Turtle Beach KILO User Manual

For xbox 360/ps3/pc/mac
Hide thumbs
Table of Contents

Advertisement

Quick Links

Watch Turtle Beach product training videos at:
youtube.com / TurtleBeachVideos
Copyright © 2012 Voyetra Turtle Beach, Inc. (VTB, Inc.) All rights reserved. No part of this package may be reproduced without permission. Turtle Beach, the Turtle Beach
Logo, Voyetra, Ear Force, and Engineered for Gaming are either trademarks or registered trademarks of VTB, Inc. All other trademarks are properties of their respective
companies and are hereby acknowledged. PlayStation is registered trademark and PS3 is a trademark of Sony Computer Entertainment. Xbox, Xbox 360, and Xbox LIVE are
registered trademarks of Microsoft Corporation. Dolby and the double-D symbol are trademarks of Dolby Laboratories. Made in China. © 2012 Activision Publishing, Inc.
ACTIVISION, CALL OF DUTY, CALL OF DUTY BLACK OPS and stylized roman numeral II are trademarks of Activision Publishing, Inc.
This product is compliant with the Consumer Product Safety
Improvement Act of 2008, Public Law 110-314 (CPSIA)
XBOX 360
| PS3™ I PC I Mac
®
product support and warranty information:
TurtleBeach.com / support
FOR / POUR
N30375

Advertisement

Table of Contents
loading

Related Manuals for Turtle Beach KILO

Summary of Contents for Turtle Beach KILO

  • Page 1 TurtleBeach.com / support Copyright © 2012 Voyetra Turtle Beach, Inc. (VTB, Inc.) All rights reserved. No part of this package may be reproduced without permission. Turtle Beach, the Turtle Beach Logo, Voyetra, Ear Force, and Engineered for Gaming are either trademarks or registered trademarks of VTB, Inc. All other trademarks are properties of their respective companies and are hereby acknowledged.
  • Page 2 L I M I T E D E D I T I O N User Guide...
  • Page 3 Congratulations on your purchase of the Call of Duty® Black Ops II Earforce Kilo Headset from Turtle Beach. You are now in possession of a premium product that will enhance your gaming experience in new ways, engaging your sensitivities, heightening your communications, and...

  • Page 4: Table Of Contents

    Package Contents Feature/Function Map Connecting to XBOX 360 (HDMI /RCA) Connecting to a PS3 (HDMI) Using your Kilo Headset on PS3 Connecting your Kilo Headset to a PC or Mac Mac Set Up and Chat Specifications Compliance / Conformity Warranty –...

  • Page 5: Package Contents

    FOR / POUR XBOX 360 | PS3™ | PC | MAC ® Quick Start Guide For the full user guide, please go to http://www.turtlebeach.com/products/kilo Package Contents | Contenu de la boîte EarForce Kilo XBOX 360 Talkback Cable Kilo Audio Splitter Cable Turtle Beach Sticker XBOX 360 câble Discussion...

  • Page 6: Feature/Function Map

    Feature / Function Map (Location of controls / inputs) In-line Amplifier 1. Mic. Mute Switch Activates / Disables Chat Mic. 2. Mic. Mute LED Lights GREEN when Mic. is on; RED when Mic. is off 3. Game Volume Sets the game sound level 4.

  • Page 7: Connecting To Xbox 360 (Hdmi /Rca)

    * If your TV has RED & WHITE RCA jacks labeled as AUDIO OUTPUT/AUDIO OUT/AUDIO L&R, you can use the provided RCA Audio Adapter Cable to feed game / TV audio directly from your TV to your Turtle Beach Kilo headset (AUDIO IN jacks will not send audio to the headset).
  • Page 8 1. Connect your XBOX 360 controller to the Kilo headset using the XBOX 360 Talkback Cable. 2. Connect your Kilo Headset to the RCA Splitter Cable. Game audio will be heard through both the TV and the headset. 3. Connect the XBOX 360 Composite AV Cable to the stereo audio inputs (Red/White) and Video (Yellow) on your TV.

  • Page 9: Connecting To A Ps3 (Hdmi)

    2. Connect RED/WHITE ends of the PS3 Console A/V Cable to the RCA Splitter Cable. 3. Insert the Kilo USB Power Connector to an available USB port on the PS3 Console. 4. Configure PS3 Audio And Chat Settings (see instructions on page 8 & 9)
  • Page 10 2. Connect the RCA Splitter Cable to the A/V Red/White inputs on your TV. 3. Connect the PS3 Console A/V Cable to the RCA Splitter Cable: (Yellow for Video goes into TV) 4. Insert the Kilo USB Power Connector to an available USB port on the PS3 Console. USB Power...

  • Page 11: Using Your Kilo Headset On Ps3

    Using your Kilo Headset on PS3 PS3 Audio Configuration Your Turtle Beach Kilo headset is designed to work on PS3 game consoles. In order to get ideal functionality from your headset, follow the directions below. 12/14 12:15 PM Audio Output Settings Select the connector on the TV or AV amplifier (receiver).
  • Page 12 Using your Kilo Headset on PS3 PS3 Chat Configuration Audio Device Settings Microphone Level Turtle Beach PX11 Headset Output Device Turtle Beach PX11 Headset X Enter Back Options 1. Go to “Settings” - Choose “Accessory Settings” - Choose “Audio Device Settings”...

  • Page 13: Connecting Your Kilo Headset To A Pc Or Mac

    1. Connect the Kilo 3.5mm plug to the 3.5mm speaker / headphone jack on your PC or Mac. 2. Connect the Kilo USB power cable to an available USB port on your PC or Mac. This will power the headset and allow a separate USB chat/audio connection.
  • Page 14 Connecting your Kilo Headset to a PC or Mac PC Set Up 1. Plug your Kilo headset into your PC by inserting the 3.5mm cable into your soundcard/headphone jack and USB into an open USB port. Windows will automatically install drivers; this may take a few minutes.
  • Page 15 “Set as default device”, if it is not already set. 5. Right click on "Turtle Beach PX11 Headset" and Select 6. Click on the "recording tab'" then right click "Turtle Beach PX11 "Set as default Communication Device" Headset" and select "set as default device”. When you speak into the...

  • Page 16: Mac Set Up And Chat

    Chat Set Up 1. Open your preferences in your chat program, such as Skype. Go to audio / video. Select “Turtle Beach PX11 Headset” for microphone, ringing and speakers.* * NOTE: Not all chat programs default to the Turtle Beach chat path. Some programs may require manual setup to output chat via the Turtle Beach Kilo Chat interface.

  • Page 17: Specifications

    Specifications · PS3 / XBOX Connection: RCA · PC Audio Connection: USB or 3.5mm Connection to sound card · PS3 / PC Mic. Connection: USB · XBOX 360 Mic. Connection: 2.5mm Chat Cable · Power: USB...

  • Page 18: Compliance / Conformity

    Regulatory Compliance Federal Communications Commission (FCC) Compliance Notices Class B Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15, Subpart B of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 19 Declaration of Conformity Declaration of Conformity Marking by this symbol: indicates compliance with the Essential Requirements of the EMC Directive of the European Union (2004/108/EC). This equipment meets the following conformance standards: Safety: EN 60950-1: 2006 Also Licensed for Standards: IEC 60950-1:2005, (CB Scheme Report/Certificate), UL60950-1 (NRTL License), CSA22.2, 60950-1 (SCC License) Additional licenses issued for specific countries available on request Emissions: EN 55022: 2006, EN 55024: 1998 + A1:2001 + A2: 2003...

  • Page 20: Warranty

    WARRANTY SERVICE: In the USA and CANADA Warranty Service is provided by our Turtle Beach USA offices and in all other Countries it is provided by our local International Distributors when available. Refurbished/Re- certified products are sold on an AS IS basis with a 90-day Warranty or less in accordance with each vendor's policy.

This manual is also suitable for:

Call of duty black ops ii earforce kilo
