Point Source Audio 8 Series Owner's Manual

CO2-8WL Specifications

Omnidirectional Lavalier Microphone
ELEMENT: (2) Back Electret Condenser
POLAR PATTERN: Omnidirectional
FREQUENCY RESPONSE: 20 Hz ~ 20 kHz
SENSITIVITY: -43dB ±3dB
(0db = 1V/microbar at
1kHz)
OUTPUT IMPEDANCE: 1400Ω (at 1kHz)
OPERATING VOLTAGE: 1 ~ 10 V
CABLE LENGTH: 6 ft. + connector
NET WEIGHT: 0.6 oz
MAXIMUM SPL: 136dB SPL
INCLUDED ACCESSORIES: Windscreen, cable clip,
Slider1 clip, storage box
www.point-sourceaudio.com

Product Warranty

Point Source Audio (PSA) products purchased in the
U.S.A. are warranted for one year from date of purchase
to be free of defects in materials and workmanship.
In event of such defect, product will be repaired without
charge or replaced (at our option) with a new product
of equal or superior value. This warranty excludes
defects due to normal wear, abuse, shipping damage,
or failure to use product in accordance with instructions.
This warranty is void in the event of unauthorized repair
or modification.
Please register your product warranty and always
KEEP YOUR RECEIPT.
REGISTER YOUR WARRANTY
Your prompt product registration establishes your right to
the protection available under the terms and conditions of
your Point Source Audio warranty. It also helps us contact
you in the rare event that we discover an issue with your
product. And, it helps us to bring you new products
specifically designed to meet your needs.
www.point-sourceaudio.com/warranty.html
© 2017 Point Source Audio. All rights reserved. The Point Source
Audio logo is a registered trademark of Point Source Audio. All other
trademarks included herein are the property of their respective owners.
www.point-sourceaudio.com
SERIES8 | CO2-8WL
Dual Lavalier Microphone
Owner's Manual
Read the enclosed instructions and cautions thoroughly
before using this product. Failure to observe the proper
use of this product could result in voiding your warranty.
www.point-sourceaudio.com
®
