Summary of Contents for Turtle Beach XP SEVEN
- Page 1 User Guide...
- Page 2 Congratulations on your purchase of the XP SEVEN gaming headset from Turtle Beach. Well played (so far). This premium product is designed to bring unmatched realism and effects to your gaming experience, enhancing it in ways you haven’t known previously.
-
Page 3: Table Of Contents
Using your XP SEVEN Headset on Xbox 360® Using your XP SEVEN Headset on PS3™ Connecting your XP SEVEN Headset to a PC / Mac Using your XP SEVEN Headset on a PC Using your XP SEVEN Headset on a Mac... -
Page 4: Headset Overview
Headset Overview Your Turtle Beach XP SEVEN headset is compatible with Xbox 360, Playstation 3 and PC or Mac gaming platforms. You can enjoy gaming at home or at tournaments and while on the go with portable game systems and mobile devices like smartphones and tablets. -
Page 5: Package Contents
Package Contents XP SEVEN Headset with Audio Control Unit Headset Console Interface Removable Microphone (ACU) Breakaway Cable Console Interface Xbox 360 Chat Cable Digital Optical Cable USB Cable Turtle Beach Stickers Audio Control Unit Extender 3.5mm, 4 Pole Auxiliary Cable... -
Page 6: Feature/Function Map
Feature / Function Map Console Interface 1. Auxiliary Input 2. USB Input 3. Digital Input & Output 4. USB Output 5. 9-pin DIN Audio Control Unit Refer to page 6 for a description of button functions. 1. Master Game Volume Knob / Mute 2. -
Page 7: Audio Control Unit Functions
Audio Control Unit (ACU) Functions Gameplay with the XP SEVEN headset is performed using the functions of the ACU. The ACU has the following functions: Game Volume Wheel: This controls the master game volume as well as the individual 5.1 speaker volumes. Press the wheel to mute game audio and again to un-mute. - Page 8 Audio Control Unit (ACU) Functions (Continued) Additional Chat Functions: Change the pitch of your voice from the deep lows to shrill highs, disguising yourself to other online players. See Chat Presets on Page 18. Voice Morphing: Change the pitch of your voice from the deep lows to shrill highs, disguising yourself to other online players.
-
Page 9: Using Your Xp Seven Headset On Xbox 360
3. Connect your Xbox Controller to the ACU using the Xbox Talkback Cable as shown below. 4. Connect the XP SEVEN Headset to the ACU using the Headset Breakaway Cable as shown below. 5. Connect your mobile phone or digital media player with the included 3.5mm cable. - Page 10 ® Using your XP SEVEN Headset on Xbox 360 Xbox 360 Audio Configuration ® Voice Digital Output Voice Volume Current Setting Digital Stere o Dolby Digital Game Volume Dolby Digital 5.1 Choose the digital output type for your system. Dolby Digital 5.1 with WM...
-
Page 11: Using Your Xp Seven Headset On Ps3
2. Connect the Audio Control Unit to the Console Interface as shown below. Utilize the Audio Control Unit Extender Cable as necessary. 3. Connect the XP SEVEN Headset to the Audio Control Unit using the Headset Breakaway Cable as shown below. 4. Connect your mobile phone or digital media player with the included 3.5mm stereo cable. - Page 12 Using your XP SEVEN Headset on PS3 PS3 Audio Configuration 1. Go to “Settings” - Choose “Accessory Settings” Audio Device Settings - Choose “Audio Device Settings” - Choose “Input/Output Device” - Choose “Turtle Beach XP SEVEN” Microphone Level 2. Adjust microphone levels...
-
Page 13: Connecting Your Xp Seven Headset To A Pc / Mac
Connecting your XP SEVEN Headset to a PC / Mac 3.5mm Stereo Cable (not included) 3.5mm, 4 pole Auxiliary Cable Headset Breakaway Cable Computers and Smartphone not included. -
Page 14: Using Your Xp Seven Headset On A Pc
Using your XP SEVEN on a PC Please note: Depending on your OS Version, the screens may differ but the steps will remain the same. 1. Connect the Audio Control Unit to your PC using the USB Cable. Allow five (5) minutes for Windows to automatically install drivers. - Page 15 Using your XP SEVEN on a PC 5. Right click on “Turtle Beach XP SEVEN Chat” and select “Set as Default Communication Device.” 6. Left click “Turtle Beach XP SEVEN Game” and click, “Configure” to confirm 5.1 channel audio. 7. Press “Next” two (2) times to ensure that “Front Left and Right”...
-
Page 16: Using Your Xp Seven Headset On A Mac
Chat program screens may differ depending on the operating system. Using Skype (download from www.skype.com), open your preferences. Go to Audio / Video and select, “Turtle Beach XP SEVEN Chat” for microphone, ringing and speakers. NOTE: Not all chat programs default to the Turtle Beach chat path. -
Page 17: Using Your Xp Seven Headset With Other Devices
Using your XP SEVEN Headset with Other Devices The 4-pole 3.5mm jack in your XP SEVEN Headset’s Breakaway Cable allows you to enjoy great audio wherever you go by plugging into your mobile phone, portable game system, tablet, MP3 player and more. -
Page 18: Speaker Mode
Speaker Mode The XP SEVEN Audio Control Unit (ACU) may be connected to a stereo speaker system. Note, the Headphone Jack is deactivated when in Speaker Mode. 1. Connect the ACU to a digital music player using the included 3.5mm auxiliary cable as shown. -
Page 19: Dolby® Digital Processing
The XP SEVEN uses Dolby® Digital surround processing technology – the industry-standard format for encoding multi- channel game audio. Dolby Digital processing recreates 5.1 channel surround sound using the XP SEVEN headset so you can hear the sound all around you, as if you were listening to a 5.1 speaker system. -
Page 20: Presets
Presets Your XP SEVEN headset features several built-in presets on the ACU for enhanced gaming, voice and speaker effects. Simply tap the numbered preset on the ACU to switch Game Presets. Press the Chat Presets Button once to enable Chat Presets for buttons 1 –... -
Page 21: Specifications
Presets / Specifications Speaker Presets Main: Incorporates Surround Sound processing for an immersive audio experience. 1. Flat: Hear stereo game sound without effects processing or Surround Sound. 2. Bass Boost: Hear and feel the rumble of deeper bass sound effects. 3. -
Page 22: Compliance / Conformity
Regulatory Compliance Statements Heading for the EAR FORCE XP7 Models Federal Communications Commission (FCC) Compliance Notices Class B Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15, Subpart B of the FCC Rules. -
Page 23: Declaration Of Conformity
Declaration of Conformity Heading Marking by this symbol: indicates compliance with the Essential Requirements of the EMC Directive of the European Union (2004/108/EC). This equipment meets the following conformance standards: Safety: EN 60950-1: 2006 + A11 + A1 + A12 (T-Mark License) Also Licensed for Standards: EC 60950-1: 2005 + A1: 2009, (CB Scheme Report/Certificate), UL60950-1 (NRTL License), CSA22.2, 60950-1 (SCC License) -
Page 24: Warranty
Usa and Canada warranty service is provided by our turtle Beach Usa offices and in all other Countries it is provided by our local international distributors when available. refurbished/recertified products are sold on an as is basis with a 90-day warranty or less in accordance with each vendor’s policy. - Page 25 EXCLUSIONS FROM LIMITED WARRANTY: This Limited Warranty shall not apply and VTB has no liability under this Limited Warranty if the Turtle Beach Product: - is used for commercial purposes such as “LAN, Call Centers” (including rental or lease); - is modified or tampered with;...
- Page 26 TurtleBeach.com/support copyright © 2013 Voyetra turtle beach, inc. (Vtb, inc.) all rights reserved. no part of this package may be reproduced without permission. turtle beach, the turtle beach Logo, Voyetra, Ear Force, and Engineered for Gaming are either trademarks or registered trademarks of VTB, Inc. All other trademarks are properties of their respective companies and are hereby acknowledged.
