VP-1124A/VP-1124A-EC/VP-1124A-UK
SPECIFICATIONS
Input:
100-250VAC, 50/60Hz
IEC 320 input receptacle
Output:
24VDC, 1A Regulated
5.5mm x 2.5mm connector center
positive (mating wire assembly
included)
Dimensions: 4.125" H x 1.625" W x 1.375" D
(102mm H x 40mm W x 30mm D)
Weight:
0.9 lbs. (0.4 kg)
Mounting:
Wall or shelf, mount near an
electrical outlet (wall mount
hardware included)
Features:
Output voltage indicator
FOR INDOOR USE ONLY
OUTPUT CONNECTIONS
Connect "+" wire to connection labeled GND
on Valcom equipment
Connect "-" wire to connection labeled -24V
on Valcom equipment
REGULATORY INFORMATION
UL, cUL and CE Approvals
Meets VDE and FCC Class B Regulations
POWER SUPPLY
TECHNICAL ASSISTANCE
When trouble is reported, verify that AC power is
being supplied to the unit. To test the power
supply, remove all output connections, and
measure the output voltage with a meter. If no
voltage is measured, replace the unit.
Assistance in troubleshooting is available from
the factory. When calling, you should have a
VOM and a test set available and be calling from
the job site. Call (540) 563-2000 and ask for
Technical Support, or visit our website at
http://www.valcom.com.
Valcom equipment is not field repairable.
Valcom, Inc. maintains service facilities in
Roanoke, VA. Should repairs be necessary,
attach a tag to the unit clearly stating your
company name, address, phone number,
contact person and the nature of the problem.
Send the unit to:
1
Valcom, Inc.
Repair and Return Dept.
5614 Hollins Road
Roanoke, VA 24019-5056
Issue 2
947702
