Splawn Amplification quickrod Owner's Manual page 7

N
ITRO
by Splawn
OUT/+4 db
IN/-10 db
A B
LEVEL
FOOTSWITCH
1. Footswitch A -TRS 1/4" Jack Tip switches Solo Volume-- Ring switches OD1/OD2
2. Footswitch B -TRS 1/4" Jack Tip switches Clean/Overdrive
3.Series Effects Loop Level Switch
4. Series Effects Loop Bypass Switch
5. Series Effects Loop Return Jack
6. Series Effects Loop Send Jack
7. Half Power Switch -Disconnects the outside power tubes
8. Speaker Outputs -Connection to the speaker cabinet (never run a tube amp without a speaker)
9. Impedence Selector
10. Main Voltage Selector
11. Main Fuse -Use 4 amp 250 volt fuse for 100 or 120 volt setting Use 2 amp 250 volt fuse for 220/240 volt setting
12. High Tension Fuse
1. Pre-amp tube - 12AX7 2nd gain stage of the clean channel
2. Pre-amp tube -12AX7 Side A 1st gain stage for clean & OD channels -- Side B 2nd gain stage of OD channel
3. Pre-amp tube -12AX7 Side A 3rd gain stage of OD channel -- Side B 4th gain stage of OD channel
4. Pre-amp tube -12AX7 Phase Inverter
5. Power Tube - EL34/KT77 -- KT88/6550
6. Power Tube - EL34/KT77 -- KT88/6550
7. Power Tube - EL34/KT77 -- KT88/6550
8. Power Tube - EL34/KT77 -- KT88/6550
EFFECTS LOOP
OUT/BYPASS
IN/ACTIVE
BYPASS RETURN SEND
Nitro Rear Panel Controls
-+4db -10db switch for matching line levels to effects units
-True bypass switch
-Connection from the output of the effects device
-Connection to the input of the effects device
always set the amps impedence to half of the speaker cabs impedence when using half power
-4/8/16 ohm selector to match the load of the speaker cabinet
-100/120/220/240 voltage selector to match the input voltage
-Use 1 amp 250 volt Slow Blow Fuse
1 2 3 4
HALF POWER SPEAKERS
FULL POWER 100 WATT RMS
5 6
Tube Layout
SELECTOR MAINS INPUT MAINS FUSE
8
4 16
100v-120v
220v-240v
OUTPUT VOLTAGE
7 8
HT FUSE
4A 120V 1A Slow-Blow
2A 220/240V
