Page 1: User Manual
Active Speaker System LX523 AUDAC PROFESSIONAL AUDIO EQUIPMENT Active Speaker System with remote input LX523 User Manual & Installation Guide... - Page 2 A U D A C P R O F E S S I O N A L A U D I O E Q U I P M E N T User Manual & Installation Guide AUDAC http://www.audac.be info@audac.be...
- Page 3 This section briefly describes the possibilities of the LX523 Active Speaker System with remote input. he LX523 is a speaker set consisting of one active and one passive speaker, to be linked be linked together. What makes the LX523 special and superior to traditional active...
-
Page 4: Safety Requirements
Safety Requirements Always handle the unit with care. This unit is not a toy. It should not be operated by children. Ensure that sufficient space is available behind the active speaker for cooling. Do not open the unit (risk of electrical shock). Always read the user manual before getting started. - Page 5 Overview rear panel of the LX523 1: Speaker Output 2: On / Off Switch 3: Power Supply socket 4: Heatsink 5: Volume Control 6: Treble Control 7: Bass Control 8: RJ45 Remote Input...
- Page 6 4: Heat sink: When using the LX523 at full power for a long time, this heat sink will warm-up. Make sure there’s always some space behind the speaker ensuring a proper airflow. Take care when placing the speaker close to other items sensitive to heat.
- Page 7 Remote input connection specifications The connections between the LX523 speaker system and the used input unit (WP523 or RM523) should be always made by means of twisted pair cabling. The maximum cable distance between the input unit and the speaker system depends of the used cable. For standard CAT5 cable, the maximum cable distance between the input unit and the speaker system can reach up to 500 meter.
- Page 8 MIC IN AUDAC The WP523 wall panel should be connected to the LX523 speaker system by means of the 8-pin Euro-Terminal block connector on the rear side of the wall panel. The pins starting from Pin 1 on the left side, to Pin 8 on the right side should be connected with the corresponding conductors of...
- Page 9 Connecting multiple LX523 sets to one input unit. The mains for powering the input units (WP523) is distributed from the LX523 speaker over Pin 3 and Pin 4 (White-Green & Blue conductor) of the twisted pair cabling. When connecting multiple speaker sets to one single input unit, make sure the mains from only one speaker set is distributed to the input unit.
-
Page 10: Features And Specifications
IEC power connector Input RJ45 remote input connection Speaker output Two pin EURO terminal block Fuse 1A Slow Colours Black LX523/B White LX523/W Dimensions (W x H x D) 178x240x193mm Packaging Carton Box Weight net. (2 Speakers) 5.4 Kg Shipping Weight/Volume... -
Page 11: Personal Notes
Personal Notes...
