Mitsubishi Electric City Multi PUMY-P48NHMU Datasheet

Job Name:
Drawing Reference:
System No.:
O UTDOOR VRF
S ST Y EM F ATUR S E E
• Single-phase outdoor unit
with variable refrigerant
technology
• Inverter-driven (variable
speed) compressor
• Total refrigerant piping
length of 394' (120 m)
• Uses CITY MULTI indoor
units and Controls Network
OUTDOOR VRF SYSTEM SPECIFICATIONS
Capacity
Cooling.....................................................48,000 Btu/h
Heating.....................................................54,000 Btu/h
Power
Power Source...........................208 / 230V, 1-phase, 60Hz
Power Input
Cooling......................................................4.97 kW
Heating......................................................4.88 kW
Current
Cooling (208 / 230)........................................24.0 / 21.7 A
Heating (208 / 230) ......................................23.6 / 21.3 A
Minimum Circuit Ampacity (MCA) (208 / 230)...............26 A
Breaker Size for Wiring ..................................................30 A
External Finish
.........Pre-coated Galvanized-steel Sheets
External Dimensions
Inches....................53-3/16 h x 37-7/16 w x 13 (+1-3/16) d
mm...................................1,350 h x 950 w x 330 (+30) d
Net Weight
........................................287 lbs. / 130 kg
Notes:
PUMY-P48NHMU
Model:
Munsell No. 3Y 7.8 / 1.1
Schedule No.
Fan
Type x Quantity..........................................Propeller Fan x 2
Airflow Rate....................................................3,530 cfm
Motor Output..........................................0.086 + 0.086 kW
Compressor
Type..................................................Inverter-driven Scroll
Motor Output......................................................2.4 kW
Lubricant
.........................................................FV50S
Refrigerant
.......................................................R410A
Protection Devices
High Pressure Protection..................High Pressure Switch
Compressor............Discharge Thermo / Overcurrent Detection
Fan......................................Overheat / Voltage Protection
Piping Diameter
Liquid (High Pressure)..........................3/8" / 9.52 mm Flare
Gas (Low Pressure)...........................5/8" / 15.88 mm Flare
Indoor Unit
Total Capacity............50% –130% of Outdoor Unit Capacity
Model / Quantity.........................................P06-P54 / 1 ~ 8
Sound Level (Cooling / Heating)
Operating Temperature Range
Cooling (Outdoor)...................23°F ~ 115°F (-5 ° ~ +46°C) DB*
Heating (Outdoor)................0°F ~ +60°F (-18 ° ~ +15°C) WB
Anti-corrosion Protection
Blue Fin Treatment applied to condenser coil protects coil
from airborne contaminants.
Options
□ Branch Joint (T-Branch)..............................CMY-Y62-G-E
□ Header - Four-Branch..................................CMY-Y64-G-E
□ Header - Eight-Branch...................................CMY-Y68-G-E
□ Drain Pan................................................PAC-SG64DP-E
□ Drain Socket............................................PAC-SG61DS-E
.............50 / 52 dB(A)
