Appendix E: Technical Specifications

APPENDIX E: TECHNICAL
SPECIFICATIONS
Note: This is an update to the original VoicePrism document.
Digital I/O
Connectors:
Input Format:
Output Format:
Digital Output
Output Dither:
Sample Rates:
Frequency Response DIO:
Analog Inputs
Connectors:
Impedance (Bal/Unbalanced-Line): 28 kOhms
Max. Input Level Line:
A to D Conversion:
THD:
Frequency Response:
Analog Outputs
Connectors:
Impedance:
Max. Output Level:
D to A Conversion:
XLR (AES/EBU)
RCA Phono (S/PDIF)
24 Bit
24 bit processed audio on VoiceCraft Card
AES/EBU and S/PDIF
24 bit unprocessed ADC output on
VoicePrism Plus S/PDIF
HPF/TPDF dither 24/20/16/8 bit
(VoiceCraft Card outputs only)
44.1kHz; 48kHz
DC to 23.9 kHz ± 0.01 dB @ 48 kHz
XLR Balanced (pin 2 hot), TRS 1/4"
+21dBu
24 bits, 100dB dynamic range (A-weighted)
0.005% @ 1kHz (A-weighted)
10Hz - 12kHz ±0.8dB, -2dB @ 20kHz
TRS 1/4"
680 Ohms (stereo out); 340 Ohms (mono out)
+21 dBu
24 bits, 100dB dynamic range (A-weighted)
% 37 %
