- Page 1 User Manual User Manual Electric Countertop Fryers Models: F120, F122 11/2010 Please read and keep these instructions. Indoor use only. www.AvantcoEquipment.com...
- Page 2 User Manual WARNINGS This equipment must be operated by trained cooks or professionals. • Do not touch any hot surfaces. • Do not immerse unit, cord or plug in liquid at any time. • Unplug cord from outlet when not in use and before cleaning. •...
- Page 3 User Manual Thank you for purchasing and using Avantco's Electric Fryer. Please read this manual thoroughly before using to understand proper use and function. Safety warnings, cleaning suggestions and electrical recommendations are given to reduce the risk of damage or injury.
-
Page 4: Circuit Diagram
User Manual Basic Information of F Series Fryers Name Deep Fryer Single 6 Liter Deep Fryer Double 6 Liter (x2) Model F120 F122 Voltage 120V 50/60Hz 120V 50/60Hz Power 1750W 2 x 1750W Number of oil tanks Size of oil tanks 9 1/2"... -
Page 5: Cleaning And Maintenance
User Manual Instructions for Fryer Usage 1. Please make sure the power supply you are using is adequate for continual fryer use and voltage is adequate. The use of a surge protector or circuit breaker is advisable. 2. Fill oil receptacle with vegetable oil to between the minimum and maximum levels, allowing for food volume. 3. -
Page 6: Troubleshooting
User Manual Troubleshooting Problem Causes Solution Indicator light will not turn on and Plug not properly in- Reinsert plug. unit will not heat. serted. Micro-switch not closed. Adjust the limit distance of mircro-switch. Heating indicator is not on, the Electric heater tubes is Tighten both sides of electric heater. -
Page 7: Parts Diagrams
I. Parts diagrams Parts Diagrams I. Parts diagrams DF series 1-tank electric fryer DF series 1-tank electric fryer F120 1-Tank Electric Fryer DF series 2-tank electric fryer F122 2-Tank Electric Fryer DF series 2-tank electric fryer 1 Power indicator (Green ) 12. - Page 8 User Manual F120 Part List NO NAME SPECIFICATION AMOUNT NOTE Power indicator 12 250V Green, Merchant LH-580-N or Arcoelectric 0589 Heating indicator 12 250V Yellow, Merchant LH-580-N or Arcoelectric 0589 Fix screw for back board M4×8 Pan Head Rear cover Stainless S=0.8...
-
Page 9: Specification
User Manual F122 Part List NO NAME SPECIFICATION AMOUNT NOTE Power indicator 12 250V Green, Merchant LH-580-N or Arco- electric 0589 Heating indicator 12 250V Yellow, Merchant LH-580-N or Arco- electric 0589 Fix screw for back board M4×8 Pan Head Rear cover Stainless S=0.8 Electric circuit enclosure...
