CO-8WS Specifications
Omnidirectional Earworn Microphone
ELEMENT:
Back Electret Condenser
POLAR PATTERN:
Omni-directional
FREQUENCY RESPONSE:
20 Hz ~ 20 kHz
SENSITIVITY:
-54dB ±3dB
(0dB = 1V/microbar at 1kHz)
OUTPUT IMPEDANCE:
1400
(at 1kHz)
OPERATING VOLTAGE:
1 ~ 10 V
CABLE LENGTH:
4 ft .077 in. + connector
NET WEIGHT:
0.6 oz
MAXIMUM SPL:
148dB SPL
INCLUDED ACCESSORIES:
Windscreen, body clip,
storage box
CR-8S Specifications
Cardioid Earworn Microphone
ELEMENT:
Back Electret Condenser
POLAR PATTERN:
Uni-directional
FREQUENCY RESPONSE:
160 Hz ~ 14 kHz
SENSITIVITY:
-70dB ±3dB
(0dB = 1V/microbar at 1kHz)
OUTPUT IMPEDANCE:
5000
(at 1kHz)
OPERATING VOLTAGE:
1 ~ 10 V
CABLE LENGTH:
4 ft .077 in. + connector
NET WEIGHT:
0.6 oz
MAXIMUM SPL:
135dB SPL
INCLUDED ACCESSORIES:
Windscreen, body clip,
storage box
www.point-sourceaudio.com
SERIES8 | CO-8WS | CR-8S
Earworn Microphone
Owner's Manual
Read the enclosed instructions and cautions thoroughly before
using this product. Failure to observe the proper use of this
product could result in voiding your warranty.
w w w . p o i n t - s o u r c e a u d i o . c o m
Advertisement
Related Manuals for Point Source Audio 8 Series
Summary of Contents for Point Source Audio 8 Series
- Page 1 CO-8WS Specifications CR-8S Specifications Omnidirectional Earworn Microphone Cardioid Earworn Microphone ELEMENT: Back Electret Condenser ELEMENT: Back Electret Condenser POLAR PATTERN: Omni-directional POLAR PATTERN: Uni-directional FREQUENCY RESPONSE: 20 Hz ~ 20 kHz FREQUENCY RESPONSE: 160 Hz ~ 14 kHz SENSITIVITY: -54dB ±3dB SENSITIVITY: -70dB ±3dB (0dB = 1V/microbar at 1kHz)
- Page 2 Read Before Use Using with Your Wireless System Read the enclosed instructions and cautions thoroughly before boom feature allows for 360˚ using this product. Failure to observe the proper use of this bending, but it is always a good product could result in voiding your warranty. idea to handle any electronic device with care.
