Summary of Contents for CEL 10.8v Li-ion
- Page 1 10.8v Li-ion Cordless Multi2PRO User Manual...
- Page 2 THANK YOU Thank you for investing in a CEL product. The 10.8v Li-Ion Cordless Multi2PRO has been engineered and made to demanding high quality standards; ease of operation and safety have taken a major role in development. Proper care of your product will give you years of trouble-free use.
-
Page 3: Table Of Contents
Contents Important Safety Notes GETTING Unpacking Description of Parts STARTED Battery Charging Safety Notes Fitting Tools OPERATION Tools Operating Overload and Low Voltage Protection 10.0 Maintenance 11.0 Storage CARE 12.0 Environment 13.0 14.0 Technical Specifications Manual Version: 2009-0A Designed and edited in the UK Printed in China... -
Page 4: Important Safety Notes
Important Notes Description of symbols The rating plate on your tool may show symbols. These represent important information about the product or instructions on its use. General Read Keep Dry Protect Keep Flying Sharp Hazard Instructions Eyes, Ears, Bystanders Debris Blades Lungs Away... - Page 5 ~ Use the battery only in conjunction with your Cel power tool. This measure alone protects the battery against dangerous overload. ~ Wear protective gloves when changing application tools/accessories. Application tools/accessories become hot after prolonged usage.
-
Page 6: Unpacking
Unpacking... -
Page 7: Description Of Parts
Description of Parts Read all safety warnings and all Charger Unit instructions. Hex Key Failure to follow the warnings and instructions may result in electric shock, fire Locking Bolt and/or serious injury. Blade Adaptor Washer Intended Use Locking Washer The machine is intended for sawing and Universal Saw MT1-AC11 cutting -using the specified accessories- wooden materials, plastic, gypsum, non-... -
Page 8: Battery
Do not exert any force. WARNING Use only the battery charger supplied with this tool or an identical replacement. Use only original Cel lithium Battery charge indicator ion batteries with the voltage listed on the GREEN YELLOW nameplate of your power tool. - Page 9 Charging CHARGER LIGHTS INDICATOR Only use supplied POWER ON GREEN+GREEN battery and charger or CHARGING GREEN+RED identical CHARGED GREEN+GREEN replacements. ERROR FLASHING GREEN 1. Place the charger in a safe position The lithium ion battery can be charged at away from moisture, heat or any hazard any time without reducing its service life.
-
Page 10: Safety Notes
Safety Notes Before Starting Work Materials containing asbestos may only be worked by specialists. - Use dust extraction whenever possible. - Provide for good ventilation of the Sharp blades, heat buildup and flying working place. debris are a danger to user and - It is recommended to wear a P2 bystanders. -
Page 11: Fitting Tools
Fitting Tools If required, remove The sanding plates an already mounted are fitted with Velcro application backing for quick tool/accessory. and easy fastening Loosen the screw of sanding sheets with the hex key and with Velcro remove the adhesion. tool/accessory. Be Before attaching the sure to clear any sanding sheet , free... -
Page 12: Tools
Tools Rasp Carbide Rasp Coarse grinding or rasping, aggressive material Finger removal in small, tight areas. MT1-AC03 Triangular Carbide Coarse grinding or rasping, aggressive material Rasp removal over larger areas. MT1-AC04 Scrape Removing old vinyl, wood or other floor Stainless Steel coverings, paint and coatings, residues and MT1-AC14 Scraper... - Page 13 Linear and Plunge cutting. Flat on one side MT1-AC13 so you can cut into corners and flush against adjoining surfaces. More tools and uses are available at www.cel-global.com Please let us know if you have any ideas or new uses for the Multi2PRO...
-
Page 14: Operating
Operating Switching On and Off ~ When sawing light building To start the machine, push materials, observe the statutory the On/Off switch forward provisions and the recommendations so that "ON" is indicated of the material suppliers. on the switch. ~ Plunge cuts may only be To switch off the machine, applied to soft materials, such push the On/Off switch... - Page 15 The removal rate and the sanding for metal should not be used for pattern are primarily determined by other materials. the choice of sanding sheet, the Use only original CEL sanding preset oscillation rate and the accessories. applied pressure. Flawless sanding sheets achieve the...
-
Page 16: Overload And Low Voltage Protection
Overload and Low Voltage Protection Overload Protection When the unit is overloaded (e.g.: the product is working too hard or the blade is jammed) the current will increase rapidly, this triggers the auto cut-off, indicated by a RED flashing LED. To reset, slide the power switch to the “OFF” position and restart again after re-adjusting to a proper cutting pressure/angle as well as choosing a higher torque setting. -
Page 17: Storage
Storage 11.0 Store the tool, instruction manual and accessories in a secure, dry place. In this way you will always have all the information and parts ready to hand. Never store the tool with a flat battery. The battery should ideally be stored between 10ºC and 24ºC (50ºF) and (75ºF). Environment 12.0 When the time comes to dispose of this product please consider the environment... -
Page 18: Faq
Turn off, wait, then turn on advice or help? again. Ask at your retailer or visit www.cel-global.com The Multi2PRO wont start, what’s wrong? How long is the warranty and what is a)Clean as described in the maintenance section. -
Page 19: Technical Specifications
- approx (14x10x4") Weight - 0.88Kg (1.9lbs) (not including charger) Product Code - MT1 If you experience any problems with the product please contact email: sales@cel-global.com phone UK: +44 (0) 8453 88 97 69 www.cel-global.com GENERAL HAZARD BEWARE OF FLYING SAFETY ALERT... - Page 20 C Enterprise Ltd C Enterprise Limited www.cel-global.com info@cel-global.com • • • China • Europe • Australia • Japan...
