A Graham-Field Brand
Warning: This product should not be used without proper instruction from a healthcare
professional.
Warning: The scale is able to measure weight range up to 600 lbs. However, the LF1007 lift
has a maximum user weight limitation of 360 lbs., and the LF1009A lift has a maximum
user weight limitation of 400 lbs. Do not exceed your lift's maximum user weight limitation
when using this scale.
Warning: Lumex assumes no responsibility for any damage or injury caused by improper
installation, assembly or use of this product.
Warning: If components are damaged or missing, contact your dealer immediately. DO NOT
use substitute parts.
Warning: Ensure that all lift and scale components are securely mounted as instructed in the
Assembly Instructions for your specific lift and scale before use.
LIFT SCALE SPECIFICATIONS
WEIGHT RANGE ................... 600 lb / 270 kg
DISPLAY RESOLUTION ....... 0.1 lb / 0.1 kg
ACCURACY ........................... 0.1% +/- Digit of reading
DISPLAY TYPE ...................... LCD
SIZE ....................................... 3" x 3" x 4"
WEIGHT ................................. 1 Pound
POWER SUPPLY ................... 9V Battery
BATTERY LIFE ...................... Approx. 3,000 readings
The LUMEX Lift Scale is a compact precision scale system designed for use with approved lift designs
employing compatible boom and hanger configurations.
Completely self-contained, the LUMEX Lift Scale combines the latest microprocessor and load cell technol-
ogy to provide accurate and repeatable weight data with a calibrated accuracy of 0.1%.
One button Auto-Zero Electronics makes patient weighing quick and easy.
The LUMEX Lift Scale is powered by a single 9-Volt battery that will provide approximately 3,000 readings.
Installation
Refer to the Assembly Instructions provided with your scale, and attach the scale system as described.
LF1007 / LF1009A: Lift Scale Kit Operation Instructions
©Graham-Field Health Products, 11/03
LF1007 / LF1009A: LIFT SCALE KIT
OPERATION INSTRUCTIONS
patient lift scale
1
