User Manual
M8050 Compact Handheld Computer
Quick-Start Guide
Effective Date:
June 2011
Getting Started
1
1
Load the main battery
1.
Loosen the battery
2.
retaining screw
3.
4.
Tighten the battery
Insert battery and
retaining screw
replace door
Stylus
SD Card Slot
Audio &
Microphone Jack
Communications &
Charging Port
Charge the M8050 for
2
2
at least 6 hours
Remove the
battery door
LED
Indicator
Front View
LCD Touch
Screen
Trackball
18-key
& LED Indicator
Keypad
Getting Started
USB to PC
12V AC
Adapter
RED:
Charging ( < 70% )
YELLOW:
Charging ( > 70% )
GREEN:
Fully Charged
Back View
Speaker
Tether
Location
Battery
Door
Scanner Window
Scan Button
Getting Started
Learn More about
3
3
the AML M8050
Download the M8050 Specification
Sheet and User Manual online at
www.amltd.com/support.asp
or
View the
M8050 Product Video
to learn about the many features
available with the M8050.
Magnetic
Stripe Reader
