Connecting the Battery Pack

Unlock the rear cover by pressing down on the spring lock at the
top of the cover.
Remove the cover. For shipment from the factory, the battery is left
out of the MX-5000. Place the battery into the battery compart-
ment, making sure you align the contacts on the battery to the con-
tacts on the MX-5000. The battery will snap into place when
aligned properly.
Replace the cover and snap it into place.

Using the Charging Base

Plug the 6V DC adapter into a power outlet
and into the back of the charging base.
Gently place the MX-5000 into the cradle of
the charging base. It automatically aligns
itself to the contacts on the charging base.
The status indicator should immediately light.
Red indicates that it is charging. Blue shows
that it is fully charged. There is no harm in
leaving the MX-5000 on its charging base
whenever it is not in use.

Two Way via Wi-Fi

To use the MX-5000 with any two way companion product, the
MX-5000 must be configured by your installer to be part of a LAN
(local area network) via a Wi-Fi b/g access point or router. This is
not user configurable. If you have any questions, consult with your
custom installer.
MX-5000 T W
WO
Page 2
T S
AY OUCH CREEN
Red indicates charging, Blue that
the remote is fully charged.
