AML TDX20 Quick Start Manual

TDX20
Wireless
Handheld Computer
Quick-Start Guide
800.648.4452
www.amltd.com
02162016
Download DC Console
3
Download DC Console
Download the DC Console utility at
www.barcodepower.com
DC Console
Utilize
quickly modify existing
applications or create
new ones and transfer
files from your TDX20 to
your PC.
IMPORTANT!
Users must install either Microsoft ActiveSync
®
or Windows Mobile Device Center
® ®
installing AML DC Console.
Note: Microsoft ActiveSync works only with
Windows XP or earlier.
®
Note: The Windows Mobile Device Center is only
supported on Windows Vista or later.
™
10312016-1
Physical Features
Scan Key
Power
Button
DC Suite Software
The TDX20 comes with
a suite of pre-installed
applications as a part
of our
applications were
to
developed for
common data
collection tasks and
are ready to go right
out of the box.
As future
applications are
developed, they will
®
be made available
before on the web at
barcodepower.com.
Dashboard
All applications are
launched from here.
Charging
1
Charge the TDX20 for 6 hours
Use the USB cable and the optional adapter to charge
from a 110VAC wall outlet.
LCD
T9 Keypad
Scan Engine
Window
Top
DC Suite Software
Item Count
Simple one-field scanning.
DC Suite. These
Item Quantity
Scan the Item Number and key in the
Quantity.
Item Serial
Scan in Item Number and the unique
Serial Number.
Item Lot Quantity
Scan the Item Number and then collect
Lot Number and Quantity information.
Asset Tracker
Asset Tracking application.
Check In/Out
Check-In/Out application for tool or
part rooms.
Compare
Compare two scans and confirm that
they are the same OR not the same.
2
Starting up the TDX20
Power and Reboot Procedures
Power Button
• If left idle for 30 minutes, the TDX20 will automatically
USB Charging &
power down.
Communications Port
• Pressing the power button briefly, while the unit is on,
will either put the TDX20 into suspend mode, or wake it
up depending on its current state.
• Pressing and holding the power button for more
than 3 seconds causes the TDX20 to power off.
Bottom
Other Apps:
access point. The user interface will display any
data files created by other DC Suite apps.
The interface will also display lookup files that are
configured to update (using DC Console). These
files can be selected and synced, provided that
DC Console or DC Sync server is running. This also
requires that DC Suite and DC Console (or DC
Sync) end points are configured correctly (IP
Address and Port).
DC Uplink requires a license that is typically
purchased at the same time as the TDX20.
Powering Up
• Pressing the power button while
the TDX20 is OFF powers up and
re-boots the unit.
• While charging, the TDX20
display will go dark after a time
set in the 'Display Properties'
settings in Windows® Control
Panel. Touching the screen or
any key will awaken it from this
idle state.
DC Uplink
The DC Uplink app provides a
wireless way to send data files
and update relevant lookup
files, on the device, using a
local network with a wireless
