Thank you for purchasing this American DJ® product. Some setup required.
Please read the following instructions before installing or using your new unit.
HALOGEN LAMP WARNING!
This fixture is fitted with a halogen lamp
which is highly susceptible to damage if
improperly handled. Never touch lamp
with bare fingers as the oil from your
hands will shorten lamp life. Also, never
move fixture until lamp has had ample
time to cool. Remember, lamps are not
covered under warranty conditions.
THE MAX™ Feature s
•20 Dichroic Colors + White / Split colors
•21 Gobos plus Spot on separate wheel
•360 degree rotation of Yoke and Base
•High speed Shutter
•Strobes in every Color
•16 flashes per second
•Variable Speeds
•Pan 120 rpm (20,000 steps)
•Tilt 60 rpm (38,400 steps)
•DMX-512 Protocol
User
®
™
1
1: MIC SENSITIVITY ADJUSTMENT
2: MICROPHONE
3: DMX / MASTER SLAVE SETTINGS
4: DMX INPUT / OUTPUT
5: POWER SWITCH
6: FUSE HOLDER Dual 6.3A
7: POWER CONNECTION
THE MAX™ Specifications
Voltage: 120V 50/60 Hz
Dimensions: 12" x 7" x 7"
Lamp: ZB-ELC 250W 24V
Weight: 22 lbs.
Fuse: Dual 6.3A
The MAX™ User Instructions page 1
Instructions

Control Panel

2 3
4 5 7
6
