Klipsch CP-4 Specifications

CP-4
COMPACT, HIGH PERFORMANCE
INDOOR/OUTDOOR LOUDSPEAKER
The Klipsch Compact Performance CP-4 mountable cabinet speaker,
with its weather-resistant design, is as much at home on the patio as
it is placed on a shelf or mounted on the wall indoors. The proprietary
90° x 90° Tractrix® Horn provides for unmatched low-distortion clarity
and detail while the long-throw woofer combines with front-firing
ports for amazingly powerful low frequency response wherever they
are located. Traditional Klipsch efficiency provides maximum output
with minimum wattage.
QUICK, EASY INSTALLATION
The CP-4 makes a highly aesthetic statement with its smaller size
and ability to mount closer to a wall or even be tucked into a
corner with its V-shaped rear profile. Tool-free angle adjustment
makes positioning a breeze. The unique, solid mounting bracket
assures a fast, easy, one-screwdriver installation. Front speaker wire
terminals combined with a pull-through wire channel provide a quick
connection with an uncluttered look. The CP-4 will also look great
placed on a shelf or stand without using the supplied bracket.
MULTIPURPOSE DESIGN
The Klipsch CP-4 can function as stereo mains or surrounds or be
mounted outdoors for warmer weather enjoyment with its solid,
mineral-filled cabinet and stainless steel hardware. Sold in pairs and
offered in Black or White with the ability to custom paint, the CP-4
complements any indoor or outdoor décor.
3502 Woodview Trace Indianapolis, IN 46268 | klipsch.com
All specifications are subject to change without notice.
©2014 Klipsch Group, Inc. Klipsch is a wholly-owned subsidiary of VOXX Intertnational Corporation
SPECIFICATIONS CP-4
Frequency Response 80Hz-22kHz +3/-6 dB
1
Power Handling 50 w (200 peak)
2
Maximum Continuous Output 3 105dB
Sensitivity 91 dB @ 1 watt/1 meter
4
Nominal Impendance 8 ohms
Tweeter .75" (1.9cm) aluminum dome tweeter
High Frequency Horn 90° x 90° Tractrix® Horn
Woofer 3.5" (8.9cm) long-throw IMG woofer
Crossover Frequency 3.2kHz 12dB octave
Enclosure Type Bass-reflex via dual front-firing ports
Anti-resonant, mineral-filled PPC;
Enclosure Material
paintable, weather resistant
Grille Powder-coated aluminum w/rotatable logo
Terminals Front baffle mounted accessed via rear pull-through
Speaker Weight 4.8 lbs. (2.2kg)
Speaker Dimensions 8.8"(22.4cm) H x 5.5"(14.0cm) W x 4.7"(11.9cm) D
Speaker Dimension
8.8"(22.4cm) H x 5.5"(14.0cm) W x 5.5"(14.0cm) D
w/ Wall Mount
Other Mounting Options 1/4", 20-thread insert on cabinet rear
Finishes White/Black enclosure and grille
Wire Gauge Accommodated Up to 16AWG
Sold As Speaker pairs
S
Included in Carton Mounting Template, Bracket Retaining Screws (x4),
Safety Instructions, Grille Removal Tool
Carton Dimensions 12.6"(320mm) H x 17.3"(440mm) W x 9"(230mm) D
Total Carton Weight 10.14 lbs.(4.6kg)
Item Number 1060305 (white), 1016295 (black)
UPC 743878027013 (white), 743878025965 (black)
Built From 2014
1 3M anechoic
2 IEC 268-5 filtered pink noise with 6dB crest factor
3 Calculated at 1M at power handling power input
4 SPL at 1M, anechoic with 2.83V input
peakers (x2), Grilles (x2), Brackets (x2), Manual,
