User Instructions
9/06
American DJ
®
4295 Charter Street
Los Angeles, CA. 90058
www.americandj.com
LED Matrix
Introduction: Thank you for purchasing the LED Matrix by Ameri-
can DJ®. The LED Matrix is a sound active, stand alone unit. You
can also connect the LED Matrix to a DMX controller and select
one of the many programs and control the speed of the program.
This system is great for displays, mood, architectural, interior
decoration, and clubs.
Customer Support: American DJ® provides a toll free customer
support line, to provide set up help and to answer any question
should you encounter problems during your set up or initial oper-
ation. You may also visit us on the web at www.americandj.com
for any comments or suggestions. For service related issue
please contact American DJ®. Service Hours are Monday
through Friday 9:00 a.m. to 5:00 p.m. Pacific Standard Time.
Voice:
(800) 322-6337
Fax:
(323) 582-2610
E-mail:
support@americandj.com
To purchase parts online visit http://parts.americandj.com
Warning! To prevent or reduce the risk of electrical shock or fire,
do not expose this unit to rain or moisture.
Caution! There are no user serviceable parts inside this unit. Do
not attempt any repairs yourself, doing so will void your manu-
factures warranty. In the unlikely event your unit may require
service please contact American DJ®.
PLEASE do not discard the shipping carton in the trash.
Please recycle when ever possible.
American DJ
- www.americandj.com - LED Matrix Instruction Manual Page 2
©
®
