MODEL G0636X
17" ULTIMATE BANDSAW
OWNER'S MANUAL
COPYRIGHT © MAY, 2007 BY GRIZZLY INDUSTRIAL, INC.
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
#BL9291 PRINTED IN TAIWAN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the G0636X and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Grizzly G0636X

  • Page 1 MODEL G0636X 17" ULTIMATE BANDSAW OWNER'S MANUAL COPYRIGHT © MAY, 2007 BY GRIZZLY INDUSTRIAL, INC. WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC. #BL9291 PRINTED IN TAIWAN...
  • Page 2 ���� ������ �������� �������� ������ ������������ �� ��� ������ ������ ���������� ����������� ��� ������� �� ���� ������������������ ������� �� ����� ���������� ��� ������ ��� ������������ ����� �� ���� ������ ��� ������ �� ������� �������� ������� ��������� ����������� ������������� �� ������ ���...
  • Page 3: Table Of Contents

    INTRODUCTION ... 2 Foreword ... 2 Contact Info ... 2 Machine Data Sheet ... 3 Identification ... 5 SECTION 1: SAFETY ... 6 Safety Instructions for Machinery ... 6 Additional Safety Instructions for Bandsaws . 8 SECTION 2: CIRCUIT REQUIREMENTS ... 9 220V Single-Phase ...
  • Page 4: Introduction

    INTRODUCTION Foreword We are proud to offer the Model G0636X 17" Ultimate Bandsaw. This machine is part of a grow- ing Grizzly family of fine woodworking machinery. When used according to the guidelines set forth in this manual, you can expect years of trouble-free, enjoyable operation and proof of Grizzly’s com-...
  • Page 5: Machine Data Sheet

    ������������ � ���������������������������������������������������������������������������������������������������������������������������������������������������� �������� ����������� � ����������������������������������������������������������������������������������������������������������������������������������������������� ������������������ ������� ���������� �������������������������������������������������������������������������������������������������������������������������������������������������������������������� ��� ������������������������������ � ���������������������������������������������������������������������������������������������������������������������������������� �� ����� ����������� ���������������������� � ������������������������������������������������������������������������������������������������������������������������������������� ��������� ���������������������������������������������������������������������������������������������������������������������������������������������������������������� ������������� � ������������������������������������������������������������������������������������������������������������������������������������������������ ������������ G0636X 17" Ultimate Bandsaw ����� ������ ������� ���� ����� ����� ������ � ������ � ������...
  • Page 6 ��������� � �������������������������������������������������������������������������������������������������������������������������������������������������������������������������� ������ ��������������������������������������������������������������������������������������������������������������������������������� ����������������������������� ������������������������������������������������������������������������������������������������������������������������������������������������������������������������������ ��������� ������������������������� ������������������������������������ ���������������������������������������� ������������������������������������������������� ������������������������������������������������������������������ ����������������������� ���������������������������������� ����������������������������������� ��������������������� ������������������������������������ �������������������������������������������������������������������� ��������������� �������������������� ����������������� ����������������� ����� ������ � � � � � � � � G0636X 17" Ultimate Bandsaw ���� � �� �...
  • Page 7: Identification

    Figure 1. G0636X front view. A. Eye Bolt B. Hinged Wheel Covers C. Blade Tracking Window D. Guide Post Handwheel E. Cutting Height Scale Guide Post G. Ball Bearing Blade Guides H. Miter Gauge 4" Dust Port Foot Brake K. Fence Lock Lever Resaw Fence M.
  • Page 8: Section 1: Safety

    �������� ���������������������������������������������� ��� �������� ����� ���� ������ ��� ������� ������� ����� ����������� ����� ��������� ��� �������� ������������������������������������� �� ����� ������� ��������� ���� ����� �� ����� ��� ��������� �� ��������� ����� �� �������� ������������������ ������������������������������������ ��������� ����������� G0636X 17" Ultimate Bandsaw...
  • Page 9 ��� �������� ��������� ���� ������ ����������������������������������������� �������������������������������������������� ������������������������������������� ��� ���� ���� ������ ��� �� ����� ��� ���� ��������� ������ ����� ���������� G0636X 17" Ultimate Bandsaw ��� ������ ��������������������������������������� ����� ���� ���������� ��������� ������� ����� ����������������� ��� ����� ������ ����� ���������������������...
  • Page 10: Additional Safety Instructions For Bandsaws

    Use this and other machinery with caution and respect. Failure to do so could result in serious per- sonal injury, damage to equipment, or poor work results. G0636X 17" Ultimate Bandsaw...
  • Page 11: Section 2: Circuit Requirements

    DO NOT connect the machine to the power source until instructed to do so. Amperage Draw The Model G0636X motor draws the following amps under maximum load: Motor Draw ... 22 Amps Circuit Requirements...
  • Page 12: Section 3: Setup

    • 1000 Lb Capacity Chain or Strap w/Hook .. 1 Unpacking Your Model G0636X was carefully packaged for safe transportation. Remove the packaging mate- rials from around your machine and inspect it. If you discover the machine is damaged, please immediately call Customer Service at (570) 546- 9663 for advice.
  • Page 13: Inventory

    Hex Wrench 5mm & 6mm ...1 Ea • Cap Screw M6-1 x 25 (Handwheel) ... 1 G0636X 17" Ultimate Bandsaw Figure 4. G0636 crate contents. If any nonproprietary parts are missing (e.g. a nut or a washer), we will gladly replace them; or for the sake of expediency, replacements can be obtained at your local hardware store.
  • Page 14: Hardware Recognition Chart

    Hardware Recognition Chart -12- G0636X 17" Ultimate Bandsaw...
  • Page 15: Clean Up

    The unpainted surfaces are coated with a waxy oil to prevent corrosion during shipment. Remove this protective coating with a solvent cleaner or citrus-based degreaser such as Grizzly’s G7895 Citrus Degreaser. To clean thoroughly, some parts must be removed. For optimum performance from your machine, clean all moving parts or sliding contact surfaces.
  • Page 16: Moving & Placing Base Unit

    Lift the bandsaw off of the pallet, remove the pallet, and slowly set the bandsaw into posi- tion. Note: If you are concerned about your forklift forks hitting the tension handwheel, remove the handwheel, then reinstall it after lifting. G0636X 17" Ultimate Bandsaw...
  • Page 17: Mounting To Shop Floor

    (see Figure 10) that has wheel locking or wheel retracting capabilities that keep the mobile base from rolling when the bandsaw is in use. We recommend using the Grizzly Model G7315 mobile base. Bolting to Concrete Floors Lag shield anchors with lag bolts (Figure 9) and anchor studs are two popular methods for anchor- ing an object to a concrete floor.
  • Page 18: Blade Tracking

    Be careful when turning the wheels by hand. Blade Centered on Wheel Figure 13. Center tracking profiles. Quick Tension Lever Blade Centered on Peak of Crown Wheel CENTER TRACKING G0636X 17" Ultimate Bandsaw...
  • Page 19: Positive Stop

    Figure 14. Blade tracking controls. -17- G0636X 17" Ultimate Bandsaw...
  • Page 20: Dust Collection

    -18- Dust Collection DO NOT operate the Model G0636X without an adequate dust collection system. This saw creates substantial amounts of wood dust while operating. Failure to use a dust collection system can result in short and long-term respiratory illness.
  • Page 21: Fence

    Figure 19. Note: Leave the moving plate and lock handle loose enough to slide on the resaw fence. G0636X 17" Ultimate Bandsaw Resaw Lock Handle Screw Figure 19. Attaching resaw fence to standard Tighten the resaw lock handle.
  • Page 22: Test Run

    Always disconnect the machine from power when investigating or correcting potential problems. -20- Figure 20. G0636X switch disabling key and ON/OFF switch. Press the OFF button to stop the machine. WITHOUT resetting the OFF button, press the ON button. The machine should not start.
  • Page 23: Tensioning Blade

    Slowly release the tension one quarter of a turn at a time. When you see the bandsaw blade start to flutter, stop decreasing the ten- sion. G0636X 17" Ultimate Bandsaw Now, slowly increase the tension until the blade stops fluttering, then tighten the tension another quarter turn.
  • Page 24 " behind the Note: 0.004" is approximately the thickness of a dollar bill. Tighten both of the the bearing rotation adjustment bolts to lock the blade guide bear- ings in position. " spacing is ideal, although with NOTICE G0636X 17" Ultimate Bandsaw...
  • Page 25: Adjusting Support Bearings

    Adjustment Rod Cap Figure 26. Lower blade guide controls (rear view). G0636X 17" Ultimate Bandsaw Follow the procedure for adjusting the upper blade guides on Page 21. Note: The lateral adjustment rod cap screw and guide block assembly cap screws are located below the table tilt lock lever (see Figure 26).
  • Page 26 Using a feeler gauge between the support bearing and the blade, position the bearing 0.016" away from the back of the blade, as illustrated in Figure 28. Side View Figure 28. Blade aligned 0.016" away from the bearing edge. -24- Support Bearing G0636X 17" Ultimate Bandsaw...
  • Page 27: Aligning Table

    DISCONNECT BANDSAW FROM POWER! Loosen the four trunnion cap screws that secure the table to the trunnions (Figure 31). G0636X 17" Ultimate Bandsaw Cap Screws Figure 31. Cap screws securing table to trun- nion. Place an accurate straightedge along the blade.
  • Page 28: Aligning Fence

    Adjusting the fence parallel to the miter slot does not guarantee straight cuts. The miter slot may need to be adjusted parallel to the side of the blade. Refer to the "Aligning Table" instructions on Page 25. G0636X 17" Ultimate Bandsaw...
  • Page 29: Pointer Calibration

    Figure 36. Fence pointer adjustment screw. Tighten the pointer adjustment screw. G0636X 17" Ultimate Bandsaw Miter Gauge The miter gauge needs to be calibrated to the blade when it is first mounted in the miter slot.
  • Page 30: Section 4: Operations

    OMMEND that you read books, trade maga- zines, or get formal training before begin- ning any projects. Regardless of the con- tent in this section, Grizzly Industrial will not be held liable for accidents caused by lack of training. -28-...
  • Page 31: Foot Brake

    The Model G0636X is equipped with a foot brake (Figure 38). Use the brake only in emergency situations to stop power from going to the motor and bring the blade to a halt. The foot brake will not stop the bandsaw wheels and blade instantly.
  • Page 32: Fine Tune Tracking

    To skew your fence: Cut a piece of scrap wood approximately thick x 3" wide x 17" long. On a wide face of the board, draw a straight line parallel to the long edge. G0636X 17" Ultimate Bandsaw ⁄ "...
  • Page 33: Table Tilt

    (Figure 31). Shift the table to compen- sate for the blade lead, then retighten the cap screws. Repeat Steps 1–4 until the blade cuts straight. G0636X 17" Ultimate Bandsaw Table Tilt Personal injury or death can occur if the bandsaw starts during table adjust- ment.
  • Page 34: Ripping

    ON. Slowly feed the workpiece into the blade and continue the cut until the blade is all the way through the workpiece. Figure 44 shows a typical cross- cutting operation. Figure 44. Example of crosscutting operation with miter gauge. G0636X 17" Ultimate Bandsaw...
  • Page 35: Resawing

    (see Figure 45). G0636X 17" Ultimate Bandsaw Figure 45. Example of resawing lumber. Cutting Curves When cutting curves, simultaneously feed and turn the stock carefully so that the blade follows the layout line without twisting.
  • Page 36: Stacked Cuts

    Measured by the circumference, blade lengths are usually unique to the brand of your bandsaw and the distance between wheels. The Model G0636X is designed for blades that are 160" long. Refer to Page 37 for blade replacements. Blade Width...
  • Page 37: Blade Breakage

    However, these blades also leave a rougher cut than raker blades. G0636X 17" Ultimate Bandsaw Hook: The teeth on this style have a posi- • tive angle (downward) which makes them dig into the material, and the gullets are usu- ally rounded for easier waste removal.
  • Page 38: Blade Changes

    Adjust tension as described on Page 21. Adjust tracking if needed (see Page 16). Adjust the upper/lower guide bearings and the support bearings (see Page 21). Replace the table insert and table pin. Close the wheel covers. G0636X 17" Ultimate Bandsaw...
  • Page 39: Section 5: Accessories

    1" H8430 ⁄ " G1094—Bandsaw Power Feeder with Fence, Single-Phase Figure 50. G1094 Bandsaw Power Feeder. G0636X 17" Ultimate Bandsaw 162" Carbon Steel Replacement Blades for the Model G0636X. 6 HOOK 10 RAKER 4 HOOK 6 HOOK 162" Timber Wolf 3 HOOK Model G0636X.
  • Page 40 1 Qt. Gel ® 12 oz Spray ® T-9 12 oz Spray ® T-9 4 oz Spray ® Gun Treatment 12 oz Spray Gun Treatment 4.5 oz Spray G0636X 17" Ultimate Bandsaw...
  • Page 41: Section 6: Maintenance

    Clean/vacuum dust buildup from inside cabi- net and off motor. Cleaning Cleaning the Model G0636X is relatively easy. Vacuum excess wood chips and sawdust, and wipe off the remaining dust with a dry cloth. If any resin has built up, use a resin dissolving cleaner to remove it.
  • Page 42 Apply a thin coat of grease to the tension adjustment assembly and tension lever cam (Figure 58). Figure 58. Tension adjustment assembly locations (top wheel removed for clarity). G0636X 17" Ultimate Bandsaw...
  • Page 43 Move the table up and down several times to distribute the grease, then wipe off any excess grease. G0636X 17" Ultimate Bandsaw To lubricate the trunnions: DISCONNECT BANDSAW FROM POWER! Move the table up until it reaches its maximum 45˚...
  • Page 44: Section 7: Service

    7. Test for good contacts and correct wiring. 8. Correct motor wiring connections (Page 50). 9. Test by rotating shaft; rotational grinding/loose shaft requires bearing replacement. 10. Let motor cool, clean it off, and reduce workload. 11. Repair/replace. G0636X 17" Ultimate Bandsaw...
  • Page 45: Cutting Operations

    Blade wanders or 1. Blade lead. won't follow line of cut. G0636X 17" Ultimate Bandsaw Possible Solution 1. Replace blade (Page 36). 2. Replace blade (Page 36). 3. Inspect/replace stripped or damaged bolts/nuts, and re-tighten with thread locking fluid.
  • Page 46: Checking And Tensioning V-Belts

    If the deflection is more than When the V-belt tension is correct, tighten the motor adjustment bolts, and close the wheel covers. ���������� Tension Bolt Motor Adjustment Bolts ⁄ " with moderate pressure, ⁄ ", repeat Step 4. G0636X 17" Ultimate Bandsaw...
  • Page 47: Replacing V-Belts

    V-belt set in their place. Install the lower wheel back onto the bearing shaft, tighten the wheel mount cap screw, and tension the V-belt (see Page 44). Close the lower wheel cover. G0636X 17" Ultimate Bandsaw -45-...
  • Page 48: Adjusting Wheel And Blade Brushes

    Reinstall the blade (Page 36), making sure the guide bearings and support bearings are away from the blade, then tighten your blade to the tension that it will be used during operation. G0636X 17" Ultimate Bandsaw open both wheel cov-...
  • Page 49 Figure 67. ������ ��� ��� ��� ������ ��� ��������� Figure 66. Dimensions of coplanarity gauge. G0636X 17" Ultimate Bandsaw Coplanarity Gauge Positions Gauge Tracking Knob Wheels Adjustment Figure 67. Checking for coplanarity. Adjust the tracking knob to get both wheels parallel.
  • Page 50 This will be more noticeable with larger blades. Parallel, Not Not Parallel Coplanar Not Coplanar Shim Upper Wheel Out Lower Figure 69. Coplanarity diagram. Adjust Tracking Knob Adjust G0636X 17" Ultimate Bandsaw...
  • Page 51: Electrical Components

    Electrical Components Figure 70. Power supply terminal box. Figure 73. Motor wiring. POWER Figure 71. Control panel wiring. Figure 72. Wheel cover limit switch (left) and Figure 74. Magnetic switch. foot brake switch (right). -49- G0636X 17" Ultimate Bandsaw...
  • Page 52: Wiring Diagram

    ������ ������ � � ��� ��� ��� � ����� ���� ��� ��� ������������ (See Figure 72) ������ ������ ���� � � � � � � � � � � � � �� ���������� (See Figure 72) G0636X 17" Ultimate Bandsaw...
  • Page 53: Main Parts Breakdown

    Main Parts Breakdown -51- G0636X 17" Ultimate Bandsaw...
  • Page 54: Fence/Guides Parts Breakdown

    Fence/Guides Parts Breakdown -52- G0636X 17" Ultimate Bandsaw...
  • Page 55: Parts List

    STOP SWITCH P0636X050 KEY SWITCH P0636X051 SWITCH PLATE P0636X052 CONNECTING CORD P0636X053 CONNECTING CORD P0636X054 SWITCH CORD G0636X 17" Ultimate Bandsaw Parts List REF PART # DESCRIPTION P0636X055 ADJUST BOLT PB73M HEX BOLT M10-1.5 X 50 PN02M HEX NUT M10-1.5 PW04M...
  • Page 56 UPPER GUIDE SUPPORT BLOCK PB04M HEX BOLT M6-1 X 10 P0636X186 UPPER GUIDE BAR PN04M HEX NUT M4-.7 PS38M PHLP HD SCR M4-.7 X 10 PSB01M CAP SCREW M6-1 X 16 P0636X190 HANDLE 3/8-16 X 1/2 G0636X 17" Ultimate Bandsaw...
  • Page 57 LOCK WASHER 6MM PW03M FLAT WASHER 6MM P0636X222 SUPPORT PLATE PW03M FLAT WASHER 6MM P0636X224 PROTECT COVER (ASM) G0636X 17" Ultimate Bandsaw REF PART # DESCRIPTION P0636X225 SLIDING PLATE P0636X226 FIBER WASHER 13MM P0636X227 STEP SCREW PSB04M CAP SCREW M6-1 X 10...
  • Page 58: Labels/Cosmetic Parts

    MUST maintain the original location and readability of the labels on the machine. If any label is removed or becomes unreadable, REPLACE that label before using the machine again. Contact Grizzly at (800) 523-4777 or www.grizzly.com to order new labels. -56-...
  • Page 59: Warranty And Returns

    WARRANTY AND RETURNS Grizzly Industrial, Inc. warrants every product it sells for a period of 1 year to the original purchaser from the date of purchase. This warranty does not apply to defects due directly or indirectly to misuse, abuse, negligence, accidents, repairs or alterations or lack of maintenance.
  • Page 60 -58- G0636X 17" Ultimate Bandsaw...
  • Page 61 ���������������������������������������������������������������������������������� � ������������������������������������������������������������������������������������ ����� ����������������������� ������ � ������������������������ ���� ��������������������� ���������������������������� ������ ������������������������ ���������� � ���������������� ���������������������������� ������������������������������� ��������������������������� ��� ��������� ����������� �� ����� �� � ��������� ������ �� ���� �� ���� ��� ��������� �������� �� ���� �� ������� ������ �������� ��� ��������� �� ������� ��� ����������� �� �������� ������������� ���...
  • Page 62 ���������������������� ���������������������� ����������������������������������� ����������������������������������� ������������������������������������� �������������������������������������� ������� ����������� ���� ���� ��� ���� ����������� �� ���������� �������������������������������������� ����� ����� ����...
  • Page 64 ��� ������ ��� ���� ���� ������� ����� ��� ������� ����� ��� �������� ��� ������� � � � ���� ����� ��� � � �������� ������ ��� � ����� ������ � �� ��� �������� ������� � ������ �������� ������ ������� ������ �� ����� ������...
