Picture; Adjust - NEC MULTEOS M401 User Manual

Setting


BRIGHTNESS
CONTRAST
SHARPNESS
BLACK LEVEL
TINT
COLOR
COLOR TEMPERATURE
COLOR CONTROL
GAMMA SELECTION
NATIVE
2.2
2.4
S GAMMA
DICOM SIM.
PROGRAMMABLE
MOVIE SETTINGS
NOISE REDUCTION
TV, VIDEO1, VIDEO2, S-VIDEO inputs only
FILM MODE
HDMI, DVD/HD1, DVD/HD2, SCART, VIDEO1, VIDEO2, S-VIDEO, TV* inputs only
ADAPTIVE CONTRAST Sets the level of adjustment for dynamic contrast.
HDMI, DVD/HD1, DVD/HD2, SCART, VIDEO1, VIDEO2, S-VIDEO, TV* inputs only
PICTURE MODE
PICTURE RESET

ADJUST

AUTO SETUP
VGA, RGB/HV inputs only
AUTO ADJUST
VGA, RGB/HV inputs only
H POSITION
All inputs except DVI, HDMI, DPORT
V POSITION
All inputs except DVI, HDMI, DPORT
CLOCK
VGA, RGB/HV inputs only
CLOCK PHASE
VGA, RGB/HV, DVD/HD1, DVD/HD2, SCART inputs only
*: The product you purchased may not have this feature.
Adjusts the overall image and background brightness. Press + or - to adjust.
Note: When AMBIENT1 or AMBIENT2 is selected in picture mode, this function cannot changed.
Adjusts the image brightness in relationship to the background. Press + or - to adjust.
Note: The sRGB picture mode is standard and cannot be changed.
Adjusts the crispness of the image. Press + or - to adjust.
Adjusts the image brightness in relationship to the background. Press + or - to adjust.
Note: The sRGB picture mode is standard and cannot be changed.
Adjusts the tint of the screen. Press + or - to adjust.
Note: The sRGB picture mode is standard and cannot be changed.
Adjusts the color depth of the screen. Press + or - to adjust.
Note: The sRGB picture mode is standard and cannot be changed.
Adjusts the color temperature of the entire screen. A low color temperature will make the screen
reddish. A high color temperature will make the screen bluish. If TEMPERATURE needs further
adjustment, the individual R/ G/ B/ levels of the white point can be adjusted. To adjust the
R/G/B levels, CUSTOM must be showing as the COLOR TEMP selection.
Note: The sRGB picture mode is set to a predefined 6500 K standard and cannot be changed.
Adjusts the levels of the Red, Yellow, Green, Cyan, Blue, Magenta and Saturation.
Note: The sRGB picture mode is standard and cannot be changed.
Select a display gamma for best picture quality.
Note: The sRGB picture mode is standard and cannot be changed.
Gamma correction is handled by the LCD panel.
Typical display gamma for use with a PC.
Good for video (TV, DVD, etc.)
Special gamma for certain types of movies. Raises the dark parts and lowers the light parts
of the image (S-Curve).
DICOM GSDF curve simulated for LCD type.
A programmable gamma curve can be loaded using NEC optional software.
Adjusts the amount of noise reduction. Press + or - to adjust.
Selects Film mode.
Selects picture mode, [HIGHBRIGHT], [STANDARD], [sRGB], [CINEMA], [AMBIENT1] or
[AMBIENT2]. See page 18.
Resets the following settings within the PICTURE menu back to factory setting:
BRIGHTNESS, CONTRAST, SHARPNESS, BLACK LEVEL, TINT, COLOR, COLOR
TEMPERATURE, COLOR CONTROL , GAMMA SELECTION, MOVIE SETTINGS.
Automatically adjusts Screen Size, H position, V position, Clock, Clock Phase and White Level.
H Position, V Position and Clock Phase are adjusted automatically upon power on.
Controls the horizontal position of the image within the Display area of the LCD.
Press + to move right. Press - to move left.
Controls the vertical position of the image within the Display area of the LCD.
Press + to move up. Press - to move down.
Press + to expand the width of the image on the right of the screen.
Press - to narrow the width of the image on the left.
Adjusts the visual "noise" on the image.
English-20
Default
70
50
50* 2
50
50
50* 2
10000K
0
NATIVE* 2
(except sRGB
setting)
6* 2
AUTO* 2
OFF
STANDARD
-
-
OFF
-
-
-
-
*2: depends on signal input
