheels

    1. Attach the fence locking lever by threading it into the eccentric located at the front of the fence. See Figure 8. G5045 10'' Bench Top Table Saw Figure 8. Attaching fence locking handle. 2. Lift the fence over the saw’s table top, ensuring that the rear holding clamp fits over the rear rail.

  • Page 14: Blade Attachment

    Blade Attachment The Model G5045 is shipped with a general pur- pose 10" blade. To install the blade: 1. Disconnect the saw from its power source and remove the table insert by removing the two screws. 2. Raise the arbor to its top position by turning the blade height handwheel.

  • Page 15: Dust Collection Port

    9. Check splitter alignment after tightening. G5045 10'' Bench Top Table Saw Dust Collection Port The Model G5045 10" Bench Top Table Saw is equipped with a dust which can be attached to standard 2 ⁄ " dust collection systems. To connect your table saw to a dust collection system: 1.

  • Page 16: Adjustments Rip Fence

    " thick hardwood to the blade side of the fence. This protects the fence from contact with the blade when dadoing or rip- ping thin stock. The fence is already drilled to accept the needed screws. G5045 10'' Bench Top Table Saw...

  • Page 17: Miter Gauge

    Miter Gauge The miter gauge provides angle-adjustable sup- port for workpieces while cross-cutting with the Model G5045 Table Saw. To adjust the miter gauge: 1. Loosen the clamp knob so the gauge is free to rotate. 2. Slide the miter gauge into one of the two miter slots.

  • Page 18: Positive Stops

    Re-check with your straight edge. 5. Re-adjust if necessary. Once you are satisfied with the results, repeat the process for the 45° positive stop. To adjust the 45° positive stop: 1. Tilt the blade to its maximum angle. G5045 10'' Bench Top Table Saw...

  • Page 19: Table Parallelism

    7. Re-adjust, if necessary. G5045 10'' Bench Table Parallelism The G5045 table is factory-aligned. In the unlike- ly event furthere adjustment is needed, a quick inspection checks table parallelism: 1. Place your miter gauge (set at 90°) in its slot, even with the front of the blade.
  • Page 20 5. If the blade and square don’t meet proper- ly, loosen screws and adjust the table until the blade and straightedge are properly aligned, front and back. See Figure 22. 6. Tighten screws and re-check for parallel. -18- G5045 10'' Bench Top Table Saw...

  • Page 21: Section 6: Operations

    Items 1 and 2 are prevalent in ripping operations, while item 3 can occur during ripping or crosscutting. G5045 10'' Bench Top Table Saw Always observe these steps to prevent the possi- bility of kickback occurring: 1. Always use the splitter and guard.
  • Page 22 This section on Blade Selection is by no means comprehensive. Always follow the saw blade manufacturer's recommendations to assure safe and efficient operation of your table saw. G5045 10'' Bench Top Table Saw Most blade...

  • Page 23: Ripping

    Blade height in excess of that recommend- ed increases the danger of contact between the blade and fingers or other body parts. G5045 10'' Bench Top Table Saw Crosscutting Crosscutting means cutting across the grain of the wood. In wood products without grain (i.e.

  • Page 24: Table Inserts

    C. Push Paddle D. Feather Board G5045 10'' Bench Top Table Saw ⁄ " apart. Clamp the...

  • Page 25: Maintenance General

    G5045 10'' Bench Top Table Saw Unpainted Surfaces Any non-painted surfaces on the Model G5045 should be protected against rust and pitting. Wiping the saw clean after every use ensures that moisture from sawdust isn’t allowed to trap moisture against bare metal surfaces.

  • Page 26: Warranty And Returns

    SECTION 9: CLOSURE The following pages contain general machine data, parts diagrams/lists and Warranty/Return information for your Model G5045 10" Bench Top Table Saw. If you need parts or help in assembling your machine, or if you need operational information,...

  • Page 27: Machine Data Sheet

    Switch ...Toggle with Safety Lock Tab and Thermal Reset Arbor: Size: ... Features: ...10" Blade ...2 ...Portable Design Specifications, while deemed accurate, are not guaranteed. G5045 10'' Bench Top Table Saw MACHINE DATA SHEET ⁄ '' x 19'' x 38'' ⁄ '' W x 14 ⁄...

  • Page 28: Parts List

    -26- G5045 10'' Bench Top Table Saw...
  • Page 29 G5045 10'' Bench Top Table Saw -27-...
  • Page 30 PART # DESCRIPTION 410 P5045410 STAND LEG 412 PCB01M CARR BOLT M8-1.25 x 20mm 413 PN03M HEX NUT M8-1.25 414 PW01M FLAT WASHER 8mm 416 P5045416 UPPER BRACKET LONG 417 P5045417 BOTTOM BRACKET LONG 418 P5045418 FOOT PAD 419 P5045419 WRENCH 420 PB18M HEX BOLT M6-1 x 15mm...
  • Page 31 DRIVE SCREW 100 P5045100 FENCE 101 P5045101 LOCKING ROD 102 P5045102 REAR CLAMP 103 P5045103 SPRING G5045 10'' Bench Top Table Saw PART # 104 PW03M 105 P5045105 106 PS17M 107 P5045107 108 P5045108 109 PSB26M 110 P5045110 113 P5045113...

  • Page 32: Pushstick Template

    HEX HD BOLT BOTTOM SUPPORT BRACKET EXTENSION WING HEX NUT ⁄ "-16 WASHER ⁄ " SCREW M6 X 16 WASHER ⁄ " LOCK WASHER ⁄ " SCREW ⁄ "-16 x ⁄ " SCALE LABEL G5045 10'' Bench Top Table Saw...
  • Page 33 G5045 10'' Bench Top Table Saw -31-...
  • Page 34 Notes -32- G5045 10'' Bench Top Table Saw...

  • Page 35: Warranty And Returns

    WARRANTY AND RETURNS Grizzly Imports, Inc. warrants every product it sells for a period of 1 year to the original purchaser from the date of purchase. This warranty does not apply to defects due directly or indirectly to misuse, abuse, neg- ligence, accidents, repairs or alterations or lack of maintenance.

  • Page 36: Warranty Card

    Do you think your purchase represents good value? ___Yes Would you recommend Grizzly Imports to a friend? ___Yes Would you allow us to use your name as a reference for Grizzly customers in your area? Note: We never use names more than three times. ___Yes Comments:_________________________________________________...
  • Page 37 FOLD ALONG DOTTED LINE FOLD ALONG DOTTED LINE Send a Grizzly Catalog to a friend: Name_______________________________ Street_______________________________ City______________State______Zip______ GRIZZLY INDUSTRIAL, INC. P.O. BOX 2069 BELLINGHAM, WA 98227-2069 TAPE ALONG EDGES--PLEASE DO NOT STAPLE Place Stamp Here...
