- Page 1 User's Manual 2-WAY STEREO X23SW CROSSOVER PLUS SUBWOOFER www.altoproaudio.com Version 1.2 September 2005 English...
- Page 2 SAFETY RELATED SYMBOLS Fuse To prevent fire and damage to the product, use only the recommended fuse type as indicated in this CAUTION manual. Do not short-circuit the fuse holder. Before RISK OF ELECTRIC SHOCK DO NOT OPEN replacing the fuse, make sure that the product is OFF and disconnected from the AC outlet.
- Page 3 Preface Dear Customer: Thanks for choosing LTO Active Crossover and thanks for choosing the one of results of AUDIO TEAM job and researches. For our LTO AUDIO TEAM, music and sound are more than a job...are first of all passion and let us say... our obsession! We have been designing professional audio products for a long time in cooperation with some of the major brands in the world in the audio field.
-
Page 4: Table Of Contents
3.2 The Rear Panel 4. INSTALLATION & CONNECTION ..................5 4.1 Mains Connection 4.2 Audio Connection 4.3 Rack Mounting 5. APPLICATION .......................7 5.1 X23SW 2-Way Stereo 6. TECHNICAL SPECIFICATIONS ..................8 7. WARRANTY ......................... 9... -
Page 5: Introduction
CD Horn Equ, alization, and individual Phase and Mute switches per frequency band. The X23SW Active Crossover is an effective and efficient electronic crossover solution, which will give you precise control and superior sound from your loudspeaker system. 2. FEATURE LIST... -
Page 6: The Rear Panel
4.1 Mains Connection Please ensure that the LTO X23SW Active Crossover is set to the correct supply voltage before plugging the power cord into the wall outlet , use the same fuse as marked on the fuse holder at the AC power connection socket. -
Page 7: Audio Connection
For XLR onnector XLR Unbalanced Input XLR Balanced Input b. In Line Connection For these applications, the X23SW Active Crossover provides XLR connectors to easily interface with most professional audio devices. Follow the configuration examples below for your particular connection. Balanced Ring... -
Page 8: Rack Mounting
The most secure mounting is on a universal rack shelf available from various rack manufactures or your music dealer. The X23SW Active Crossover fits into one standard 19" rack unit of space. Please allow at least an additional 4" depth for the connectors on the rear panel. Be sure that there is enough air space... -
Page 9: Technical Specifications ...................... ...................................................... .......... 8
6.TECHNICAL SPECIFICATIONS Electrical Subwoofer Frequency Range 50Hz ~ 250Hz Low - High Frequency Range 250Hz ~ 6KHz <0.05% S/N Ratio >95dB Controls Input Level Continuouliy variable Output Level Sub, Low. High continuously variable Front panel switches Low Cut Front panel switches Phase Power Supply Connector type... -
Page 10: Warranty ........... ...................... ........................................................... ..................... 9
7. WARRANTY 1. WARRANTY REGISTRATION CARD To obtain Warranty Service, the buyer should first fill out and return the enclosed Warranty Registration Card within 10 days of the Purchase Date. All the information presented in this Warranty Registration Card gives the manufacturer a better under- standing of the sales status, so as to purport a more effective and efficient after-sales warranty service. - Page 11 No. 1, Lane 17, Sec. 2, Han Shi West Road, Taichung 40151 Taiwan http://www.altoproaudio.com Tel: 886-4-22313737 email: alto@altoproaudio.com Fax: 886-4-22346757 All rights reserved to ALTO. All features and content might be changed without prior notice. Any photocopy, translation, or reproduction of part of this manual without written permission is forbidden. Copyright 2005 SEIKAKU GROUP NF00876-1.2...
