Thank you for purchasing your new Splawn amplifier. We have put together a little information that will help you
understand the amp and all of its functions. All of our amps are built in our shop in Dallas NC right here in the USA. We
build all of our speaker cabs and head boxes in house. Some parts of the amplifier are out sourced such as the
chassis's, circuit boards and transformers. The transformers are custom wound by Heyboer and are also made in the
USA. We hope that this amplifier will give you years of tonal pleasure.
POWER STANDBY
ON
1. Power Switch -Switches main AC power on or off
2. Standby Switch -Switches the high voltage on or off
3. Presence Control -High frequency control on the output section
4. Bass Control -Controls the bass frequency on the overdrive channel
5. Middle Control -Controls the middle frequency on the overdrive channel
6. Treble Control -Controls the treble frequency on the overdrive channel
7. Solo Volume -Switchable volume control on the overdrive channel activated by the footswitch
8. Master Volume -Controls the overall volume of the overdrive channel
9. Gain Control -Controls the amout of pre-amp gain to the overdrive channel
10. Mode Switch -Three position switch that gives different pre-amp styles
(1st gear Classic ) (2nd gear Hot rodded) (3rd gear Super Hot rodded)
_______________________________________OVERDRIVE CHANNEL_______________________________
PRESENCE BASS
ON
Competition & Pro Stock Front Panel Controls
Splawn Amplification
115 South Gaston St.
Dallas, NC 28034
www.splawnguitars.com
MIDDLE TREBLE SOLO
C
Splawn
by
OMPETITION
704-922-0020
VOLUME GAIN MODE
3rd Gear
2nd Gear
1st Gear
