Turtle Beach Ear Force X-Ray User Manual page 16

Surround Sound Settings
To activate the surround sound on your X-Ray headset, follow these instructions.
1. Press SURROUND ON/OFF to turn ON the surround sound function.
2. Press the SURROUND ANGLES button on the transmitter to scroll through six (6) different presets (shown below).
3. The LED will blink in sequence to indicate which preset was selected.
RR
105
o
FR
FL 30
30
o
Front Angle; 30 degrees
1
Rear Angle; 105 degrees
RR
120
o
60
o
FR
Front Angle; 60 degrees
4
Rear Angle; 120 degrees
RR
120
o
RL
105
o
FR
45
o
o
Front Angle; 45 degrees
2
Rear Angle; 120 degrees
135
o
RR
RL
120
o
60
60 o
o
FR
FL
Front Angle; 60 degrees
5
Rear Angle; 135 degrees
2 1
PAIR SURROUND SURROUND
ANGLES ON/ OFF
RL
120
o
FL
45
o
135
o
RL
60
o
FL
135 135
o
RR RL
FR FL
45
o
Front Angle; 45 degrees
3
Rear Angle; 135 degrees
150 150
RR RL
60
60
o
FR FL
Front Angle; 60 degrees
6
Rear Angle; 150 degrees
o
45
o
o
