  • Page 1 G4S601-B Rev. A+ System Board User’s Manual 935-G4S606-500 A84500447...
  • Page 2 Copyright This publication contains information that is protected by copyright. No part of it may be reproduced in any form or by any means or used to make any transformation/adaptation without the prior written permission from the copyright holders. This publication is provided for informational purposes only. The manufacturer makes no representations or warranties with respect to the contents or use of this manual and specifically disclaims any express or implied warranties of merchantability or fitness for any...

  • Page 3: Fcc And Doc Statement On Class B

    Joystick or MIDI port: • Do not use any joystick or MIDI device that requires more than 10A current at 5V DC. There is a risk of fire for devices that exceed this limit. FCC and DOC Statement on Class B This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules.
  • Page 4 Introduction Notice An electronic file of this manual is included in the CD. To view the user’s manual in the CD, insert the CD into a CD-ROM drive. The autorun screen (Main Board Utility CD) will appear. Click “User’s Manual” on the main menu.

  • Page 5: Table Of Contents

    Introduction Table of Contents Chapter 1 - Introduction 1.1 Specifications........................1.2 Special Features of the System Board............. 1.3 Package Checklist......................Chapter 2 - Hardware Installation System Board Layout ................... System Memory......................CPU............................Jumper Settings......................Rear Panel I/O Ports....................I/O Connectors......................Chapter 3 - BIOS Setup 3.1 Award BIOS Setup Utility.................
  • Page 6 Introduction Appendix A - Watchdog Timer A.1 Watchdog Timer......................Appendix B - Enabling the Hyper-Threading Technology B.1 Enabling the Hyper-Threading Technology........... Appendix C - System Error Messages C.1 POST Beep........................C.2 Error Messages......................Appendix D - Troubleshooting D.1 Troubleshooting Checklist.................

  • Page 7: Chapter 1 - Introduction

    Introduction Chapter 1 - Introduction 1.1 Features Processor ® ® • Intel Pentium 4 (Prescott and Northwood) processor up to 3.2GHz+ Intel Hyper-Threading Technology FSB: 533MHz and 800MHz ® ® • Intel Celeron processor 400MHz system data bus • Socket 478 Chipset •...
  • Page 8 Introduction 64 Mbit 128 Mbit 256 Mbit 512 Mbit Density Density Width SS/DS SS/DS SS/DS SS/DS SS/DS SS/DS SS/DS Single/Double SS/DS 184-pin DDR 64/128MB 32MB/NA 128/256MB 64MB/NA 256/512MB 128MB/NA 512/1024MB 256MB/NA BIOS • Award BIOS • 4Mbit flash memory Energy Efficient Design •...
  • Page 9 Introduction • 2D graphics features Optimized 256-bit BLT engine 32-bit alpha blended cursor Programmable 3-color transparent cursor • 3D graphics features 200 megapixels/sec fill rate Maximum 3D resolution: 1600x1200x32 @ 85Hz Flat and Gouraud shading 16- and 24-bit Z-buffering and 16- and 24-bit W-buffering Ver tex progr ammable pixel...
  • Page 10 Introduction AGP (Accelerated Graphics Port) • Supports AGP 3.0 (AGP 4x and 8x) and AGP 2.0 (AGP 1x and 4x) spec. • Supports 1.5V AGP 8x (2.13GB/sec.) and AGP 4x (1066MB/ sec.) add-in cards. Note: AGP 2x and 3.3V AGP cards are not supported. Rear Panel I/O Ports •...

  • Page 11: Special Features Of The System Board

    Introduction Compatibility • PCI 2.2 and AC ’97 compliant • Intel AGP version 3.0 • 4 layers, ATX form factor • 30.5cm (12") x 22cm (8.66") 1.2 Special Features of the System Board Hyper-Threading Technology Functionality Requirements The system board supports Intel processors with Hyper-Threading Technology.
  • Page 12 Introduction 6-channel Audio The system board supports 6-channel audio output via the surround connector (which supports 4-channel audio output signals) and the line-out jack (2-channel) at the rear panel. S/PDIF S/PDIF is a standard audio file transfer format that transfers digital audio signals to a device without having to be converted first to an analog format.
  • Page 13 Introduction AGP (Accelerated Graphics Port) AGP is an interface designed to support high performance 3D graphics cards. It utilizes a dedicated pipeline to access system memory for texturing, z-buffering and alpha blending. The universal AGP slot supports AGP 8x with up to 2132MB/sec. bandwidth and AGP 4x with up to 1066MB/sec.
  • Page 14 Introduction Wake-On-PS/2 Keyboard/Mouse This function allows you to use the PS/2 keyboard or PS/2 mouse to power-on the system. Important: The 5VSB power source of your power supply must support 720mA. Wake-On-USB Keyboard/Mouse This function allows you to use a USB keyboard or USB mouse to wake up a system from the S3 (STR - Suspend To RAM) state.

  • Page 15: Package Checklist

    Introduction into RAM (Random Access Memory) when it powers-off. The operating session will resume exactly where you left off the next time you power-on the system. Important: The 5VSB power source of your power supply must support AC Power Failure Recovery When power returns after an AC power failure, you may choose to either power-on the system manually or let the system power-on automatically.

  • Page 16: Chapter 2 - Hardware Installation

    Hardware Installation Chapter 2 - Hardware Installation 2.1 System Board Layout 2nd fan PS/2 Power (JP2) DIMM LED Mouse CPU fan COM 1 power Parallel +12V power USB 1 USB 2 USB 1-4 Power Intel (JP1) 82865G USB 3 USB 4 Mic-in Line-in Line-out...

  • Page 17: System Memory

    Hardware Installation Warning: Electrostatic discharge (ESD) can damage your system board, processor, disk drives, add-in boards, and other components. Perform the upgrade instruction procedures described at an ESD workstation only. If such a station is not available, you can provide some ESD protection by wearing an antistatic wrist strap and attaching it to a metal part of the system chassis.

  • Page 18: Hardware Installation

    Hardware Installation Virtual Single Channel (VSC) If both channels are populated with different memory configurations, the MCH defaults to Virtual Single Channel. Dual Channel (DC) Dual channel provides better system performance because it doubles the data transfer rate. Single Channel Only one socket is populated with DIMM.

  • Page 19: Installing The Dim Module

    Hardware Installation 2.2.1 Installing the DIM Module A DIM module simply snaps into a DIMM socket on the system board. Pin 1 of the DIM module must correspond with Pin 1 of the socket. Notch Pin 1 1. Pull the “tabs” which are at the ends of the socket to the side. 2.

  • Page 20: Cpu

    Hardware Installation 2.3 CPU 2.3.1 Overview The system board is equipped with a surface mount 478-pin CPU socket. This socket is exclusively designed for installing an Intel processor. 2.3.2 Installing the CPU 1. Locate Socket 478 on the system board. 2.
  • Page 21 Hardware Installation 3. Position the CPU above the socket then align the gold mark on the corner of the CPU (designated as pin 1) with pin 1 of the socket. Important: Handle the CPU by its edges and avoid touching the pins. Gold mark Pin 1 4.

  • Page 22: Installing The Fan And Heat Sink

    Hardware Installation 5. Once the CPU is in place, push down the lever to lock the socket. The lever should click on the side tab to indicate that the CPU is completely secured in the socket. 2.3.3 Installing the Fan and Heat Sink The CPU must be kept cool by using a CPU fan with heatsink.
  • Page 23 Hardware Installation 1. The system board comes with the retention module base already installed. Retention Retention hole hole Retention Retention hole hole Retention module base 2. Position the fan / heat sink and retention mechanism assembly on the CPU, then align and snap the retention legs’ hooks to the retention holes at the 4 corners of the retention module base.
  • Page 24 Hardware Installation 3. The retention levers at this time remains unlocked as shown in the illustration below. Retention lever Retention lever 4. Move the retention levers to their opposite directions then push them down. This will secure the fan / heat sink and retention mechanism assembly to the retention module base.

  • Page 25: Jumper Settings

    Hardware Installation 2.4 Jumper Settings 2.4.1 Clear CMOS Data 1-2 On: Normal 2-3 On: (default) Clear CMOS Data If you encounter the following, a) CMOS data becomes corrupted. b) You forgot the supervisor or user password. c) You are unable to boot-up the computer system because the processor’s ratio was incorrectly set in the BIOS.
  • Page 26 Hardware Installation 4. After powering-on the system, press <Del> to enter the main menu of the BIOS. 5. Select the Frequency/Voltage Control submenu and press <Enter>. 6. Set the processor’s ratio to its default setting or an appropriate frequency ratio. Refer to the Frequency/Voltage Control section in chapter 3 for more information.
  • Page 27 Hardware Installation 2.4.2 PS/2 Power Select 1-2 On: 5V 2-3 On: 5VSB (default) JP2 is used to select the power of the PS/2 keyboard/mouse port. Selecting 5VSB will allow you to use the PS/2 keyboard or PS/2 mouse to wake up the system. BIOS Setting Configure the PS/2 keyboard/mouse wake up function in the Integrated Peripherals submenu (“Super IO Device”...

  • Page 28: Usb Power Select

    Hardware Installation 2.4.3 USB Power Select USB 1-4 (JP1) 1-2 On: 5V 2-3 On: 5VSB (default) USB 5-8 (JP3) 1-2 On: 5V 2-3 On: 5VSB (default) JP1 and JP3 are used to select the power of the USB ports. Selecting 5VSB will allow you to use the USB keyboard or USB mouse to wake up the system.
  • Page 29 Hardware Installation 2.4.4 Auto Power-on 1-2 On: 2-3 On: Auto power-on Auto power-on enabled disabled (default) If you want the system to power-on whenever AC power comes in, set pins 1 and 2 to On.

  • Page 30: Rear Panel I/O Ports

    Hardware Installation 2.5 Rear Panel I/O Ports PS/2 Mouse Parallel Mic-in USB 2 Line-in Line-out PS/2 KB COM 1 USB 1 USB 3-4 The rear panel I/O ports consist of the following: • PS/2 mouse port • PS/2 keyboard port •...
  • Page 31 Hardware Installation 2.5.1 PS/2 Mouse and PS/2 Keyboard Ports PS/2 Mouse PS/2 Keyboard The system board is equipped with an onboard PS/2 mouse (Green) and PS/2 keyboard (Purple) ports - both at location CN1 of the system board. The PS/2 mouse port uses IRQ12. If a mouse is not connected to this port, the system will reserve IRQ12 for other expansion cards.
  • Page 32 Hardware Installation • BIOS Setting: Configure the PS/2 wake up function in the Integrated Peripherals submenu (“Super IO Device” section) of the BIOS. Refer to chapter 3 for more information. Important: The 5VSB power source of your power supply must support 720mA.

  • Page 33: Serial Ports

    Hardware Installation 2.5.2 Serial Ports COM 1 COM 2 The serial ports are RS-232C asynchronous communication ports with 16C550A-compatible UARTs that can be used with modems, serial printers, remote display terminals, and other serial devices. The system board is equipped with an onboard serial port (CN4 - Teal/Turquoise) for COM 1 and a 9-pin connector at location J7 for COM 2.

  • Page 34: Parallel Port

    Hardware Installation 2.5.3 Parallel Port Parallel The system board has a standard parallel por t (Burgundy) at location CN7 for interfacing your PC to a parallel printer. It supports SPP, ECP and EPP. Setting Function Allows normal speed operation but (Standard Parallel Port) in one direction only.

  • Page 35: Vga Port

    Hardware Installation 2.5.4 VGA Port The system board can only be used with an analog video monitor. Connect the monitor’s 15-pin D-shell cable connector to the VGA port (Blue) at location CN2. If your monitor supports analog video but does not have a 15-pin D-shell connector, see your monitor dealer for the adapter or optional cable.

  • Page 36: Universal Serial Bus Ports

    Hardware Installation 2.5.5 Universal Serial Bus Ports USB 2 USB 1 USB 4 USB 3 USB 5-6 USB 7-8 Four onboard USB 2.0/1.1 ports (Black) are at locations CN5 (USB 1-2) and CN6 (USB 3-4) of the system board. J10 (USB 5-6) and J12 (USB 7-8) connectors allow you to connect 4 additional USB 2.0/1.1 ports.
  • Page 37 Hardware Installation Wake-On-USB Keyboard/Mouse The Wake-On-USB Keyboard/Mouse function allows you to use a USB keyboard or USB mouse to wake up a system from the S3 (STR - Suspend To RAM) state. To use this function: • Jumper Setting: JP1 and/or JP3 must be set to “2-3 On: 5VSB”. Refer to “USB Power Select”...
  • Page 38 Hardware Installation 2.5.6 RJ45 Fast-Ethernet Port RJ45 LAN The system board is equipped with an onboard RJ45 fast-ethernet LAN port at location CN6. It allows the system board to connect to a local area network by means of a network hub. BIOS Setting Enable or disable the onboard LAN in the Integrated Peripherals submenu (“Onboard Device”...
  • Page 39 Hardware Installation 2.5.7 Audio Mic-in Line-in Line-out Audio Jacks The system board is equipped with 3 audio jacks at location CN3. A jack is a one-hole connecting interface for inserting a plug. • Mic-in Jack (Pink) This jack is used to connect an external microphone. •...
  • Page 40 Hardware Installation • Line-out Jack (Lime) This jack is used to connect to the front right and front left speakers of the audio system. Note: The functions of these audio jacks will change to support 6- channel audio output only after you have installed the audio driver and set the appropriate configuration.

  • Page 41: I/O Connectors

    Hardware Installation 2.6 I/O Connectors 2.6.1 Game/MIDI Connector The system board is equipped with a 15-pin connector at location J4 for connecting an external game/MIDI port. One card-edge bracket, mounted with a game/MIDI port cable, will be provided as an option. Install the card-edge bracket to the system chassis then connect the game/MIDI port cable to connector J4.
  • Page 42 Hardware Installation 2.6.2 CD-in Internal Audio Connector Ground Ground Left audio Right audio channel channel The CD-in (J2) connector is used to receive audio from a CD-ROM drive, TV tuner or MPEG card.
  • Page 43 Hardware Installation 2.6.3 S/PDIF-out Connector SPDIF out The system board is equipped with a S/PDIF-out connector. One card-edge bracket, mounted with the S/PDIF-out port, will be provided as an option. Install the card-edge bracket to the system chassis then connect the audio cable connector to J6. Make sure pin 1 of the audio cable connector is aligned with pin 1 of J6.

  • Page 44: Floppy Disk Drive Connector

    Hardware Installation 2.6.4 Floppy Disk Drive Connector The system board is equipped with a shrouded floppy disk drive connector that supports two standard floppy disk drives. To prevent improper floppy cable installation, the shrouded floppy disk header has a keying mechanism. The 34-pin connector on the floppy cable can be placed into the header only if pin 1 of the connector is aligned with pin 1 of the header.

  • Page 45: Serial Ata Connectors

    Hardware Installation 2.6.5 Serial ATA Connectors SATA 2 SATA 1 The system board is equipped with two Serial ATA connectors for connecting Serial ATA devices. Connect one end of the Serial ATA cable to J16 (SATA 1) or J15 (SATA 2) and the other end to your Serial ATA device.

  • Page 46: Ide Disk Drive Connector

    Hardware Installation 2.6.6 IDE Disk Drive Connector IDE 2 IDE 1 The system board is equipped with two 90 PCI IDE headers that will interface four Enhanced IDE (Integrated Drive Electronics) disk drives. To prevent improper IDE cable installation, each shrouded PCI IDE header has a keying mechanism.
  • Page 47 Hardware Installation Note: Refer to your disk drive user’s manual for information about selecting proper drive switch settings. Adding a Second IDE Disk Drive When using two IDE drives, one must be set as the master and the other as the slave. Follow the instructions provided by the drive manufacturer for setting the jumpers and/or switches on the drives.

  • Page 48: Irda Connector

    Hardware Installation 2.6.7 IrDA Connector IRTX Ground IRRX N. C. Connect your IrDA cable to connector J1 on the system board. Note: The sequence of the pin functions on some IrDA cable may be reversed from the pin function defined on the system board. Make sure to connect the cable to the IrDA connector according to their pin functions.

  • Page 49: Cooling Fan Connectors

    Hardware Installation 2.6.8 Cooling Fan Connectors Power Power Ground N. C. Ground Sense 2nd fan CPU fan Power Ground N. C. Chassis fan Connect the CPU fan’s cable connector to the CPU fan connector (J14) on the system board. The 2nd fan (J17) and chassis fan (J11) connectors are used to connect additional cooling fans.
  • Page 50 Hardware Installation 2.6.9 Chassis Open Connector Chassis signal Ground The system board supports the chassis intrusion detection function. Connect the chassis intrusion sensor cable from the chassis to the J3 connector. Whenever a chassis component has been removed, the sensor sends signal to J3 alerting you of a chassis intrusion event. To disable this function, place a jumper cap over J3.
  • Page 51 Hardware Installation 2.6.10 Wake-On-LAN Connector Ground +5VSB Your LAN card package should include a cable. Connect one end of the cable to the wakeup header on the card and the other end to location J9 on the system board. The network will detect Magic Packet and assert a wakeup signal to power-up the system.
  • Page 52 Hardware Installation 2.6.11 LED DIMM Standby Power LED DIMM Standby Power LED This LED will turn red when the system’s power is on or when it is in the Suspend state (Power On Suspend or Suspend to RAM). It will not light when the system is in the Soft-Off state. Important: If the DIMM Standby Power LED is lighted, you must power-off the system then turn off the power supply’s switch or unplug...

  • Page 53: Power Connectors

    Hardware Installation 2.6.12 Power Connectors 3.3V 3.3V -12V 3.3V Ground Ground PS-ON Ground Ground Ground Ground Ground PW-OK 5VSB +12V Ground Ground +12V +12V We recommend that you use a power supply that complies with the ATX12V Power Supply Design Guide Version 1.1. An ATX12V power supply has a standard 20-pin ATX main power connector and a 4-pin +12V power connector that must be inserted onto CN9 and CN8 connectors respectively.

  • Page 54: Front Panel Connectors

    Hardware Installation 2.6.13 Front Panel Connectors RESET SW HDD-LED PWR-LED PWR-BTN HDD-LED - HDD LED This LED will light when the hard drive is being accessed. RESET SW - Reset Switch This switch allows you to reboot without having to power off the system.

  • Page 55: Chapter 3 - Bios Setup

    BIOS Setup Chapter 3 - BIOS Setup 3.1 Award BIOS Setup Utility The Basic Input/Output System (BIOS) is a program that takes care of the basic level of communication between the processor and peripherals. In addition, the BIOS also contains codes for various advanced features found in this system board.

  • Page 56: Bios Setup

    BIOS Setup 3.1.1 Standard CMOS Features Use the arrow keys to highlight “Standard CMOS Features” and press <Enter>. A screen similar to the one below will appear. The settings on the screen are for reference only. Your version may not be identical to this one.
  • Page 57 BIOS Setup 3.1.1.3 IDE Channel 0 Master, IDE Channel 0 Slave, IDE Channel 1 Master and IDE Channel 1 Slave Move the cursor to the “IDE Channel 0 Master”, “IDE Channel 0 Slave”, “IDE Channel 1 Master” or “IDE Channel 1 Slave” field, then press <Enter>.
  • Page 58 BIOS Setup Access Mode For hard drives larger than 528MB, you would typically select the LBA type. Certain operating systems require that you select CHS or Large. Please check your operating system’s manual or Help desk on which one to select. Capacity Displays the approximate capacity of the disk drive.
  • Page 59 BIOS Setup 3.1.1.4 Drive A and Drive B These fields identify the types of floppy disk drives installed. None No floppy drive is installed 360K, 5.25 in. 5-1/4 in. standard drive; 360KB capacity 1.2M, 5.25 in. 5-1/4 in. AT-type high-density drive; 1.2MB capacity 720K, 3.5 in.
  • Page 60 BIOS Setup 3.1.1.7 Base Memory Displays the amount of base (or conventional) memory installed in the system. The value of the base memory is typically 512K for systems with 512K memory installed on the motherboard or 640K for systems with 640K or more memor y installed on the motherboard.

  • Page 61: Advanced Bios Features

    BIOS Setup 3.1.2 Advanced BIOS Features The Advanced BIOS Features allows you to configure your system for basic operation. Some entries are defaults required by the system board, while others, if enabled, will improve the performance of your system or let you set some features according to your preference. The screen above list all the fields available in the Advanced BIOS Features submenu, for ease of reference in this manual.
  • Page 62 BIOS Setup 3.1.2.1 CPU Feature Move the cursor to this field and press <Enter>. The following screen will appear. The settings on the screen are for reference only. Your version may not be identical to this one. Delay Prior To Thermal This field is used to select the time that would force the CPU to a 50% duty cycle when it exceeds its maximum operating temperature therefore protecting the CPU and the system board from...
  • Page 63 BIOS Setup Limit CPUID MaxVal The CPUID instruction of some newer CPUs will return a value greater than 3. The default is Disabled because this problem does not exist in the Windows series operating systems. If you are using an operating system other than Windows, this problem may occur. To avoid this problem, enable this field to limit the return value to 3 or lesser than 3.
  • Page 64 BIOS Setup 3.1.2.3 CPU L1 & L2 Cache This field speeds up the memory access. 3.1.2.4 CPU L3 Cache This field is used to enable or disable the CPU’s L3 cache. ® ® 3.1.2.5 Hyper-Threading Technology (for Intel Pentium 4 Processor with Hyper-Threading Technology only) ®...
  • Page 65 BIOS Setup 3.1.2.9 Boot Up Floppy Seek When enabled, the BIOS will check whether the floppy disk drive installed is 40 or 80 tracks. Note that the BIOS cannot distinguish between 720K, 1.2M, 1.44M and 2.88M drive types as they are all 80 tracks.
  • Page 66 BIOS Setup 3.1.2.13 Typematic Rate (Chars/Sec) This field allows you to select the rate at which the keys are accelerated. 3.1.2.14 Typematic Delay (Msec) This field allows you to select the delay between when the key was first depressed and when the acceleration begins. 3.1.2.15 Security Option This field determines when the system will prompt for the password - everytime the system boots or only when you enter the BIOS...
  • Page 67 BIOS Setup 3.1.2.19 HDD S.M.A.R.T. Capability The system board supports SMART (Self-Monitoring, Analysis and Reporting Technology) hard drives. SMART is a reliability prediction technology for ATA/IDE and SCSI drives. The drive will provide sufficient notice to the system or user to backup data prior to the drive’s failure.

  • Page 68: Advanced Chipset Features

    BIOS Setup 3.1.3 Advanced Chipset Features The settings on the screen are for reference only. Your version may not be identical to this one. This section gives you functions to configure the system based on the specific features of the chipset. The chipset manages bus speeds and access to system memory resources.
  • Page 69 BIOS Setup Manual If you want better system performance other than the one “by SPD”, select “Manual” then select the best option in the “CAS Latency Time” to “DRAM RAS# Precharge” fields. 3.1.3.2 CAS Latency Time This field is used to select the local memory clock periods. 3.1.3.3 Active to Precharge Delay The options are 5, 6, 7 and 8.
  • Page 70 BIOS Setup 3.1.3.8 Video BIOS Cacheable As with caching the system BIOS, enabling the Video BIOS cache will allow access to video BIOS addresssed at C0000H to C7FFFH to be cached, if the cache controller is also enabled. The larger the range of the Cache RAM, the faster the video performance.

  • Page 71: Integrated Peripherals

    BIOS Setup 3.1.4 Integrated Peripherals The settings on the screen are for reference only. Your version may not be identical to this one. 3.1.4.1 OnChip IDE Device Move the cursor to this field and press <Enter>. The following screen will appear. The settings on the screen are for reference only.
  • Page 72 BIOS Setup IDE HDD Block Mode Enabled The IDE HDD uses the block mode. The system BIOS will check the hard disk drive for the maxi- mum block size the system can transfer. The block size will depend on the type of hard disk drive. Disabled The IDE HDD uses the standard mode.
  • Page 73 BIOS Setup IDE Primary Master/Slave UDMA and IDE Secondary Master/ Slave UDMA These fields allow you to set the Ultra DMA in use. When Auto is selected, the BIOS will select the best available option after checking your hard drive or CD-ROM. Auto The BIOS will automatically detect the settings for you.
  • Page 74 BIOS Setup 3.1.4.2 Onboard Device Move the cursor to this field and press <Enter>. The following screen will appear. The settings on the screen are for reference only. Your version may not be identical to this one. USB Controller This field is used to enable or disable the onboard USB. USB 2.0 Controller If you are using USB 2.0, this field must be set to Enabled.
  • Page 75 BIOS Setup BIOS Flash Protect Enabled This option will protect the system from unnecessary updating or flashing of the BIOS. When enabled, it secures the BIOS therefore any updates to the BIOS will not take effect. Disabled Disables the “BIOS flash lock” function, allowing you to update or flash the BIOS any time needed.
  • Page 76 BIOS Setup 3.1.4.3 Super IO Device Move the cursor to this field and press <Enter>. The following screen will appear. The screen above list all the fields available in the Super IO Device submenu, for ease of reference in this manual. In the actual CMOS setup, you have to use the scroll bar to view the fields.
  • Page 77 BIOS Setup Any Key Press any key to power-on the system. Keyboard 98 When this option is selected, press the “wake up” key of the Windows 98 compatible keyboard to power-on the system. KB Power On Password Move the cursor to this field and press <Enter>. Enter your password.
  • Page 78 BIOS Setup RxD, TxD Active The options are Hi, Lo; Lo, Hi; Lo, Lo; and Hi, Hi. IR Transmission Delay If this field is Enabled, transmission of data will be slower. This is recommended when you encounter transmission problem with your device.
  • Page 79 BIOS Setup ECP Mode Use DMA This is used to select the DMA channel of the parallel port. PWRON After PWR-Fail When power returns after an AC power failure, the system’s power is off. You must press the Power button to power-on the system. When power returns after an AC power failure, the system will automatically power-on.

  • Page 80: Power Management Setup

    BIOS Setup 3.1.5 Power Management Setup The Power Management Setup allows you to configure your system to most effectively save energy. The settings on the screen are for reference only. Your version may not be identical to this one. 3.1.5.1 ACPI Function This function should be enabled only in operating systems that ®...
  • Page 81 BIOS Setup 3.1.5.3 Run VGABIOS if S3 Resume When this field is set to Auto, the system will initialize the VGA BIOS when it wakes up from the S3 state. This can be configured only if the “ACPI Suspend Type” field is set to “S3(STR)”. 3.1.5.4 Power Management This field allows you to select the type (or degree) of power saving by changing the length of idle time that elapses before the HDD...
  • Page 82 BIOS Setup 3.1.5.9 Suspend Mode When the system enters the Suspend mode, the CPU and onboard peripherals will be shut off. 3.1.5.10 HDD Power Down This is selectable only when the Power Management field is set to User Define. When the system enters the HDD Power Down mode according to the power saving time selected, the hard disk drive will be powered down while all other devices remain active.
  • Page 83 BIOS Setup 3.1.5.13 Wake-Up By PCI Card Enabled This field should be set to Enabled only if your PCI card such as LAN card or modem card uses the PCI PME (Power Management Event) signal to remotely wake up the system. Access to the LAN card or PCI card will cause the system to wake up.
  • Page 84 BIOS Setup 3.1.5.18 Date (of Month) Alarm The system will power-on everyday according to the time set in the “Time (hh:mm:ss) Alarm” field. 1-31 Select a date you would like the system to power-on. The system will power-on on the set date, and time set in the “Time (hh:mm:ss) Alarm”...
  • Page 85 BIOS Setup 3.1.6 PnP/PCI Configurations This section describes configuring the PCI bus system. It covers some very technical items and it is strongly recommended that only experienced users should make any changes to the default settings. The settings on the screen are for reference only. Your version may not be identical to this one.
  • Page 86 BIOS Setup 3.1.6.3 IRQ Resources Move the cursor to this field and press <Enter>. The “IRQ-3” to “IRQ-15” fields will appear. Set each system interrupt to either PCI Device or Reserved. The settings on the screen are for reference only. Your version may not be identical to this one.

  • Page 87: Pc Health Status

    BIOS Setup 3.1.7 PC Health Status The settings on the screen are for reference only. Your version may not be identi- cal to this one. 3.1.7.1 Current System Temperature, Current CPU Temperature and Current CPU Fan Speed These fields will show the internal temperature of the system, current temperature of the CPU and the current CPU fan speed in RPM (Revolutions Per Minute).
  • Page 88 BIOS Setup 3.1.8 Frequency/Voltage Control The settings on the screen are for reference only. Your version may not be identical to this one. 3.1.8.1 CPU Clock Ratio This field is used to select the frequency ratio of the processor. Important: The frequency ratio of some processors may have been locked by the manufacturer.
  • Page 89 BIOS Setup 3.1.9 Load Fail-Safe Defaults The “Load Fail-Safe Defaults” option loads the troubleshooting default values permanently stored in the ROM chips. These settings are not optimal and turn off all high performance features. You should use these values only if you have hardware problems. Highlight this option in the main menu and press <Enter>.

  • Page 90: Load Optimized Defaults

    BIOS Setup 3.1.10 Load Optimized Defaults The “Load Optimized Defaults” option loads optimized settings from the BIOS ROM. Use the default values as standard values for your system. Highlight this option in the main menu and press <Enter>. Type <Y> and press <Enter> to load the Setup default values.

  • Page 91: Set Supervisor Password

    BIOS Setup 3.1.11 Set Supervisor Password If you want to protect your system and setup from unauthorized entry, set a supervisor’s password with the “System” option selected in the Advanced BIOS Features. If you want to protect access to setup only, but not your system, set a supervisor’s password with the “Setup”...

  • Page 92: Set User Password

    BIOS Setup 3.1.12 Set User Password If you want another user to have access only to your system but not to setup, set a user’s password with the “System” option se- lected in the Advanced BIOS Features. If you want a user to enter a password when trying to access setup, set a user’s password with the “Setup”...
  • Page 93 BIOS Setup 3.1.13 Save & Exit Setup When all the changes have been made, highlight “Save & Exit Setup” and press <Enter>. Type “Y” and press <Enter>. The modifications you have made will be written into the CMOS memory, and the system will reboot. You will once again see the initial diagnostics on the screen.

  • Page 94: Exit Without Saving

    BIOS Setup 3.1.14 Exit Without Saving When you do not want to save the changes you have made, highlight “Exit Without Saving” and press <Enter>. Type “Y” and press <Enter>. The system will reboot and you will once again see the initial diagnostics on the screen. If you wish to make any changes to the setup, press <Ctrl>...

  • Page 95: Updating The Bios

    BIOS Setup 3.2 Updating the BIOS To update the BIOS, you will need the new BIOS file and a flash utility, AWDFLASH.EXE. Please contact technical support or your sales representative for the files. 1. Save the new BIOS file along with the flash utility AWDFLASH.EXE to a floppy disk.
  • Page 96 BIOS Setup 6. The following will appear. Do You Want to Save BIOS (Y/N) This question refers to the current existing BIOS in your system. We recommend that you save the current BIOS and its flash utility; just in case you need to reinstall the BIOS. To save the current BIOS, press <Y>...

  • Page 97: Chapter 4 - Supported Softwares

    Supported Software Chapter 4 - Supported Software 4.1 Drivers, Utilities and Software Applications The CD that came with the system board contains drivers, utilities and software applications required to enhance the performance of the system board. Inser t the CD into a CD-ROM drive. The autorun screen (Mainboard Utility CD) will appear.

  • Page 98: Supported Software

    Supported Software 4.1.1 Intel Chipset Software Utility ® The Intel Chipset Software Utility is used for updating Windows INF files so that the Intel chipset can be recognized and configured properly in the system. To install the utility, please follow the steps below. 1.
  • Page 99 Supported Software 4.1.2 Intel 865G Graphics Drivers To install the driver, please follow the steps below. 1. Click “Intel 865G Graphics Drivers” on the main menu. The following screen will appear. 2. Follow the prompts on the screen to complete installation. 3.

  • Page 100: Realtek Lan Drivers

    Supported Software 4.1.3 Realtek LAN Drivers To install the driver, please follow the steps below. 1. Click “Realtek LAN Drivers” on the main menu. The following screen will appear. 2. Follow the prompts on the screen to complete installation. 3. Reboot the system for the driver to take effect. The LAN driver for Windows NT 4.0 does not suppor t “Autorun”.
  • Page 101 Supported Software 4.1.4 AC’97 Audio Drivers To install the driver, please follow the steps below. 1. Click “AC’97 Audio Drivers” on the main menu. The following screen will appear. 2. Follow the prompts on the screen to complete installation. 3. Reboot the system for the driver to take effect.
  • Page 102 Supported Software 4.1.5 Winbond HW Doctor Winbond HW Doctor is capable of monitoring the system’s hard- ware conditions such as the temperature of the CPU and system, voltage, and speed of the cooling fans. It also allows you to manu- ally set a range to the items being monitored.
  • Page 103 Supported Software 4.1.6 Microsoft DirectX 9.0C To install, please follow the steps below. 1. Click “Microsoft DirectX 9.0C” on the autorun screen. The follow- ing screen will appear. 2. Click “I accept the agreement” then click “Next”. 3. Follow the prompts on the screen to complete installation. 4.

  • Page 104: Installation Notes

    Supported Software 4.1.7 Intel USB 2.0 Drivers The Intel chipset does not support USB 2.0 drivers for Windows 98 SE and Windows ME. ® Windows ® If your Windows XP CD already includes Service Pack 1, the USB 2.0 driver will automatically install when you install the operating system.

  • Page 105: Watchdog Timer

    Watchdog Timer Appendix A - Watchdog Timer A.1 Watchdog Timer The following parameters are references for setting the time interval of the Watchdog Timer function. The system will regularly be “cleared” according to the set time interval. If the system hangs or fails to function, it will also reset according to the time interval so that your system will continue to operate.

  • Page 106: Appendix B - Enabling The Hyper-Threading Technology

    Enabling Hyper-Threading Technology Appendix B- Enabling Hyper-Threading Technology B.1 Enabling Hyper-Threading Technology To enable the functionality of the Hyper-Threading Technology, please follow the requirements and steps below. Basically, the following ® ® presumes that you have already installed an Intel Pentium Processor with Hyper-Threading Technology.
  • Page 107 Enabling Hyper-Threading Technology Click the General tab. The processor shown under Computer should resemble the one shown below. Now click the Hardware tab then click Device Manager. The items shown under Computer and Processors should resemble the ones shown below.
  • Page 108 Enabling Hyper-Threading Technology Lastly, press the <Ctr l> <Alt> and <Del> keys simultaneously. The Windows Task Manager dialog box will appear. Click the Performance tab. The diagram under CPU Usage History should resemble the one shown below.

  • Page 109: Appendix C - System Error Messages

    System Error Message Appendix C - System Error Message When the BIOS encounters an error that requires the user to correct something, either a beep code will sound or a message will be displayed in a box in the middle of the screen and the message, PRESS F1 TO CONTINUE, CTRL-ALT-ESC or DEL TO ENTER SETUP, will be shown in the information box at the bottom.
  • Page 110 System Error Message setting than indicated in Setup. Determine which setting is correct, either turn off the system and change the jumper or enter Setup and change the VIDEO selection. FLOPPY DISK(S) fail (80) Unable to reset floppy subsystem. FLOPPY DISK(S) fail (40) Floppy type mismatch.

  • Page 111: Appendix D - Troubleshooting

    Troubleshooting Appendix D - Troubleshooting D.1 Troubleshooting Checklist This chapter of the manual is designed to help you with problems that you may encounter with your personal computer. To efficiently troubleshoot your system, treat each problem individually. This is to ensure an accurate diagnosis of the problem in case a problem has multiple causes.

  • Page 112: Power Supply

    Troubleshooting The picture seems to be constantly moving. 1. The monitor has lost its vertical sync. Adjust the monitor’s vertical sync. 2. Move away any objects, such as another monitor or fan, that may be creating a magnetic field around the display. 3.

  • Page 113: Hard Drive

    Troubleshooting Hard Drive Hard disk failure. 1. Make sure the correct drive type for the hard disk drive has been entered in the BIOS. 2. If the system is configured with two hard drives, make sure the bootable (first) hard drive is configured as Master and the second hard drive is configured as Slave.

  • Page 114: Serial Port

    Troubleshooting Serial Port The serial device (modem, printer) doesn’t output anything or is outputting garbled characters. 1. Make sure that the serial device’s power is turned on and that the device is on-line. 2. Verify that the device is plugged into the correct serial port on the rear of the computer.
