• How to set the DIP-switches to obtain the right starting address:
On the back of the Falcon you will see that each of the first 9 DIP-switches
corresponds to certain value:
Dip #1 #2
Value 1 2
You can combine the values of these switches to become any starting address
between 1 and 512:
Begin address = 01
Begin address = 05
Begin address = 09
Begin address = 13
Begin address = 62
• DMX-CONFIGURATION OF FALCON:
Channel 1
Shutter
255 Fastest speed
Gobo Shaking
136 Slowest speed
135 Fastest speed
Strobe
016 Slowest speed
000-015 Stop
• DIFFERENT GOBOS:
JB SYSTEMS
#3 #4 #5
4 8 16
switch 1=ON
switch 1+3=ON
switch 1+4=ON
switch 1+3+4=ON
switch 2+3+4+5+6=ON
Channel 2
Gobos/Colors
255 Fastest speed
Rainbow Effect
128 Slowest speed
120-127 Gobo 14 / Yellow
112-119 Gobo 13 / Red
104-111 Gobo 12 / Four-color
096-103 Gobo 11 / Green
088-095 Gobo 10 / Magenta
080-087 Gobo 9 / Yellow
072-079 Gobo 8 / Cyan
064-071 Gobo 7 / Red
056-063 Gobo 6 / Green + Pink
048-055 Gobo 5 / Magenta
040-047 Gobo 4 / Amber
032-039 Gobo 3 / Blue
024-031 Gobo 2 / Orange
016-023 Gobo 1 / Cyan
008-015 Open
000-007 Blackout
5/31
OPERATION MANUAL
#6 #7 #8
32 64 128
values: 1
values: 1+4 = 5
values: 1+8 = 9
values: 1+4+8 = 13
values: 2+4+8+16+32 = 62
Channel 3
Rotation
246-255 Stop
245
135
121-134 Stop
120
010
000-009 Stop
#9
256
Channel 4
Zoom
255 Fastest speed
Zoom in/out
(continue)
160 Slowest speed
159 Zoom out max.
000 Zoom in min.
