Page 1: Installation Guide
Sound Projector SP20 AUDAC PROFESSIONAL AUDIO EQUIPMENT Sound Projector SP20 Installation Guide... -
Page 2: Installation Procedure
Introduction The AUDAC SP20 is an unidirectional and humidity proof sound projector with a high efficiency. It is suitable for speech and music and ensures a powerful and high quality sound reproduction. It features a 5” full range speaker and a built-in 100 Volt line transformer with four different power taps, to be used in large 100V PA applications. - Page 3 Connections To avoid electric shocks during installation, always switch of the amplifier power when connecting loudspeakers. A 5 core connection cable is provided on the rear side of the loudspeaker. By connecting the appropriate cable cores, the desires power taps for the loudspeaker can be selected, to be used in 100V public address applications.
-
Page 4: Technical Specifications
Technical Specifications Projector way Unidirectional Max Power 40 Watt RMS Power 20 Watt Line Transformer Power taps 20 Watt 500 Ohm 10 Watt 1000 Ohm 5 Watt 2000 Ohm 2.5 Watt 4000 Ohm Line Voltage 100 V Driver impedance 8 Ohm Sensitivity 1W / 1m 92 ±...
