Point Source Audio CO-7 Owner's Manual

Ear worn

Download this manual

Specifications

ELEMENT: Back Electret Condenser

POLAR PATTERN: Omni-directional

FREQUENCY RESPONSE: 30 Hz ~ 18kHz

SENSITIVITY: 4.0mV / Pascal

OUTPUT IMPEDANCE: 3,000 Ω (at 1 kHz)

OPERATING VOLTAGE: 5V DC

MAXIMUM SPL: 135 dB

CABLE LENGTH: 4 ft .077 inches + Connector

NET WEIGHT: .6 oz

CO-7 Ear Worn Microphone

BOOM FLEXIBILITY: Up to 20,000 repetitive bends

Owner's Manual

EAR PLACEMENT: Left/Right

INCLUDED ACCESSORIES: Wind screen, clothing clip,

storage box

Read the enclosed instructions and cautions thoroughly before

using this product. Failure to observe the proper use of this

product could result in voiding your warranty.

For help or information, please contact us at:

Email: service@point-sourceaudio.com

w w w . p o i n t - s o u r c e a u d i o . c o m

Web: www.point-sourceaudio.com

Phone (in the US): 415.226.1122

Do you have a question about the CO-7 and is the answer not in the manual?

Page 1: Specifications
OPERATING VOLTAGE: 5V DC MAXIMUM SPL: 135 dB CABLE LENGTH: 4 ft .077 inches + Connector NET WEIGHT: .6 oz CO-7 Ear Worn Microphone BOOM FLEXIBILITY: Up to 20,000 repetitive bends Owner’s Manual EAR PLACEMENT: Left/Right INCLUDED ACCESSORIES: Wind screen, clothing clip,...
Page 2 3. Carefully adjust the “boom” portion of the CO-7 to curve the cable termination or electronics, will void your you maximum fitting control every around the face. The capsule portion of the CO-7 is at the tip warranty. time. of the boom. Curve the boom so that the capsule is located...
