Specifications

Cable specifications

SFP+
module type
10GBASE-SR
(short range)
Optical
Module
10GBASE-CR
with Direct
Attached
Copper
(DAC) cable

Supported cables for HPN5900

The following cables can connect the adapter to an HPN5900:
HP X240 10G SFP+ to SFP+ 0.65m DAC cable JD095C
HP X240 10G SFP+ to SFP+ 1.2m DAC cable JD096C
HP X240 10G SFP+ to SFP+ 3m DAC cable JD097C
HP X240 10G SFP+ to SFP+ 5m DAC cable JG081C
HP X240 QSFP+ 4x10G SFP+ 1m DAC cable JG329A
HP X240 QSFP+ 4x10G SFP+ 3m DAC Cable JG330A

Supported cables for HPN6600

The following cables can connect the adapter to an HPN6600:
HP X242 10G SFP+ to SFP+ 1m DAC cable J9281B
HP X242 10G SFP+ to SFP+ 15m DAC cable J9287B
For more information about product features, specifications, options, configurations, and compatibility, see
the product QuickSpecs on the HP Product Bulletin website (http://www.hp.com/go/productbulletin).
Cable
Wavelength
Connector
(nm), type of
Type
cable
LC
850,
Multi-Mode
Fiber (MMF)
SFP+
N/A, Twin
Axial Copper
Core Size
Cable grade Minimum
(microns,
µm)
62.5
("FDDI")
62.5
OM1
50
50
OM2
OM3
50
24 to 28
N/A
AWG,
depending on
length and
manufacturer
Maximum
modal
Cable Length
bandwidth
(meters)
(MHz-km)
160
26
200
33
400
66
500
82
2000
300
N/A
5
Specifications 10
