Summary of Contents for Fiberstars JAZZ J400
- Page 1 ™ Fiberstars JAZZ J400 Owners Manual 79-15217-00 REV. A www.fiberstars.com Page 1 of 7...
- Page 2 Allow the light to cool down before installing underwater. ATTENTION Fiberstars JAZZ Series Wet-Niche Lighting Fixtures for Swimming pools are now ETL Classified for use with the following manufactures Wet-Niches for use in new Pool construction. PENTAIR, (American) model no. 79206700 (ABS), model no.
- Page 3 2. Feed cord through niche and conduit, while light fixture is on deck area right above the niche. Feed cord to junction box leaving enough cord, about 3’ to allow fixture to be placed on deck to allow relamping. 3. Make connections in the junction box. 79-15217-00 REV. A www.fiberstars.com Page 3 of 7...
- Page 4 NOTE: Metal Halide is not dimmable! Switch Controlled. The J400 Jazz light is controlled with one switch. Jandy RS Controlled or comparable control system. The J400 Jazz requires one NON -Dimming relay. 79-15217-00 REV. A www.fiberstars.com Page 4 of 7...
- Page 5 4. Disassemble light fixture and remove bulb. a. Disassemble fixture by removing outer clamp ring and lens. 79-15217-00 REV. A www.fiberstars.com Page 5 of 7...
- Page 6 Reassemble lamp assembly by following steps 1 thru 5 in reverse order. Remove old gasket from lens and discard it. Install new gasket during reassembly of light, Fiberstars part number J30-7000. NOTE: DO NOT USE ANY LUBRICANTS WHEN INSTALLING THE LENS GASKET! To prevent the risk of damage or injury do not operate fixture on the deck of Pool or Spa for more than 15 minutes.
- Page 7 (Includes replacement gasket #7) J30-3000 Pilot Screw, with captive neoprene washer J30-4000 Face ring, Stainless Steel J30-5000 Compression Clamp J30-6000 Lens, Fiberstars, 8-3/8 in. dia., tempered J30-7000 Gasket, Lens SAVE THESE INSTRUCTIONS. 79-15217-00 REV. A www.fiberstars.com Page 7 of 7...
