Point Source Audio CO-3 Owner's Manual

Ear worn

Hide thumbs Also See for CO-3:

Specifications

ELEMENT: Back Electret Condenser

POLAR PATTERN: Omni-directional

FREQUENCY RESPONSE: 50 Hz ~ 16kHz

SENSITIVITY: -60 dB ± 3 dB

(0dB = 1V/microbar at 1,000 Hz)

OUTPUT IMPEDANCE: 1,500 Ω ± 30% (at 1 kHz)

OPERATING VOLTAGE: 1.5V ~ 10V D.C.

MAXIMUM SPL: 116 dB

CABLE LENGTH: 3 ft 11 inches + Connector

NET WEIGHT: .28 oz

CO-3 Ear Worn Microphone

Owner's Manual

BOOM FLEXIBILITY: Fixed/Not bendable

EAR PLACEMENT: Left

INCLUDED ACCESSORIES: Storage box

Read the enclosed instructions and cautions thoroughly before

using this product. Failure to observe the proper use of this

product could result in voiding your warranty.

For help or information, please contact us at:

Email: service@point-sourceaudio.com

w w w . p o i n t - s o u r c e a u d i o . c o m

Web: www.point-sourceaudio.com

Phone (in the US) : 415.226.1122

Table of Contents

Do you have a question about the CO-3 and is the answer not in the manual?

Page 1: Specifications
OUTPUT IMPEDANCE: 1,500 Ω ± 30% (at 1 kHz) OPERATING VOLTAGE: 1.5V ~ 10V D.C. MAXIMUM SPL: 116 dB CABLE LENGTH: 3 ft 11 inches + Connector NET WEIGHT: .28 oz CO-3 Ear Worn Microphone Owner’s Manual BOOM FLEXIBILITY: Fixed/Not bendable EAR PLACEMENT: Left INCLUDED ACCESSORIES: Storage box Read the enclosed instructions and cautions thoroughly before using this product.
Page 2 3. Carefully adjust the “boom” portion of the CO-3 to curve handled delicately. around the face. The capsule portion of the CO-3 is at the tip of the boom. Curve the boom so that the capsule is located 3.5mm locking...
