Klipsch CP-6 Specifications

CP-6
COMPACT, HIGH PERFORMANCE
INDOOR/OUTDOOR LOUDSPEAKER
The Klipsch Compact Performance CP-6 mountable cabinet speaker,
with its weather-resistant design, is as much at home on the patio as
it is placed on a shelf or mounted on the wall indoors. The proprietary
90° x 90° Tractrix® Horn provides for unmatched low-distortion clarity
and detail while the long-throw woofer combines with front-firing
ports for amazingly powerful low frequency response wherever they
are located. Traditional Klipsch efficiency provides maximum output
with minimum wattage.
QUICK, EASY INSTALLATION
The CP-6 makes a highly aesthetic statement with its smaller size
and ability to mount closer to a wall or even be tucked into a
corner with its V-shaped rear profile. Tool-free angle adjustment
makes positioning a breeze. The unique, solid mounting bracket
assures a fast, easy, one-screwdriver installation. Front speaker wire
terminals combined with a pull-through wire channel provide a quick
connection with an uncluttered look. The CP-6 will also look great
placed on a shelf or stand without using the supplied bracket.
MULTIPURPOSE DESIGN
The Klipsch CP-6 can function as stereo mains or surrounds or be
mounted outdoors for warmer weather enjoyment with its solid,
mineral-filled cabinet and stainless steel hardware. Sold in pairs and
offered in Black or White with the ability to custom paint, the CP-6
complements any indoor or outdoor décor.
3502 Woodview Trace Indianapolis, IN 46268 | klipsch.com
All specifications are subject to change without notice.
©2014 Klipsch Group, Inc. Klipsch is a wholly-owned subsidiary of VOXX Intertnational Corporation
SPECIFICATIONS CP-6
Frequency Response 70Hz-22kHz +3/-6 dB
1
Power Handling 75 w (300 peak)
2
Maximum Continuous Output 111dB
3
Sensitivity 4 94 dB @ 1 watt/1 meter
Nominal Impendance 8 ohms
Tweeter .75" (1.9cm) aluminum dome tweeter
High Frequency Horn 90° x 90° Tractrix® Horn
Woofer 5.25" (13.3cm) long-throw IMG woofer
Crossover Frequency 3kHz 12dB octave
Enclosure Type Bass-reflex via dual front-firing ports
Anti-resonant, mineral-filled PPC;
Enclosure Material
paintable, weather resistant
Grille Powder-coated aluminum w/rotatable logo
Terminals Front baffle mounted accessed via rear pull-through
Speaker Weight 5.8 lbs. (2.6kg)
Speaker Dimensions 11.0"(27.9cm) H x 7.0"(17.8cm) W x 6.1"(15.5cm) D
Speaker Dimension
11.0"(27.9cm) H x 7.0"(17.8cm) W x 6.9"(17.5cm) D
w/ Wall Mount
Other Mounting Options 1/4", 20-thread insert on cabinet rear
Finishes White/Black enclosure and grille
Wire Gauge Accommodated up to 16AWG
Sold As Speaker pairs
Speakers (x2), Grilles (x2), Brackets (x2), Manual,
Included in Carton Mounting Template, Bracket Retaining Screws (x4),
Safety Instructions, Grille Removal Tool
Carton Dimensions 15"(380mm) H x 19.5"(496mm) W x 10.6"(268mm) D
Total Carton Weight 15.21 lbs.(6.9kg)
Item Number 1060387 (white), 1016297 (black)
UPC 743878027037 (white), 743878025989 (black)
Built From 2014
1 3M anechoic
2 IEC 268-5 filtered pink noise with 6dB crest factor
3 Calculated at 1M at power handling power input
4 SPL at 1M, anechoic with 2.83V input
