Page 3
Thank you! Mail to: documentation@teracue.com All information within this document is confidential to Teracue costumers and should not be copied or distributed to non Teracue customers. All Teracue products and all of its components are registered trademarks RADEMARKS licensed to Teracue.
Page 4
User Guide V1.1 Information about the manual This manual is designed to help administrators and users to install the DCH-510P™ on their computer. If you received this publication as a PDF, then it's a good idea to print it out for future reference.
DCH-510P™ User Guide V1.1 Content BEFORE USING THE DEVICE ....................... 6 ........................6 AFETY WARNINGS ..........................6 MODELS THAT ARE COVERED BY THIS USER MANUAL ............7 INSTALLATION ..........................7 ..........................7 NSPECTION ........................ 7 PERATING OLTAGE ..........................8 USES ......................
Do not remove the covers of this equipment. Hazardous voltages are present within this equipment and may be exposed if the covers are removed. Only Teracue trained and approved service engineers are permitted to service this equipment.
DCH-510P™ User Guide V1.1 Models that are Covered by this User Manual Model DCH-510P™-x DCH-510P™-x-x Tuner -T2-IP -C-IP -T-IP -S2-IP ASI Input Built-in Re-MUX ■ ■ ■ ■ ■ ■ ■ ■ ASI-Output (Redundancy) ■ ■ ■ ■ ■ ■...
DCH-510P™ User Guide V1.1 The Fuses The recognized recommended fuses are size 5 by 20 mm, rate T 2.0A, 250 V (UL and IEC approved). The line fuse is housed in a small container besides the power connector on the rear panel. To check the fuse, insert the tip of a screwdriver in the slot at the middle of the container and pry gently to extend the fuse where there is a little tap and pull out the fuse gently.
DCH-510P™ User Guide V1.1 Power on the Device Be sure the device is mounted into the rack properly and firmly, and the signal cables are connected well, then power can be applied to the device. The main socket and fuse are located at the rear panel of the device.
DCH-510P™ User Guide V1.1 Input Menu There are four options: Status, DVB-S2, RSSI and Ethernet (optional): Inputs Status RSSI DVB-S2 Ethernet 5.1.1 Status Menu It contains four options, ASI1, ASI2, TUNER and IP IN, to show the status of signal input: ASI1: When signal from ASI1 input port is locked, it will display package format and code rate;...
DCH-510P™ User Guide V1.1 5.1.4 Ethernet Menu (The Ethernet menu is showed only if the IP streaming in/out board is installed and the TS/IP streaming board is set to “IP IN”. Refer to chapter 5.3.6.) The Ethernet connector is for receiving transport stream over IP. The Ethernet connector has user- configurable IP address, network mask and default gateway.
DCH-510P™ User Guide V1.1 5.2.1 BISS Menu It includes Biss Mode, Biss 1 Setup and Biss E Setup. Biss Mode: Set Biss mode, can select OFF, Biss E or Biss 1 Biss 1 Setup: Set Biss 1, password is required...
TS will be delivered to the ASI output port on the back panel. Program: under this sub menu, you will see all program names detected by DCH-510P™. The programs could be coming from ASI input, Tuner, TS/IP input, the internal CI decryption portion, BISS Decryption portion or MUX TS.
Page 14
DCH-510P™ User Guide V1.1 Video: You can configure the video parameters of programs in this submenu. Press the <ENTER>-key to confirm or press the <EXIT>-key to cancel. Video Standard: You can select Auto/1920x1080i 60/1920x1080i 50/1280x720p 60/1280x720p 50/720x480p 60/720x576p 50/525x480i 60/625x576i 50 for the video output.
DCH-510P™ User Guide V1.1 5.2.4 You can configure the settings of ASI1 in this menu. ASI1 Source: Press the <ENTER>-key and use the < > or < >-key to roll up or down to select the signal source of ASI output, there are 5 optional types of signal source:...
TS ID: you can configure the TS ID to mark the multiplexed TS. Default value is 1. Program List: press the <ENTER>-key to enter ‘MUX List’ sub-menu. It shows all programs detected by DCH-510P™. The programs come from ASI input, Tuner, TS/IP input or the internal CI decryption. Use <...
DCH-510P™ User Guide V1.1 5.2.8 Ethernet (Note this menu is shown only when the TS/IP streaming is installed and the board is set to “IP Out”, refer to chapter 5.3.6 for how to set up.) The TS/IP Ethernet connector could also be configured as the output of the transport stream over IP.
Page 18
'Multicast IP' on the first row, the stream itself is Unicast. The IP address of receiver device (maybe PC with XPlayer™) needed to be set to as the unicast address on DCH-510P™, please don't use DHCP to get a dynamic IP address for receiver device.
5.3.1 Local Setup Each DCH-510P™ has an IP address, a network sub mask and a gateway. These must be set to an appropriate value for the network over which the unit can be accessed by the remote control system such as the HDMS.
DCH-510P™ User Guide V1.1 5.3.4 Properties Version: show software version of this device MAC Address: Factory-set MAC address which is guaranteed to be unique. You cannot configure this address. Linux OS version: show Linux OS version ARM SW version: show ARM software version...
DCH-510P™ User Guide V1.1 Specification DVB-S2 Demodulation Input frequency range 950~2150MHz Input level 25~-65dBm Input impedance Connector F Connector Symbol rate 2~45MBauds for QPSK; 2~45MBauds for 8PSK Rolling off factor 0.35 for QPSK; 0.35, 0.25, 0.2 for DVB-S2 Punctured rates...
Page 22
DCH-510P™ User Guide V1.1 YPbPr 1080ix60, 1080ix50, 1280x720px60, 1280x720px50, 720x480p60, 720x576p50, 576ix50, 480ix60, 1080ix59.94 CVBS port 576ix50, 480ix60 Management Ethernet Connector RJ45, 10/100M, for NMS and software upgrade Protocol SNMP, TCP/IP, HTTP Front panel control LCD display and keypad General...
How to Receive a Multicast or Unicast Stream Normally, the DCH-510P™ is set to IP Output by the factory. To set the DCH-510P™ to IP input mode, please follow the procedure below: 1. Only on the front panel is accessible, go to Main Menu ->...
Target Mac address-> set the MAC address of the receiving device. The parameter will be used only when the receiving device is located under the same gateway. The parameter will be ignored by DCH-510P™ if the receiving device is located under other remote network or under different gateway.
− will be used only when the receiving device is located under the same gateway. The parameter will be ignored by DCH-510P™ if the receiving device is located under other remote network or under different gateway. 0-Switch -> turn on/off channel 0.
<= 16 A per phase and not subject to conditional connection. EN 60950-1:2006 + A11:2009 Information technology equipment – Safety – Part 1: General requirements This regards to the following Teracue products: DCH-510P-S2, DCH-510P-S2-IP DCH-510P-C, DCH-510P-C-IP DCH-510P-T, DCH-510P-T-IP DCH-510P-T2, DCH-510P-T2-IP...
