AML M7225 Quick Start Manual

M7225
Wireless
Handheld Computer
Quick-Start Guide
800.648.4452
www.amltd.com
07072015
Getting Started
1
Load the main battery
1. 2.
Turn the access latch Remove the battery
counter-clockwise door by hinging it upward
3. 4.
Turn the access
Insert battery in rear and slide
latch clockwise
towards the front to engage
1
2
Front and Bottom Views
Stylus
Speaker
Touchscreen
Scan
Key
Power
Key
Microphone Jack
Cradle Port
Getting Started
2
Charge the M7225 for
at least 4 hours
USB
Battery Charge Times
Main Battery Backup Battery
Before Initial Use = 4 hours Before Initial Use =
For Full Charge = 5 hours For Full Charge = 2 hours
Back and Top Views
Beeper
Laser Safety
Label
LCD &
Backlight
Key
Battery
Serial Label
Door
Getting Started
3

Using the Touchscreen

The M7225 uses a
resistive-type touchscreen
that can be used with
gloved fingers or a
plastic tipped stylus.
5V DC
Power Jack
NEVER USE METAL OR
SHARP OBJECTS ON
1 hour
THE TOUCHSCREEN!
Alphanumeric Keypad
1
8
Battery
Latch
7
1. Power ON/OFF Key
Stylus Holder
2. Scan Key
3. Backlight Key
Scan Engine
4. Arrow Keys
Window
Getting Started
4
Learn More about
the AML M7225
Learn more about the M7225 at:
www.amltd.com/m7225
Give us a call at
Get Updates from AML
Don't forget to register your product(s)
online at www.amltd.com/register
receive updates about AML products
2
3
4
5
6
5. Numeric Keys
6. Alpha Keys
7. Menu Key
8. Enter Keys
or
800.648.4452
to
and software.
