- Page 1 TOUCH TERMINALS GN Series Hardware Manual...
-
Page 2: Limited Warranty
This manual and everything described in it are copyrighted. You may not copy this manual, in whole or part, without written consent of Panasonic Electric Works Europe AG (PEWEU). PEWEU pursues a policy of continuous improvement of the design and performance of its products. - Page 3 Important Symbols One or more of the following symbols may be used in this documentation: DANGER! The warning triangle indicates especially important safety instructions. If they are not adhered to, the results could be fatal or critical injury. CAUTION Indicates that you should proceed with caution. Failure to do so may result in injury or significant damage to instruments or their contents, e.g.
-
Page 4: Table Of Contents
Table of Contents GN Series Hardware Manual Table of Contents Introduction ................1 Safety Instructions ..................2 Overview....................4 Electrostatic Discharge (ESD) ..............5 1.3.1 Grounding Methods..................5 FCC Statement ..................6 Electromagnetic Compatibility ..............7 Applicable Directives and Standards ............8 Scope of Delivery .............. - Page 5 Table of Contents GN Series Hardware Manual Bottom View .....................23 3.3.1 Optional Interfaces ...................23 3.3.1.1 RS422/RS485 Serial Interface ............23 3.3.2 DC Power Connector ................25 3.3.3 LAN0 and LAN1 Ethernet Interface Connectors ........25 3.3.4 VGA Interface Connector .................25 3.3.5 Reset Button.....................26 3.3.6...
- Page 6 GN Series Hardware Manual Table of Contents 4.4.1 Ethernet Interfaces (LAN0 and LAN1) ............. 52 4.4.2 USB Interfaces ..................52 4.4.3 RS232 (COM1, COM2) ................52 4.4.4 RS422/RS485 Configured as RS422 (4-Channel Mode) ......53 4.4.5 RS422/RS485 Configured as RS485 (4-Wire Mode), Full Duplex, Bus Master ......................
-
Page 8: Introduction
Chapter 1 Introduction... -
Page 9: Safety Instructions
Introduction GN Series Hardware Manual 1.1 Safety Instructions WARNING To ensure safe operation, observe these safety instructions. • Always take precautions to ensure the overall safety of your system so that the whole system remains safe in the event of failure of this product or other external factor. - Page 10 GN Series Hardware Manual 1.1 Safety Instructions the current consumption of the system does not exceed the value stated on the product label. • Switch off and ensure that the device cannot be operated if the following apply because safe operation may no longer be possible:...
-
Page 11: Overview
The GN is designed to be connected to a +24V DC power supply using the DC power plug (included). NOTE The GN series touch panels are designed to fulfill the IP65 degree of protection for the front side. However, the USB connector on the front (if present) must be covered by the elastic captive rubber coat. -
Page 12: Electrostatic Discharge (Esd)
GN Series Hardware Manual 1.3 Electrostatic Discharge (ESD) 1.3 Electrostatic Discharge (ESD) A sudden discharge of electrostatic electricity can destroy static-sensitive devices or micro-circuitry. Proper packaging and grounding techniques are necessary prerequisites for avoiding damage. Always take the following precautions: •... -
Page 13: Fcc Statement
Introduction GN Series Hardware Manual 1.4 FCC Statement This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in commercial environment. -
Page 14: Electromagnetic Compatibility
GN Series Hardware Manual 1.5 Electromagnetic Compatibility 1.5 Electromagnetic Compatibility This product has been designed for industrial use. The most recent version of the EMC guidelines (EMC Directive 2004/108/EC) and national laws apply. If the user modifies and/or adds to the equipment (e.g. installation of add-on cards), the prerequisites for the CE conformity... -
Page 15: Applicable Directives And Standards
Introduction GN Series Hardware Manual 1.6 Applicable Directives and Standards Applicable directives for the CE mark Low Voltage Directive (Electrical Safety) 2006/95/EC EMC Directive 2004/108/EC Electrical safety Standards EUROPE EN 60950-1: 2006 USA / Canada UL 60950-1: 2006 cULus Listed... -
Page 16: Scope Of Delivery
Chapter 2 Scope of Delivery... -
Page 17: Product Parts
Scope of Delivery GN Series Hardware Manual 2.1 Product Parts The system comes with the following parts: Item Description GN system in the configuration ordered: • GN07 • GN10 • GN12 • GN15 Phoenix power plug Stylus (touch pen) 4 x mounting clamp with Allen screws for the GN07... -
Page 18: Type Label And Product Identification
GN Series Hardware Manual 2.2 Type Label and Product Identification 2.2 Type Label and Product Identification Product name Product identification AIGN07xxxx GN07 (system with a 7" display) AIGN10xxxx GN10 (system with a 10.4" display) AIGN12xxxx GN12 (system with a 12.1" display) AIGN15xxxx GN15 (system with a 15"... -
Page 20: Product Description
Chapter 3 Product Description... -
Page 21: All Views
Product Description GN Series Hardware Manual 3.1 All Views The pictures show a GN10. Bottom view Right view Front view Left view Top view... - Page 22 GN Series Hardware Manual 3.1 All Views Rear view...
-
Page 23: Front View
3.2.1 USB Interface on the Front NOTE • The GN series touch panels are designed to fulfill the IP65 degree of protection for the front side. However, the USB connector on the front (if present) must be covered by the elastic captive rubber coat. -
Page 24: Front Plates
45.7 3.2.3 Display with Touch Screen GN series touch panels include a TFT display (see page 44) with corresponding resistive touch screen (glass-glass technology). A stylus is supplied for touch screen operation. The surface of the display is also mechanically protected by the touch screen. The touch screen (USB connected) registers contacts of a finger or a pen and allows you to move the mouse pointer. -
Page 25: Calibration Under Windows® Xp
Product Description GN Series Hardware Manual screen may not be aligned with the screen's image or may be unnecessarily small in size. If you need to access the calibration routine, use a USB mouse. The touch screen of your GN system is factory calibrated. Run the calibration routine when an alignment problem exists between the mouse pointer and the stylus contact location on the screen. - Page 26 GN Series Hardware Manual 3.2 Front View 2. Select the "Calibration" tab 3. Select [Configure] to set up calibration 4. Select the number of calibration points and offset 5. Select [OK]...
- Page 27 Product Description GN Series Hardware Manual 6. Select [Test] 7. When prompted, touch the panel at the location indicated 8. Select [Accept] REFERENCE For more information about touch screen calibration, see the Hampshire® TSHARC™ UniWinDriver™ Users Manual for Windows® XP on...
-
Page 28: Calibration Under Windows® Xp Embedded
GN Series Hardware Manual 3.2 Front View 3.2.4.2 Calibration under Windows® XP Embedded To calibrate the system under Windows® XP Embedded, please proceed as follows: Procedure 1. Double-click the icon "hwincal.exe" on the desktop This starts the calibration program C:\Program Files\tsharc\hwincal.exe. -
Page 29: Touch Screen Care And Cleaning
Product Description GN Series Hardware Manual 2. Touch the center of each target as accurately as possible REFERENCE For more information about touch screen calibration, see the Hampshire® TSHARC™ UniWinDriver™ Users Manual for Windows® XP on www.hampshirecompany.com (http://www.hampshirecompany.com). 3.2.5 Touch Screen Care and Cleaning For cleaning we recommend a mild detergent and water. -
Page 30: Bottom View
GN Series Hardware Manual 3.3 Bottom View 3.3 Bottom View Bottom view of the GN10/GN12/GN15 Status LED, storage medium Status LED, system Optional interfaces* COM1 (RS232) DC power connector Grounding screw 24V DC N.C. COM 1 LAN 0 LAN 1... - Page 31 Product Description GN Series Hardware Manual RS485 mode communication can be either in full-duplex or half-duplex mode. While running in RS485 half duplex mode, the system stays in receiver mode. Switching to transmission mode occurs automatically and is triggered by the RTS line or the last sent message using the TxD line, which the user defines.
-
Page 32: Dc Power Connector
GN Series Hardware Manual 3.3 Bottom View Timeout Min. baud rate SW1 settings DIP5 DIP6 DIP7 DIP8 3.7ms 3.1ms 2.5ms 4800 1.9ms 1.2ms 9600 0.6ms 19200 3.3.2 DC Power Connector DC power connector Plug in the DC power plug (see page 33) to the DC power connector to supply power to the GN unit. -
Page 33: Reset Button
Product Description GN Series Hardware Manual 3.3.5 Reset Button To restart the GN unit e.g. after a system hang-up, press the reset button with a pen, for example. The system restarts automatically; you do not have to switch the computer off and NOTE During a reset, all data in the main memory is erased. -
Page 34: Top View
GN Series Hardware Manual 3.4 Top View 3.4 Top View Mounting clamp Mounting clamp with Allen screw with Allen screw CF card slot CF card eject button Top of the GN10/12/15 Mounting clamp Mounting clamp with Allen screw with Allen screw... -
Page 35: Left And Right Side View
Product Description GN Series Hardware Manual 3.5 Left and Right Side View Right side of a GN10 Left side of a GN10... - Page 36 GN Series Hardware Manual 3.5 Left and Right Side View Right side of a GN07 Left side of a GN07 Front panel of the system with seal on the rear Enclosure of the display System cover Type label Screws that secure the cover on the left and right side Mounting slots with installed mounting clamp and Allen screw "Safe-keeping"...
-
Page 37: Rear View
Product Description GN Series Hardware Manual 3.6 Rear View Rear of the GN10... - Page 38 GN Series Hardware Manual 3.6 Rear View Rear of the GN07 Front panel of the system with seal at the rear side Type label Mounting clamp and Allen screw for mounting to a subframe System cover Cover for the CF card slot ("safe keeping" location, if a CF card is inserted)
-
Page 39: Single-Board Computer
Product Description GN Series Hardware Manual 3.7 Single-Board Computer The GN unit is equipped with a single-board computer based on Intel® Atom™ Processor. -
Page 40: Connecting The System To The Power Supply
GN Series Hardware Manual 3.8 Connecting the System to the Power Supply 3.8 Connecting the System to the Power Supply CAUTION • Attach the power cable last! • Before using your system, you should first become familiar with the system components and check that everything is connected properly. -
Page 41: Connecting To The Dc Power Supply
Product Description GN Series Hardware Manual 4. Lift the cover, for example with a screwdriver, to access the terminal screws 5. Turn the terminal screws counter-clockwise to loosen 6. Insert the wires into the corresponding terminals Make sure that the polarity is correct! 7. - Page 42 GN Series Hardware Manual 3.8 Connecting the System to the Power Supply • The unit is only completely disconnected from the DC main power supply when the DC power cord is disconnected either from the power supply or the unit. Therefore, the DC power cord and its connectors must always remain easily accessible.
-
Page 43: Mounting The System To A Subframe Or Panel
Product Description GN Series Hardware Manual 3.9 Mounting the System to a Subframe or Panel The system is delivered with mounting clamps and Allen screws in order to mount the system to a subframe or panel. Mounting a GN10 Example of subframe for system installation Enclosure of the 10.4"... - Page 44 GN Series Hardware Manual 3.9 Mounting the System to a Subframe or Panel The mounting clamps enable easy, fast mounting of the GN unit onto an instrument panel or wall panel. Item GN07 GN10 GN12 GN15 Rear side enclosure 215 x 146.3 x 45.75 295 x 234 x 44 324 x 263 x 49.5...
- Page 45 Product Description GN Series Hardware Manual 5. Fasten the system from the rear using the mounting clamps 6. Hook the mounting clamps with screws from the rear side of the panel into the corresponding pairs of slots of the enclosure 6.5mm...
-
Page 46: Accessing Internal Components
GN Series Hardware Manual 3.10 Accessing Internal Components 3.10 Accessing Internal Components WARNING Before removing the cover of the GN unit in order to gain access to the internal components, the system must be powered down and the power cord has to be disconnected from the power supply. - Page 47 Product Description GN Series Hardware Manual and damage. 4. GN07: Unscrew the screws that secure the cover GN10/12/15: Unscrew the screws that secure the metal cover on the optional interface area 5. Remove the cover and put it aside 6. Locate the DIP switches in the unit 7.
-
Page 48: Replacing The Lithium Battery
GN Series Hardware Manual 3.10 Accessing Internal Components 3.10.2 Replacing the Lithium Battery The motherboard is equipped with a lithium battery. Location of the lithium battery Lithium battery Motherboard WARNING There is a risk of explosion if the battery is replaced by an incorrect type. - Page 49 Product Description GN Series Hardware Manual 6. Pull the battery outwards 7. Position the new lithium battery in the battery holder with the positive (+) pole facing up 8. Gently push the battery as far as it goes into the holder Make sure that you insert the battery correctly.
-
Page 50: Technical Data
Chapter 4 Technical Data... -
Page 51: General Specifications
Technical Data GN Series Hardware Manual 4.1 General Specifications GN series GN07 GN10 GN12 GN15 TFT LCD Screen size 7" 10.4" 12.1" 15" Display Active area (H x V) 152.4 x 91.44 211.2 x 158.4 304.1 x 228.1 246.0 x 184.5... - Page 52 GN Series Hardware Manual 4.1 General Specifications GN series GN07 GN10 GN12 GN15 DC power plug (3 pin) Mounting clamps 4 x (1 screw) 8 x (1 screw) 6 x (2 screws) 8 x (2 screws) NOTE The DC power supply must be able to output 50W to cope with the inrush...
-
Page 53: Environmental Specifications
Technical Data GN Series Hardware Manual 4.2 Environmental Specifications Item Specification Thermal management Passive cooling for CPU and system Operating temperature / relative humidity 0 … +45°C, 20 – 90% (non-condensing) Storage / transit temperature / relative -20 … +70°C, 10 – 90% (non-condensing) -
Page 54: Dimensions
GN Series Hardware Manual 4.3 Dimensions 4.3 Dimensions Dimension GN07 GN10 GN12 GN15 Height 168mm 277mm 312mm 354mm Width 235mm 348mm 380mm 449.4mm Depth (total) 50.3mm 49.6mm 57.1mm 55.6mm Depth (without front plate) 47.3mm 45.6mm 51.1mm 51.6mm Weight 2.6kg 3.6kg 4.9kg... - Page 55 Technical Data GN Series Hardware Manual GN10 214.2 GN12...
-
Page 56: Rear And Right Side Views
GN Series Hardware Manual 4.3 Dimensions GN15 449.4 4.3.2 Rear and Right Side Views GN07 45.7... - Page 57 Technical Data GN Series Hardware Manual GN10 17.2 GN12 49.5 22.8...
- Page 58 GN Series Hardware Manual 4.3 Dimensions GN15 23.2 77.2 406.4...
-
Page 59: Pin Assignments
Technical Data GN Series Hardware Manual 4.4 Pin Assignments In this section you can find the pin assignments for the standard interfaces. 4.4.1 Ethernet Interfaces (LAN0 and LAN1) Pin No. Signal name RJ45 (female) connector MDI0+ MDI0- MDI1+ MDI2+ MDI2-... -
Page 60: Rs422/Rs485 Configured As Rs422 (4-Channel Mode)
GN Series Hardware Manual 4.4 Pin Assignments 4.4.4 RS422/RS485 Configured as RS422 (4-Channel Mode) Use the DIP switches to configure the interfaces (see page 23). Signal short name Long name 9-pin Sub-D plug (female) TxD - Transmit data - RxD +... -
Page 61: Vga Port (Vga)
Technical Data GN Series Hardware Manual 4.4.7 VGA Port (VGA) Signal name 15-pin Sub-D-Plug (female) Analog red output Analog green output Analog blue output Not connected +5V (DDC) Not connected SDA (DDC) TTL Hsync TTL Vsync SCL (DDC) 4.4.8 DC Power Connector... -
Page 62: Cables
GN Series Hardware Manual 4.5 Cables 4.5 Cables Type of communication Description Product no. • GN COM1 to PLC TOOL port (5-pin mini-DIN) RS232C AFC8513D • Cable length: 3m • GN COM1 to FP2 COM/MCU RS232 RS232C AIP81862E1D • Cable length: 2m RS232C •... - Page 63 Technical Data GN Series Hardware Manual RS485 connection cable wiring GN side 9-pin Sub-D male metal housing Signal Pin no. Signal Housing Data-) Data-) Data+) Data+) GND/SG GND/SG Connect cable shield low-resistive to EMC ground.
-
Page 64: Index
DIP switches ...........23 Index Display ..........17, 44 Display with Touch Screen .....17 Accessing Internal Components.....39 All Views ..........14 Electromagnetic compatibility ....7 Applicable Directives and Standards..8 Electromagnetic Compatibility ....7 Electrostatic discharge ......5 Electrostatic Discharge (ESD) ....5 Battery ............41 Environmental Specifications ....46 BEFORE BEGINNING....... - Page 65 Index GN Series Hardware Manual RS232 (COM1, COM2)......52 RS422/RS485 Configured as RS422 LAN0 and LAN1 Ethernet Interface (4-Channel Mode) .......53 Connectors ..........25 RS422/RS485 Configured as RS485 Left and Right Side View ......28 (2-Wire Mode), Half Duplex....53 RS422/RS485 Configured as RS485 (4-Wire Mode), Full Duplex, Bus Master ............53...
- Page 66 Index GN Series Hardware Manual VGA Interface Connector .......25 VGA Port (VGA)........54...
- Page 67 Record of Changes Manual No. Date Description of Changes ACGM0192V1EN April 2010 First edition.
- Page 68 PEW Fire & Security Technology Europe AB Jungmansgatan 12, 21119 Malmö, Tel. +46 40697-7000, Fax +46 40697-7099, www.panasonic-fire-security.com Poland Panasonic Electric Works Polska sp. z o.o. Al. Krakowska 4/6, 02-284 Warszawa, Tel. +48 (0) 22 338-11-33, Fax +48 (0) 22 338-12-00, www.panasonic-electric- works.pl Portugal Panasonic Electric Works España S.A.
