PRODUCT OVERVIEW

Master Keys
8 backlit buttons provide
"One Touch to Music"
Soft Keys
3 backlit buttons
that change function
depending upon the
source selected
VOL+/VOL–
2 backlit buttons adjust
volume up or down
Cursor Keys
and Select Key
5 backlit buttons provide
navigation of menus,
playlists and favorites
OFF
Backlit button turns zone
or system off
12V DC
Power Supply
Figure 1. IntelliControl ICS iRemote
2
iPod
The White Album
The Beatles
Revolution
Shuffle Menu
Battery Indicator
Display – Backlit LCD
displays system information
from iPod, Digital Audio
Broadcasting Radio and AM/
FM and functions associated
with "Soft Keys"
PREV/NEXT
2 backlit buttons move to
Next or Previous/Track
or Station
Alphanumeric Keys
Provide direct access
tuning, numeric selection
of track and alphabetic
search for iPod
MUTE
Backlit button mutes/
un-mutes audio output
to zone
Niles System Settings
Provides access to system
settings: audio (bass,
treble, balance), sleep
timer, alarm clock, etc.
Charging Base
