Splawn Amplification quickrod Owner's Manual page 11

C
OMPETITION
by Splawn
OUT/+4 db
IN/-10 db
A B
FOOTSWITCH
1. Footswitch A -TRS 1/4" Jack Tip switches Solo Volume-- Ring switches OD1/OD2
2. Footswitch B -TRS 1/4" Jack Tip switches Clean/Overdrive-- Ring switches Mode Switch
3.Series Effects Loop Level Switch
4. Series Effects Loop Bypass Switch
5. Series Effects Loop Return Jack
6. Series Effects Loop Send Jack
7. Competition Pentode Triode Switch
Pro Stock Half Power Switch
8. Speaker Outputs -Connection to the speaker cabinet (never run a tube amp without a speaker)
9. Impedence Selector
10. Main Voltage Selector
11. Main Fuse -Use 4 amp 250 volt fuse for 100 or 120 volt setting Use 2 amp 250 volt fuse for 220/240 volt setting
12. High Tension Fuse
1. Pre-amp tube -12AX7 Side A 1st gain stage for OD channel -- Side B 2nd gain stage of OD channel
2. Pre-amp tube -12AX7 Side A 3rd gain stage of OD channel -- Side B 4th gain stage of OD channel
3. Pre-amp tube -12AX7 Phase Inverter
4. Power Tube - EL34B -- KT88/6550 (Pro Stock)
5. Power Tube - EL34B -- KT88/6550 (Pro Stock) (Competition)
6. Power Tube - EL34B -- KT88/6550 (Pro Stock) (Competition)
7. Power Tube - EL34B -- KT88/6550 (Pro Stock)
EFFECTS LOOP
OUT/BYPASS
IN/ACTIVE
LEVEL BYPASS RETURN SEND
Competition & Pro Stock Rear Panel Controls
-+4db -10db switch for matching line levels to effects units
-True bypass switch
-Connection from the output of the effects device
-Connection to the input of the effects device
-Pentode=Full Power 50 watts Triode=Half Power 25 watts
Disconnects the outside power tubes
-4/8/16 ohm selector to match the load of the speaker cabinet
-100/120/220/240 voltage selector to match the input voltage
-Use 1 amp 250 volt Slow Blow Fuse
1 2
HALF POWER SPEAKERS
FULL POWER
always set the amps impedence to half of the speaker cabs impedence when using half power
4 5
3
Tube Layout
SELECTOR MAINS INPUT MAINS FUSE
8
4 16
100v-120v
220v-240v
OUTPUT VOLTAGE
6 7
HT FUSE
4A 120V 1A Slow-Blow
2A 220/240V
